Elo TouchSystems ET2239L 22” LCD Touchmonitor User Guide Revision D P/N E653007 Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com...
Page 3
fi tness for a particular purpose. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content hereof without obliga- tion of Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments...
About the Product Your new ET2239L Elo TouchSystems Touchmonitor combines the reliable performance of touch technology with the latest advances in Liquid Crystal Display (LCD) design. The monitor comes with the fol- lowing features: • • • • For more detailed information, please visit our website: www.elotouch.com.
C H A P T E R INSTALLATION AND SETUP This chapter discusses how to install and set up your LCD touchmonitor and how to install Elo TouchSystems driver software. Elo TouchSystems ET2239L User Guide...
Check that the following items are present and in good condition: Touchmonitor USB Cable Serial Cable (not included with ET2239L-Axxx models) Analog Video ET2239L-xxxx-x-A-x CD and Quick Install Guide OSD Control Box Elo TouchSystems ET2239L User Guide Power cable DVI-D cable (not included with models)
Connect the OSD control box to the monitor. Press the power button on the rear panel to turn the monitor on. DVI-D cable Power OSD box USB cable (not included with Button connector ET2239L-xxxx-x- A-x models) Elo TouchSystems ET2239L User Guide Analog Video Cable...
• Windows NT 4.0 The latest versions of drivers and driver information for other operating systems are available on the Elo TouchSystems web site at www.elotouch.com/support/downloads/. To install the Touch Driver for Windows XP, Windows 2000, Me, and 98, follow...
Page 10
“Specify a location” and use Browse to select the \EloUSB directory on the Elo CD-ROM. Choose Next. Once the Elo TouchSystems touchscreen driver has been detected, choose Next again. You will see several fi les being copied. Insert your Windows 98 CD if prompted.
Alternatively, the monitor may be mounted in the portrait orientation. For this orientation, the cable connection panel may be on either side, as shown in the illustrations below. Rear View of Monitor—Portrait Orientation Elo TouchSystems ET2239L User Guide...
Page 12
Landscape Mounting Orientation Angle Views The mounting orientation can be up to a 90° angle from vertical, as shown in the illustrations below. 90º 90º Elo TouchSystems ET2239L User Guide...
Page 13
Portrait Mounting Orientation Angle Views The mounting orientation can be up to a 90° angle from vertical, as shown in the illustration below. 90° Elo TouchSystems ET2239L User Guide...
Range” (OOR) message and the OSD menu will be disabled. Note: Do not operate the touchmonitor if you see the OOR message, or LCD damage may result. If you see the OOR message, set the video mode to one within the allowable range. Elo TouchSystems ET2239L User Guide...
1) Enters brightness adjustment (if no OSD is currently displayed on screen) 2) Decreases value of OSD adjustment choice 1) Automatically adjusts the image on the screen (this function not available for ET2239L-xxEx models) 2) Selects adjustment choices from the OSD menus. Elo TouchSystems ET2239L User Guide...
Page 16
2 seconds. A window will appear displaying “Power Unlock.” Continue to hold the buttons down for another 2 seconds and the window toggles to “Power Lock.” NOTE: By default, the OSD screen will disappear if no input activities are detected for 30 seconds. Elo TouchSystems ET2239L User Guide...
OSD Timeout • Adjusts amount of time that the OSD menu is displayed. Language • Selects the language used for the OSD menu from English, French, German, Spanish, Italian, Traditional Chinese, Simplifi ed Chinese, or Japanese. Elo TouchSystems ET2239L User Guide...
Page 18
• Restores original factory settings for all other parameters and video inputs, except language (VGA and DVI). Miscellaneous Sharpness • Adjusts sharpness of video. Display Information • Frequency of the input horizontal/vertical synchronizing signal is indicated. Elo TouchSystems ET2239L User Guide...
The monitor comes with preset settings for commonly used video modes. It will automatically adjust the picture size and centering for any of the video modes listed in Appendix B, ET2239L Specifi cations table, under “Preset Display Modes.” If you make any adjustments to the H-position, V-Position, Clock and...
See Chapter 3 and Appendix B for more information on allowable video modes. Make sure the USB or serial cable is securely attached at both ends. Elo TouchSystems ET2239L User Guide...
Do not block or insert anything inside the venti- lation slots. It is important that your touchmonitor remains dry. Do not pour liquid into or onto your touchmonitor. If your touchmonitor be- comes wet do not attempt to repair it yourself. APPENDIX Elo TouchSystems ET2239L User Guide...
Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. Elo TouchSystems ET2239L User Guide...
Surface Capacitive: Typical 249 cd/m APR: Typical 270 cd/m ; Min 212.5 cd/m Secure Touch: Typical 270 cd/m Rising time: 3.6 ms (typical) Falling time: 1.4 ms (typical) Elo TouchSystems ET2239L User Guide ; Min 200 cd/m , Min 212.5 cd/m...
Page 25
Horizontal - 170° • RGB Analog Video (0.7V p-p, 75 ohm; separate syncs, composite sync, or sync-on-green; TTL positive or negative) • DVI Video (not available for ET2239L-xxxx-x-A-x models) Analog: 15 pin Female D-Sub Digital: Female DVI-D (not available for...
This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. Elo TouchSystems ET2239L User Guide...
Page 28
The user is cautioned that changes or modifi cations to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Elo TouchSystems ET2239L User Guide...
Page 29
(Removing or cutting the line cord ground may increase RF emission levels and may also present a lethal shock hazard to the user.) vii) If you need additional help, consult your dealer, manufacturer, or an experi enced radio or televi- sion technician. Elo TouchSystems ET2239L User Guide...
Page 30
This device is not intended for use at visual display workplaces in compliance with BildscharbV. The following marks have been issued for the unit and appear on the safety label as shown in the illustration below: Elo TouchSystems ET2239L User Guide...
Product to conform to the war- ranty set forth above, then Seller shall, at Seller’s option, either refund to Buyer or credit to Buyer’s account the purchase price of the Elo TouchSystems ET2239L User Guide...
Page 32
Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attributable to Buyer’s products or representations or warranties con- cerning same. Elo TouchSystems ET2239L User Guide...
