PRODUCT NO.
BASE MODEL NO.
FRT21R6AB2
FRT21R6A
FRT21R6AB3
FRT21R6A
FRT21R6AQ2
FRT21R6A
FRT21R6AQ3
FRT21R6A
FRT21R6AW2
FRT21R6A
FRT21R6AW3
FRT21R6A
MARKET
North America
WIRING DIAGRAM - # 240379007
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET - # 240379007
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995364345
020123
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21R6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21R6A
Summary of Contents for Frigidaire FRT21R6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21R6AB2 FRT21R6A R134a black FRT21R6AB3 FRT21R6A R134a black FRT21R6AQ2 FRT21R6A R134a bisque FRT21R6AQ3 FRT21R6A R134a bisque FRT21R6AW2 FRT21R6A R134a white FRT21R6AW3 FRT21R6A R134a white MARKET North America WIRING DIAGRAM - # 240379007 OWNER’S GUIDE - # 240400105 SERVICE DATA SHEET - # 240379007 TOP MOUNT...
- Page 2 Publication No. FRT21R6A 5995364345 DOOR 01/02...
- Page 3 FRT21R6A Publication No. 5995364345 DOOR A = FRT21R6A (FRT21R6AB2) B = FRT21R6A (FRT21R6AB3) C = FRT21R6A (FRT21R6AQ2) D = FRT21R6A (FRT21R6AQ3) E = FRT21R6A (FRT21R6AW2) F = FRT21R6A (FRT21R6AW3) POS. NO PART NO DESCRIPTION 240514611 A B - - - - Gasket-frzr door,black ,magnetic 240514607 - - C D E F...
- Page 4 Publication No. FRT21R6A 5995364345 CABINET 01/02...
- Page 5 FRT21R6A Publication No. 5995364345 CABINET A = FRT21R6A (FRT21R6AB2) B = FRT21R6A (FRT21R6AB3) C = FRT21R6A (FRT21R6AQ2) D = FRT21R6A (FRT21R6AQ3) E = FRT21R6A (FRT21R6AW2) F = FRT21R6A (FRT21R6AW3) POS. NO PART NO DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F...
- Page 6 Publication No. FRT21R6A 5995364345 SHELVES 01/02...
- Page 7 FRT21R6A Publication No. 5995364345 SHELVES A = FRT21R6A (FRT21R6AB2) B = FRT21R6A (FRT21R6AB3) C = FRT21R6A (FRT21R6AQ2) D = FRT21R6A (FRT21R6AQ3) E = FRT21R6A (FRT21R6AW2) F = FRT21R6A (FRT21R6AW3) POS. NO PART NO DESCRIPTION 215667501 A B C D E F Tray-ice,plastic 240358003 A B C D E F...
- Page 8 Publication No. FRT21R6A 5995364345 SYSTEM 01/02...
- Page 9 FRT21R6A Publication No. 5995364345 SYSTEM A = FRT21R6A (FRT21R6AB2) B = FRT21R6A (FRT21R6AB3) C = FRT21R6A (FRT21R6AQ2) D = FRT21R6A (FRT21R6AQ3) E = FRT21R6A (FRT21R6AW2) F = FRT21R6A (FRT21R6AW3) POS. NO PART NO DESCRIPTION 240444401 A B C D E F Condenser,dynamic 218944001 A B C D E F...
-
Page 10: Wiring Schematic
Publication No. FRT21R6A 5995364345 WIRING SCHEMATIC 01/02... -
Page 11: Wiring Diagram
FRT21R6A Publication No. 5995364345 WIRING DIAGRAM # = Fast-moving Parts 01/02 * = Non-Illustrated Parts...
