WARRANTY
IF YOU NEED HELP OR PARTS, CALL THE CENTRO HOTLINE
HOURS: 8AM-7PM EST Mon-Fri, Close Saturday and Sunday
MISSING / DAMAGE D PA R TS • A SSEMBLY • T R OU BL ES H O OTIN G • WA R R A N T Y A S S I S TA N C E
TIP: A SS EM BL E YOUR GRI LL I MMED IAT ELY. MIS S I NG O R DAMAG E D PA R TS MU S T BE
GRILL SAFETY CHECK
For your family's safety, please check the following:
READ and UNDERSTAND the owner's manual
PERFORM LEAK TEST on all connections as specified in this user manual. Leak Checks should be performed
on all new BBQ's even if assembled by an assembler or gas technician. Leak checks should be performed
frequently thereafter.
INSPECT and CLEAN burner tubes to avoid flash fires caused by spider webs and other blockages. Inspect gas
jets to ensure they are correctly installed in burner tubes. Never leave a lit grill unattended.
BEFORE OPENING THE GAS SUPPLY, ensure the lid is open, control knobs are in OFF position, gas is turned off,
and the regulator is attached to tank correctly. Then follow the PROPER LIGHTING PROCEDURE as shown in the
manual. If above steps are not followed, you may experience low flames, or other performance issues.
CHECK that the regulator nipple is centered into the LP tank valve. Do NOT cross thread this connection. Cross
threading may result in a fire, or explosion at the tank connection.
AVOID dangerous grease fires by performing regular cleaning and maintenance of interior casting, the grease
collection system, flame tamers and cooking grates.
Manufacturer Name
Winners Products Engineering Ltd.
25/F Top Glory Tower 262 Gloucester Road, Causeway Bay, Hong Kong
Do n ot re t u rn t h e p ro d u c t to th e s to re.
1 - 877-707-5463
• PRO D U C T IN FO R MATIO N
CL AI MED WI T H IN 3 0 DAYS , O F PU R C H A S E.
S TOP
G E T H E LP F OR :
1
Advertisement
Table of Contents
Related Manuals for Centro 03122008 EJ
Summary of Contents for Centro 03122008 EJ
- Page 1 WARRANTY IF YOU NEED HELP OR PARTS, CALL THE CENTRO HOTLINE HOURS: 8AM-7PM EST Mon-Fri, Close Saturday and Sunday MISSING / DAMAGE D PA R TS • A SSEMBLY • T R OU BL ES H O OTIN G • WA R R A N T Y A S S I S TA N C E TIP: A SS EM BL E YOUR GRI LL I MMED IAT ELY.
- Page 2 T H I S B A R B E C U E I S F O R O U T D O O R U S E O N L Y Manual Revision #: 03122008 EJ please visit us on the web at www.centrobbqs.com...
-
Page 3: Table Of Contents
CAUTION Some parts may contain sharp edges – especially as noted in the manual! Wear protective gloves if necessary. For residential use ONLY. Do not use for commercial cooking. WARNING Do not attempt to repair or alter the hose and regulator or valve assembly for any assumed defect or for any type of retro fit or conversion. -
Page 4: Installation
• DO NOT block holes in sides or back of grill. • DO NOT use charcoal or ceramic briquettes in a gas grill. • DO NOT attempt to light burner with lid closed. A buildup of non-ignited gas inside a closed grill is hazardous. -
Page 5: Requirements
GAS HOOK-UP’S AND WARNINGS (LP) LIQUID PETROLEUM GAS • LP gas is nontoxic, odorless and colorless when produced. For Your Safety, LP gas has been given an odor (similar to rotten cabbage) so that it can be smelled. • LP gas is highly flammable and may ignite unexpectedly when mixed with air. LP cylinder requirements: •... -
Page 6: Transportation And Storage
LP GAS WARNINGS: • Always turn cylinder valve off when the barbecue is not in use. • Always handle the tank valve with the utmost care. • Never connect an unregulated LP gas cylinder to the barbecue • Always keep the cylinder, in use, securely fastened in an upright position •... -
Page 7: Safety Hose And Regulator
LP Cylinder Leak Test For Your Safety ATTENTION: Leak Test must be repeated each time the LP cylinder is exchanged or refilled. • Do not smoke during leak test. • Do not use an open flame to check for gas leaks •... -
Page 8: Leak Testing
FOR NATURAL GAS MODELS (if applicable) All Centro Natural Gas Barbecues come equipped with a 10’ or 12’ Natural Gas hose with a quick connect socket connection. This will allow you to attach your Barbecue to your residential gas line. -
Page 9: Natural Gas Hook-Ups And Warnings
85,000 BTU’s required (depending on the model). Please contact Centro Customer Care for requirements and then consult with your certified natural gas technician. • All gas supply plumbing must be carried out by a qualified service agency. The Supply connection shall be carried out in accordance with provincial authorities having jurisdiction, and in accordance with CAN/CGA 1-B149.1 &... - Page 10 Match-Lighting Main Burners 1. Open lid. Turn off all control knobs. Ensure LP cylinder is closed. 2. Turn on the gas supply valve at the tank (1 to 2 turns) or turn on the main gas supply valve. 3. Insert a lit match or a butane lighter into the match lighting hole located on the left hand side or right hand side of the barbecue cart (on the under side of the burner side shelf ).
- Page 11 See illustration at right. 1. Attach electrode to burner. 2. Carefully replace burners. 3. Attach burners to brackets on firebox. 4. Reposition carryover tubes and attach to burners. Replace flame tamers and cooking grates. Ensure burner sits properly over valve. Centro 6800 only.
-
Page 12: Cooking And Performance
COOKING AND PERFORMANCE Grilling Tips • Create an improved, non-stick cooking surface by coating all cooking grates with vegetable shortening or cooking oil before preheating. • To reduce flare up’ s keep the BBQ clean, cook lean cuts of meat, trim excess fat and avoid cooking over very high temperatures. •... - Page 13 • This gas barbecue has a 12,000 BTU infrared rear burner. The rear burner is designed to be used in conjunction with the Centro Rotisserie Kit. See the Rotisserie Kit for usage and assembly instructions. • Place the prepared spit rod across the hangers inside the grill.
- Page 14 Resetting the Regulator Flow Limiting feature 1. With all control knobs and the gas source in the OFF position, Open the BBQ lid 2. Disconnect the hose and regulator from the Propane tank 3. Turn all BBQ control knobs to the “Hi” position 4.
-
Page 15: Troubleshooting
Prevent Grease Fires by: • Keeping BBQ clean • Frequently cleaning the grease collection plate and grease cup • Frequently changing the ignitor battery. • Not cooking over maximum heat for extended periods of time • Burning off build-up on the cooking grates and heat plates after each use FOR YOUR SAFETY •... - Page 16 PROBLEM Electrode sparks but the burner will not light. CAUSE Electrode wire (lead wire) is unplugged or has a loose connection Electronic Igniter Module battery is dead Battery cap not threaded properly Electrode not properly spaced Damaged collector box Blockage within Venturi tubes Low fuel, no fuel, or gas source not opened Flow limiting device in regulator has...
- Page 17 Resolving BURNER Performance Issues PROBLEM Burner will not light (with igniter or match) Burner lights with match but not with igniter (NO SPARK) Fire at control knob and control panel = Flash Fire Yellow smoky flames Flame blows out on LOW Burner does not get hot enough Low or incomplete flame (assuming burners and Venturi tubes are free and...
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning and Maintaining your BBQ ensures safe and effective use, while eliminating the possibility of PARTS DETERIORATION and POOR PERFORMANCE. If you are experiencing any of the following performance or safety issues including but not limited to: 1) BBQ not reaching temperature potential, 2) yellow burner flames, 3) you smell gas, 4) popping noises, 5) delayed burner ignition, 6) uneven heat, 7) flash fires, or 8) grease fires, TURN OFF YOUR GRILL immediately and perform the 30 minute maintenance regime shown below. - Page 19 CAUTION: Do not use anything larger in diameter than the port hole itself as this may cause damage to the burner port holes. 6. Using a Venturi brush, or bottle cleaning brush, clean the interior of the burner. Special care should be taken to make sure the brush passes through the entire burner interior.
- Page 20 Cleaning STAINLESS STEEL parts To protect the appearance and integrity of Stainless Steel surfaces, routine cleaning is essential. Contaminants vary greatly in their effect on appearance, corrosivity and ease of removal. Identify the contaminant or experiment with various cleaners in order to resolve issues including the removal of free-iron contamination. It is impossible to wear out the stainless steel by excessive cleaning.
-
Page 21: Warranty And Service
1. Call the Centro® Customer Care Hotline 1-877-707-5463 2. Do not return to the store for replacement of damaged or defective parts. Centro® Customer Care will ensure that all in- stock replacement parts arrive at your home within 3-10 business days. -
Page 22: Warranty
WARRANTY LIMITATION AND EXCLUSIONS Trileaf Distributions® has the following limitations to its warranty: 1. This limited warranty is non-transferable and becomes void if used for commercial or rental purposes. 2. This warranty applies only when barbecue is used in Canada 3.
