Page 1: Document Camera
PS750 Document Camera User Manual [Important] To download the updated quick start guide, multilingual manuals, software, and drivers, please visit Lumens website at http://www.lumens.com.tw/goto.htm English - 0... -
Page 2: Table Of Contents
Contents Copyright Information ..................3 Chapter 1 Precautions ..................4 Safety Precautions ..................5 FCC Warning ....................5 EN55022 (CE Radiation) Warning ............... 5 Chapter 2 Package Content ................6 Chapter 3 Product Overview ................7 Relative Operation Position ..............7 Chapter 4 Installation and Connections ............ - Page 3 I would like to automatically adjust the image to have best brightness and focusing performance (Auto tune) ............22 I would like to set the image source of VGA OUT2 ......22 I would like to switch image sources ..........22 I would like to make text clearer and photos more colorful ....
-
Page 4: Copyright Information
Copyright Information Copyrights © Lumens Digital Optics Inc. All rights reserved. Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. -
Page 5: Chapter 1 Precautions
Chapter 1 Precautions Always follow these safety instructions when setting up and using the Document Camera: Do not place Document Camera in tilted position. Do not place the Document Camera on an unstable trolley, stand or table. Do not use the Document Camera near water or source of heat. Use attachments only as recommended. -
Page 6: Safety Precautions
Safety Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. This Document Camera has a 3-wire AC line Plug. This is a safety feature to ensure that the plug will fit into the power outlet. Do not try to disable this safety feature. If the Document Camera will not be used for a long period of time unplug it from the power outlet. -
Page 7: Chapter 2 Package Content
Chapter 2 Package Content PS750 Quick Start Guide 4-Step Card (For download of other language versions, please visit Lumens website) Download and Safety C-Video Cable Power Adapter Instruction VGA Cable USB Cable Audio cable Power Cord Remote Control Microscope Adapter Appearance may vary with country/region Remote Control Holder... -
Page 8: Chapter 3 Product Overview
Chapter 3 Product Overview Lens Camera arm Auxiliary floodlight and Backlight lamp arm Remote Control Holder DIP Switch Settings SD card slot Control Panel Remote sensor 10. Input/output port 3.1 Relative Operation Position Projector Computer English - 7... -
Page 9: Chapter 4 Installation And Connections
Chapter 4 Installation and Connections System Diagram Projector or Computer Computer (1) monitor Computer Speaker Computer (2) Projector or LCD TV Computer Computer monitor English - 8... -
Page 10: Connecting To A Projector Or Monitor
4.2 Connecting to a Projector or Monitor VGA Cable Power Adapter Power Monitor or Cord Projector 螢幕 Power Outlet 4.3 Connecting to a Computer and Use Lumens Software or an Interactive Whiteboard (IWB) Projector Power USB Cable Adapter VGA Cable Power Cord USB Cable... -
Page 11: Connecting To A Projector, 2 Pcs, And A Monitor At The Same Time
4.4 Connecting to a Projector, 2 PCs, and a Monitor at the Same Time Power Adapter Cable Cable Cable Cable Power (Default) Cord Power Outlet Projector Monitor Computer (1) Computer (2) Press button to switch the image sources. For VGA 1 setting, refer to 8.3 I would like to switch image sources. -
Page 12: Connecting To Dvd And Display Dvd Images
<Note>: It doesn’t support C-Video and VGA simultaneously. Once C-Video is on, VGA OUT is not supported. 4.6 Connecting to DVD and display DVD images Press button to switch the image source. For VGA 1 setting, refer to 8.3 I would like to switch image sources. -
Page 13: Connecting To An Hdtv
4.7 Connecting to an HDTV Power HDMI Cable Adapter Power Cord HDTV Power Outlet 4.8 Connecting to a Computer with RS232 Power RS232 Adapter Adapter (Optional) Power Cord Power Outlet Computer English - 12... -
Page 14: Connecting To Audio Input And Output
4.9 Connecting to Audio Input and Output <Remark> Audio output is set according to VGA input; if VGA IN has Audio in, preset the output of audio source of VGA IN(1). Power Adapter Audio Cable Power Cord Audio Cable Audio Cable TV or DVD Power Outlet Computer (2) -
Page 15: Chapter 5 Start Using
Chapter 5 Start Using <Note>: Please adjust it to be suitable for the local voltage frequency of 50/60Hz. For the frequency in actual use, please refer to the manual. (Attachment 1. Remove the lens cap. 2. Pull up the camera and the camera arm. The camera should aim at the center of the presenter. -
Page 16: Chapter 6 Dip Switch Settings
Chapter 6 DIP Switch Settings <Note>: You must re-start PS750 for DIP switching configuration to take effective. 6.1 Connecting to a projector or monitor 6.1.1 XGA 60Hz output( default values) XGA 50Hz output 6.1.2 SXGA 60Hz output SXGA 50Hz output 6.1.3 720P 60Hz output 720P 50Hz output 6.1.4 Special Mode 60Hz output... -
Page 17: Connecting To A Tv/Dvd
6.2 Connecting to a TV/DVD 6.2.1 NTSC: America, Taiwan, Panama, Philippines, Canada, Chile, Japan, Korea and Mexico 60Hz 50Hz 6.2.2 PAL: Countries or regions not listed above. 60Hz 50Hz <Remark> It doesn’t support C-VIDEO and VGA simultaneously. Once C-VIDEO is on, VGA is not supported. English - 16... -
Page 18: Chapter 7 Control Panel/Remote Control And Setting Menu
Chapter 7 Control Panel/Remote Control and Setting Menu Functions of control panel and remote control <Note>: OSD is not available at C-VIDEO mode. [MENU] / [ENTER] / [PLAYBACK] / [ROTATE] / [PAN] / [RECORD] / [CAPTURE] / [DELETE] / [VGA] / [SLIDE SHOW] / [PBP] functions are not available on the machine panel and the remote control. - Page 19 MENU Remote Activate the setting menu function/exit menu. control / Control panel Remote Switch a part of the live image. control Display live images together with captured images. Remote control PLAYBACK Display the list of captured images. Remote control / Control panel Turn on the projector.
-
Page 20: Setting Menu
Setting Menu <Remark> Press [MENU] on the remote control or control panel to enter the setting menu; The bold underlined values in the following table are the defaults. Level Level Level Major Adjustment Function Descriptions Minor Items Items values Adjust the image to the optimal Auto Tune Enter condition. - Page 21 Use the left and right arrow keys to select, and then press [ENTER] to confirm the deletion Delete All Yes/No of photos. Delete the image stored in the SD card (priority) or internal memory. Use the left and right arrow keys to select, and then press [Enter] Format Yes/No...
- Page 22 1. Use the left and right arrow keys to select the images displayed by VGA OUT(2). 2. VGA IN: Use the [VGA 2] key on the control panel to select VGA IN / VGA VGA OUT(2) whether the screen images Out(1) are output from VGA IN(1) or VGA IN(2).
-
Page 23: Chapter 8 Descriptions Of Major Functions
Chapter 8 Descriptions of major functions 8.1 I would like to automatically adjust the image to have best brightness and focusing performance (Auto tune) 1. Press [AUTO TUNE] on the remote control or control panel to adjust automatically. 8.2 I would like to set the image source of VGA OUT2 Press [MENU] on the remote control or control panel to enter the setting menu 1. -
Page 24: I Would Like To Make Text Clearer And Photos More Colorful
I would like to make text clearer and photos more colorful The default of [PHOTO/TEXT] is PHOTO. Use the remote control or the control panel to change settings. [Photo] (default): for viewing photos or text with photos and will make the photos more colorful. -
Page 25: I Would Like To Capture Images
I would like to capture images 8.9.1 Setting the quality of captured images 1. Press [MENU] on the remote control or control panel to enter the setting menu. 2. Press [] or [] to the [Storage] menu. 3. Press [] to find [Image Quality]. 4. -
Page 26: I Would Like To Delete Captured Images
I would like to delete captured images 8.11 1. Use the remote control and press [PLAYBACK] 2. Press [] or [] or [] or [] to select the thumbnail you want you delete. 3. Pressing [DELETE] will open a [Delete File] window. 4. -
Page 27: I Would Like To Switch A Part Of The Live Image (Pan)
8.13.3. Playing image 1. Press [PLAYBACK] on the remote control or control panel to display thumbnails of all videos recorded. 2. Press [] or [] or [] or [] to select files to browse. 3. Press [ENTER] for full-screen play. 4. -
Page 28: I Would Like To View The X-Ray Film
8.15.2 Setting delay time 1. Press [MENU] on the remote control or control panel to enter the setting menu. 2. Press [] or [] to the [Storage] menu. 3. Press [] to find [Delay]. 4. Press [] or [] to select image switch mode between [0.5 Sec / 1 Sec / 3 Sec / 5 Sec / 10 Sec / Manual]. -
Page 29: I Would Like To Resume The Factory Default Setting (Factory Reset)
5. Press [PLAYBACK] to return to image thumbnails. 6. Repeat Steps 2 ~ 4. 7. Press [MENU] to exit. I would like to resume the factory default setting 8.18 (Factory Reset) 8.18.1 Use the OSD menu 1. Press [MENU] on the remote control or control panel to enter the setting menu. -
Page 30: I Would Like To Control Projector
8.20 I would like to control projector. 8.20.1 Connecting to a computer Connect PS750 to a computer, and for connecting method, refer to User Manual 4.8 Connecting to a Computer with RS232. 8.20.2 Installing application software 8.20.2.1 Go to Lumens website: www.lumens.com.tw/goto.htm download the software [Projector Control]. - Page 31 8.20.2.4 When the installation is completed, press [Finish] to end the installation procedure. 8.20.3 Setting procedure 8.20.3.1 Click[Start]/[Programs]/[Projector Setup] 8.20.3.2 When the procedure is started, a setting window will pop up. 8.20.3.3 Press [CONNECT] to set up the connection. [Com Port] lamp flashing green indicates a successful connection.
-
Page 32: Using A Sd Card
8.20.4 Connecting to a projector 8.20.4.1 Remove the RS-232 cable from the computer. 8.20.4.2 Connect the RS-232 cable to the RS-232 port on the projector. PS750 PS750 RS232 Adapter 8.20.5 Control of projector 8.20.5.1 Press [Projector ON] on the control panel to turn on the projector. -
Page 33: Computer-Related Functions
8.20.2.2 The screen will display as follow, once you insert an unformatted SD card: Format SD Card Press [] or [] on the control panel to select. <Note> The data previously saved on the SD card will be erased when it is formatting. - Page 34 8.22.2 I would like to insert a photo in MS-Word <Remark> For Windows Office 2003 or later versions, please use the function with OneNote. 1. Click [Insert / Image / From Scanner or Camera] in MS-Word. 2. Select [Visual Presenter V2] and click [Custom Insert]. 3.
- Page 35 To control the PS750 via the Camera Settings interface. The operating procedure is the same with the remote control and control panel of the PS750. Refer to PS750 User Manual Chapter 7 Control Panel / Remote Control and Setting Menu.
- Page 36 8.22.4 I would like to set the PS750 as a webcam for Skype The PS750 can be used as a webcam for teleconferencing software such as Skype or MSN. With Skype as an example, operating instructions are provided below: 1. Open Skype and enter [Tools] > [Options]. 2.
- Page 37 8.22.5 I would like to set the PS750 as a PC Camera 1. Press [MENU] on the control panel or remote control to enter the setting menu. 2. Press [] or [] to the [Storage] menu. 3. Press [] to find [USB Transfer]. 4.
- Page 38 <Remark> The Removable Disc will select SD card if a SD card has been inserted, but if a SD card has not been inserted, the Removable Disc is internal memory <Note> Doing this will disable the [Capture] function. Suggest you return it to [Camera] mode after using this function.
-
Page 39: Chapter 9 Connecting To Microscope
Chapter 9 Connecting to Microscope 1 Mount the microscope adaptor (Optional accessory) onto the microscope. <Note> Please choose an appropriate microscope adapter. Microscope adapter accessories are applicable to eyepieces of Ø 28mm, Ø 31mm, Ø 33mm, and Ø 34mm. 2 The lens of PS750 connects with the microscope adapter. If the eyepiece is Ø... - Page 40 3.1. If you use the remote control or the control panel 3.1.1. Press [MENU] to enter the setting menu. 3.1.2. Press [] or [] to the [Display]. 3.1.3. Press [] to select [Mode]. 3.1.4. Press [] or [] to the [Microscope]. 4 If the image is not clear 4.1.
-
Page 41: Chapter 10 Packing The Machine
Chapter 10 Packing the Machine Put the remote control back to the holder. Fold back the camera head to align with the arm. Turn the two lamp arms and the arm of camera head down and adjust them to be parallel with the platform. Put the lens cap on the camera head. -
Page 42: Chapter 11 Troubleshooting
PS750 User Manual Chapter 4 Installation and Connections 3. Check the , refer to PS750 User Manual Chapter 8 Descriptions of major functions 8.3 I would like to switch image sources. 4. Check the settings for the source of the projector. For the appropriate input selection of the projector, refer to the projectors user manual. - Page 43 do not light. like to turn on / off the lamp. PS750 fails to store Please make sure whether the stored data has images or react. reached the maximum storage capacity of PS750 unit or SD card. Please make sure if SD card is adjusted to the data protection mode (Lock).
-
Page 44: Attachment 1
Attachment 1 World voltage & frequency Region/Country Region/Country Region/Country Chinese English Chinese English Chinese English 阿 富 汗 50 大 陸 China 50 關 島 Guam Afghanistan 阿爾及利亞 Algeria 50 哥 倫 比 亞 Colombia 60 石 榴 島 Grenada 安... - Page 45 Region/Country Region/Country Region/Country Chinese English Chinese English Chinese English 智 利 Chile 50 格 陸 蘭 Greenland 50 賴 比 瑞 亞 Liberia 利 比 亞 Libya 50 阿 曼 Oman 50 敘 利 亞 Syria 盧 森 堡 50 巴 基 斯 坦 Pakistan 50 大...
