Direct Channel Selection; Manually Setting Channels Into Memory; Preset Channel Scan; Switching Displays When Using The Sirius Satellite Radio - Eclipse CD7000 Owner's Manual

About optional unit

Direct channel selection

The channel can be selected by inputting the
channel directly.
Press the [MODE] button for more
1
than one second.
The mode will change to direct
channel selection mode.
Press the [SELECT] (Right/Left)
2
button to select the channel digit
number.
Right: Advances next digit.
Left: Return to previous digit.
Press the [SELECT] (Upper/Lower)
3
button to select
number to be input.
When the button is pressed, the media
type changes in the following order.
0 l 1 l 2 l 3 l 4 l 5 l 6 l 7 l
8 l 9 l 0 l MMM
4
Press the [ENTER] button.
Start reception
Manually setting channels into
memory
This section covers the setting of channels in
memory under the numbered buttons.
Press the [SELECT] (Right/Left)
1
button to tune to the channel to be
entered in memory.
Select any button, from [1] to [6],
2
and press it for more than two
seconds.
The tuned channel is now memorized
and set in the button selected. Repeat
the procedure
manually tuned channels in memory,
in turn, for buttons [1] to [6]. These
buttons are called the preset buttons.
96
the channel
to set additional
ATTENTION
If the vehicle's battery is disconnected (for
repairs to the vehicle or for removing the main
unit), all channels in memory will be lost. In
such a case, set channels in memory again.

Preset channel scan

This function enables reception of all the
channels in the preset buttons for five seconds
each.
Press the [SELECT] (Lower) button
1
for more than one second.
[P SCAN] will appear at the display,
and channels stored under preset
buttons [1] through [6] will be played
for five seconds each.
To stop the preset scan mode at a
2
desired channel,
[SELECT] (Lower) button again.
The main unit will stay tuned to the
desired channel.
Switching displays when using
the SIRIUS satellite radio
Press the [SCREEN] button for
1
more than one second.
Each time the button is pressed the
display item changes in the following
order:
channel name
o
artist album
o o
ATTENTION
• The maximum number of characters that
can be displayed for each item is as follows:
Title: 38 characters
Artist: 38 characters
Album: 38 characters
Channel: 20 characters
Category: 16 characters
• If there is no name, NO_ DATA will appear.
press the
category name title
o
channel name
o o MMM
