Names of lead wires and destinations

(refer to Page 204)
●
Never connect the power supply to the speaker leads, otherwise it
causes damage to the main unit.
●
To prevent unconnected leads from shorting out, insulate them by
wrapping their tips with electrical tape. Similarly, insulate the ends
of connected leads.
If an external amplifier is to be connected to the receiver, be sure
to ground its outside housing to the vehicle body (a metal part).
No. Name
1 ACC
2 B+
3 Ground
4 Antenna power supply
5 Illumination power
supply
6 Control power supply
7 E-LAN terminal
8 Line-out terminals (Front)
9 Line-out terminals (Rear)
10 Line-out terminals (Nonfader)
11 Speaker leads
Caution ●
Note ●
Wire color
Red
Yellow
Black
Blue
Orange/white Connect to where power comes
Blue/white
Destination
Connect where the power comes
on when the ignition is in the
ACC position.
Connect where the power is
constantly available, regardless
of the ignition switch's position.
Connect where good body
grounding is available.
Connect to the automatic-
antenna control terminal of the
vehicle.
on when the headlights are
turned on.
Connect to the control terminal
for the external amplifier, etc.
Connect to the E-LAN terminal of
the CD changer, etc.
Connect to the RCA input
connectors of an external
amplifier.
Connect to the RCA input
connectors of a EQ, or the RCA
input connectors of a woofer
amplifier.
Connect them to their respective
leads.
201
Mounting instruction
XIX
