PRODUCT NO.
BASE MODEL NO.
FRT21R7ASB2
FRT21R7AS
FRT21R7ASB5
FRT21R7AS
MARKET
North America
ENERGY GUIDE LABEL - 240791408
OWNER'S GUIDE - 2 = 240400105 & 5 = 240400106
SERVICE DATA SHEET - # 240379009
SERIES
COLOR
R134a
stain/blk
R134a
stain/blk
Publication No.
5995374633
020619
-EN/SERVICE/DCS
357
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21R7AS
Advertisement
Related Manuals for Frigidaire FRT21R7AS
Summary of Contents for Frigidaire FRT21R7AS
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21R7ASB2 FRT21R7AS FRT21R7ASB5 FRT21R7AS MARKET North America ENERGY GUIDE LABEL - 240791408 OWNER’S GUIDE - 2 = 240400105 & 5 = 240400106 SERVICE DATA SHEET - # 240379009 SERIES COLOR R134a stain/blk R134a stain/blk TOP MOUNT...
- Page 2 DOOR...
- Page 3 A = FRT21R7AS (FRT21R7ASB2) B = FRT21R7AS (FRT21R7ASB5) POS. NO 240514611 240514612 240338303 240381305 240450323 240450335 240416304 240312405 240312406 240494005 240383603 240450428 240450443 240339203 240339208 240383401 218252200 240311202 240527102 240338101 240338201 240495801 240345506 218490900 DOOR PART NO DESCRIPTION Gasket,frzr door seal ,black ,magnetic...
- Page 4 CABINET...
- Page 5 A = FRT21R7AS (FRT21R7ASB2) B = FRT21R7AS (FRT21R7ASB5) POS. NO 240355404 5308000010 5300157666 5303292396 240313606 240371303 10*# 240385402 10*# 240524701 5303208309 240366801 240374401 13 # 240369701 218931001 5303292397 240433201 240411901 218252200 215774918 240335501 240314003 240311301 240313803 240336801 240516401 240337603 240313701...
- Page 6 SHELVES...
- Page 7 A = FRT21R7AS (FRT21R7ASB2) B = FRT21R7AS (FRT21R7ASB5) POS. NO 215667501 240358003 5303299664 240417802 240362601 240466001 14 # 240505801 240436701 240436702 241500701 240407301 17*# 240388701 240360801 21 # 5304421256 240468201 23 # 215846606 5303001259 240355214 240364718 240361201 240361301 240343803 240530903...
- Page 8 SYSTEM...
- Page 9 A = FRT21R7AS (FRT21R7ASB2) B = FRT21R7AS (FRT21R7ASB5) POS. NO 240444401 218944001 240496101 6* # 240388701 6* # 240385402 6* # 240524701 14 # 5303918247 15 # 5303918250 15 # 5303918274 5308000110 240434002 240362301 240362401 240518401 21 # 5303918202 240330006...
-
Page 10: Wiring Schematic
WIRING SCHEMATIC... -
Page 11: Wiring Diagram
5995374633 WIRING DIAGRAM...
