Lightolier Lytecaster 1029 Specification

Page 1 of 2
1029/1000P1 Series
Standard Incandescent
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim
1029 † Matte Black Step Baffle
1029BNM Natural Metal Baffel
with Natural Metal Flange
1029CD † Clear Diffuse, White Flange
1029GD † Specular Gold
1029CL † Specular Clear
1029BK † Specular Black
1029WH White Step Baffle
† = add "NM" to sku for Natural Metal™ flange
Features
1. Housing Hydroformed aluminum, .040" thick (18 ga.): white or Natural
Metal ™ trim flange.
2. Aperture: Aluminum step baffle or cone, painted or anodized finish.
3. Lampholder Assembly: Provides 358° horizontal rotation and 0° to 35°
vertical adjustment. Vertical adjustment with PAR30 lamp is 0°
to 30°.
4. Frame-In Kit: (1000PI standard frame shown) Other frames listed above and
shown on the right. See Frame-In Kit specification sheets for more details.
Lytecaster
3
Frame-In Kit — See Individual Frame-In Kit Specification Sheets
Frame-In Kit Ceiling Type
1000P1 Non-IC
1000IC IC
1000AICM AirSeal® IC
Recessed Downlighting
®
5" Aperture Recessed Adjustable Reflector Trim
Incandescent
Lamping Height
50W PAR20 6 7/8"
75W PAR30
75W PAR16
50W PAR20 7 5/16"
50W PAR30 7 5/16"
75W PAR16
Options & Accessories
Extra Wide Flange Trim Ring: 1957- 7" O.D.
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
©2011 Genlyte Group LLC • J0711
1029/1000IC Series
Incandescent Insulated Ceiling
Type:
www.lightolier.com
1029
35˚
