Frigidaire FRT21P5A Factory Parts Catalog

Frigidaire FRT21P5A Factory Parts Catalog

Top mount refrigerator
Hide thumbs Also See for FRT21P5A:

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Service Data Sheet
Installation Instructions 240568300
N05L00006.eps N05DAACKA1.eps N05BBAABD0.eps N05SAAAEE13.eps
N05CAAAAA9.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRT21P5ABD FRT21P5ABE FRT21P5AQD FRT21P5AQE FRT21P5AWD FRT21P5AWE
R134a
R134a
R134a
black
black
bisque
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
North America North America North America North America North America North America
240379014
240379014
240379014
240568300
240568300
Publication No.
5995422028
04/11/15
(EN/SERVICE/DCS)
357
R134a
R134a
R134a
bisque
white
white
115
115
115
240398801
240398801
240398801
240400111
240400111
240400111
240379014
240379014
240379014
240568300
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21P5A
©
Copyright
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21P5A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21P5A

Summary of Contents for Frigidaire FRT21P5A

  • Page 1 Product No. FRT21P5ABD FRT21P5ABE FRT21P5AQD FRT21P5AQE FRT21P5AWD FRT21P5AWE Series R134a R134a R134a R134a R134a R134a Color black black bisque bisque white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801 Owner's Guide 240400111 240400111 240400111 240400111 240400111 240400111 Market North America North America North America North America North America North America Service Data Sheet 240379014...
  • Page 2 Publication No: 5995422028 FRT21P5A DOOR N05DAACKA1 11/04...
  • Page 3 FRT21P5A Publication No: 5995422028 DOOR Model Index: A FRT21P5A (FRT21P5ABD) B FRT21P5A (FRT21P5ABE) C FRT21P5A (FRT21P5AQD) D FRT21P5A (FRT21P5AQE) E FRT21P5A (FRT21P5AWD) F FRT21P5A (FRT21P5AWE) POS. NO PART NO. DESCRIPTION 240514611 A B - - - - Gasket, seal, black, frzr door, magnetic 240514607 - - C D E F Gasket, seal, white, frzr door, magnetic...
  • Page 4 Publication No: 5995422028 FRT21P5A CABINET 11/04...
  • Page 5 FRT21P5A Publication No: 5995422028 CABINET Model Index: A FRT21P5A (FRT21P5ABD) B FRT21P5A (FRT21P5ABE) C FRT21P5A (FRT21P5AQD) D FRT21P5A (FRT21P5AQE) E FRT21P5A (FRT21P5AWD) F FRT21P5A (FRT21P5AWE) POS. NO PART NO. DESCRIPTION 240355402 A B C D E F Cover-fan 240367001 A B C D E F Knob-damper control 5303212803 A B C D E F...
  • Page 6 Publication No: 5995422028 FRT21P5A CABINET 11/04...
  • Page 7 FRT21P5A Publication No: 5995422028 CABINET Model Index: A FRT21P5A (FRT21P5ABD) B FRT21P5A (FRT21P5ABE) C FRT21P5A (FRT21P5AQD) D FRT21P5A (FRT21P5AQE) E FRT21P5A (FRT21P5AWD) F FRT21P5A (FRT21P5AWE) POS. NO PART NO. DESCRIPTION 218362500 A B C D E F Screw, hex washer head, 8-18AB x 1.250, spacer, (2) 240516501 A B C D E F Pin-lower hinge...
  • Page 8 Publication No: 5995422028 FRT21P5A SHELVES N05SAAAEE13 11/04...
  • Page 9 FRT21P5A Publication No: 5995422028 SHELVES Model Index: A FRT21P5A (FRT21P5ABD) B FRT21P5A (FRT21P5ABE) C FRT21P5A (FRT21P5AQD) D FRT21P5A (FRT21P5AQE) E FRT21P5A (FRT21P5AWD) F FRT21P5A (FRT21P5AWE) POS. NO PART NO. DESCRIPTION 215667501 A B C D E F Tray, ice cube, plastic 240358003 A B C D E F Shelf, freezer, full-width, wire...
  • Page 10 Publication No: 5995422028 FRT21P5A SYSTEM N05CAAAAA9 11/04...
  • Page 11 FRT21P5A Publication No: 5995422028 SYSTEM Model Index: A FRT21P5A (FRT21P5ABD) B FRT21P5A (FRT21P5ABE) C FRT21P5A (FRT21P5AQD) D FRT21P5A (FRT21P5AQE) E FRT21P5A (FRT21P5AWD) F FRT21P5A (FRT21P5AWE) POS. NO PART NO. DESCRIPTION 240444401 A B C D E F Condenser, dynamic 218944001 A B C D E F Drier-filter, R134a System 240496101...

  • Page 12: Wiring Schematic

    Publication No: 5995422028 FRT21P5A WIRING SCHEMATIC 11/04...

  • Page 13: Wiring Diagram

    FRT21P5A Publication No: 5995422028 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
