Frigidaire FRT21IL5D Factory Parts Catalog
Top-mount refrigerator with ice-maker r134a series
Hide thumbs
Also See for FRT21IL5D:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
N05L00003.eps N05DCDBCA1.eps N05BBAAAA1.eps N05SACAFI13.eps
N05CABBAB6.eps 115-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21IL5DB0 FRT21IL5DQ0 FRT21IL5DW0
Series
R134a
Color
black
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400111
Market
North America North America North America
Energy Guide
240598683
Service Data Sheet
240379014
Installation Instructions 240568300
240398801.eps 240398601.eps
Publication No.
5995411377
04/06/15
(EN/SERVICE/DCS)
357
R134a
R134a
bisque
white
115
115
240398801
240398801
240400111
240400111
240598683
240598683
240379014
240379014
240568300
240568300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT21IL5D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FRT21IL5D
Summary of Contents for Frigidaire FRT21IL5D
- Page 1 240398801 240400111 240400111 240400111 North America North America North America 240598683 240598683 240598683 240379014 240379014 240379014 240568300 240568300 TOP-MOUNT REFRIGERATOR WITH ICE-MAKER Model No. FRT21IL5D Publication No. 5995411377 04/06/15 (EN/SERVICE/DCS) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved.
- Page 2 Publication No: 5995411377 FRT21IL5D DOOR 06/04...
- Page 3 240338101 240337901 240338001 240495804 # Functional Parts * Non-Illustrated Parts FRT21IL5D DOOR A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION A - - Gasket, seal, black, frzr door, magnetic - B C Gasket, seal, white, frzr door, magnetic...
- Page 4 Publication No: 5995411377 FRT21IL5D CABINET 06/04...
- Page 5 5303001343 240442703 240442704 240442702 240368207 240368206 # Functional Parts * Non-Illustrated Parts FRT21IL5D CABINET A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION A B C Cover-fan A B C Knob-damper control A B C A B C Damper-fan cover...
- Page 6 Publication No: 5995411377 FRT21IL5D CABINET 06/04...
- Page 7 216850900 5303305345 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRT21IL5D CABINET A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION - - C Grille/Kickplate, white A B C Screw, hex washer head, 8-15A x 0.625, low profile A B C...
- Page 8 Publication No: 5995411377 FRT21IL5D SHELVES 06/04...
- Page 9 240530903 240385201 240350654 5308016566 240598683 # Functional Parts * Non-Illustrated Parts FRT21IL5D SHELVES A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION A B C Shelf, freezer, full-width, wire A B C Diffuser-air, top A B C Diffuser, air, bottom...
- Page 10 Publication No: 5995411377 FRT21IL5D SYSTEM N05CABBAB6 06/04...
- Page 11 5303316859 240493101 240409302 5303918210 5304421289 # Functional Parts * Non-Illustrated Parts FRT21IL5D SYSTEM A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION A B C Condenser, dynamic A B C Drier-filter, R134a System A B C Harness-wiring, machine compt...
-
Page 12: Ice Maker
Publication No: 5995411377 FRT21IL5D ICE MAKER 06/04... - Page 13 5303001549 218888001 240352409 # Functional Parts * Non-Illustrated Parts FRT21IL5D ICE MAKER A FRT21IL5D (FRT21IL5DB0) B FRT21IL5D (FRT21IL5DQ0) C FRT21IL5D (FRT21IL5DW0) DESCRIPTION A B C Tube-water inlet, inlet valve, to ice maker A B C Seal-water inlet, inlet valve, to ice maker...
-
Page 14: Wiring Schematic
Publication No: 5995411377 FRT21IL5D WIRING SCHEMATIC 06/04... -
Page 15: Wiring Diagram
FRT21IL5D Publication No: 5995411377 WIRING DIAGRAM 06/04 # Functional Parts * Non-Illustrated Parts...
