Lightolier Calculite 8051 Specification

Page 1 of 2
13-5/8"
(346 mm)
Ceiling Cutout: 6 9/16"(167 mm) Dia.
Reflector Trim
8051CLW Clear Iridescence Free, White Flange
8051CLP
Clear Iridescence Free, Polished Flange
8051CL Clear Iridescence Free, Molded Trim Ring
8051 Add suffix. See options for other finishes.
Features
1. Reflector: 16 ga. Specular Alzak
and lamp image, wide distribution. Iridescence Free finish. Self-flanged or
flangeless with molded white trim ring (field paintable).
2. Socket Cup: Die-cast zinc cup effectively dissipates heat and positions
lamp holder. Snaps onto reflector neck to assure consistently correct optical
alignment without tools.
3. Mounting Frame: Die-cast aluminu for dry or plaster ceilings.
4. Retaining Springs: Precision-tooled steel friction springs secure reflector
to mounting frame for quick, tool-less installation.
5. Mounting Brackets: 16 ga. steel. Adjust from inside of fixture. Use 3/4" or
1 1/2" lathing channel, 1/2" EMT, or optional mounting bars.
6. Ballast/J-Box: Outboard mounted to reduce heat transfer and maintain
lamp efficacy and life. Service from below without tools.
Electrical
Note: For ballast electrical data and latest lamp/ballast compatibility refer to
"Ballast" specification sheet for complete electrical data.
UL listed for through branch circuit wiring with max of (8) No. 12 AWG, 90° C
supply conductors.

Options and Accessories

Comfort Clear Finishes
™
Clear CCL
Diffuse CCD
CCZ
Champagne Bronze
Specify desired flange
1
W White, P Polished
Blank - Molded Ring
Lightolier is a Philips group brand
5
6"
(152 mm)
3"
(76 mm)
10"
(254 mm)
11-1/8"
(283 mm)
Top View
1" (25 mm) min.-
2-1/8" (54 mm) max.
aluminum, 55° visual cutoff to lamp
®
Other Finishes
1
White WH
Multigroove MG
Calculite
2 1
4
6" (152 mm) Dia.
6-1/2" Trimless
7-1/4" Self-Flanged
(165 mm) (184 mm) Trim
Frame-In Kit
6218HU Electronic 4-pin
6218HDU3
PowerSpec ® Dimming 4-pin
Options and Accessories (continued)
Emergency
Chicago Plenum
Existing/Thk.Ceiling
Emergency Ltg. Kit
Fuse (Slow Blow)
*See Spec. Sheets: FAEC, FAEM
Mounting Bars & Accessories; see Specification Sheet MBA.
Sloped Ceiling Adapters; see Specification Sheet SCA.
Labels
UL listed for damp locations, I.B.E.W.
Alzak is a registered trademark of ALCOA.
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • B0711
CFL Open Downlight
®
6" Aperture (2) Quad Tube Horizontal Lamp
3
1-1/8" (29 mm) max.
Ceiling Thickness
Lamp
120V - 277V (2) 18W Quad Tube
120V - 277V
Add suffix EM*
Add suffix LC
FA EC6*
FA EM3E* (4 Pin)
FA EM4E* (4 Pin)
FA EM1T* (2 Pin)
Add Suffix F
Type:
8051
6
