PRODUCT NO.
BASE MODEL NO.
FRT21RRJD0
FRT21RRJ
FRT21RRJW0
FRT21RRJ
MARKET
North America
WIRING DIAGRAM - #218663500
OWNER'S GUIDE - #218971800
SERVICE DATA SHEET - # 218901900
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
134A
almond
134A
white
Publication No.
5995337135
000428
-EN/SERVICE /DJH
357
REFRIGERATOR
VOLTS
115V
115V
REFRIGERATOR
FRT21RRJ
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire FRT21RRJ
Summary of Contents for Frigidaire FRT21RRJ
- Page 1 PRODUCT NO. BASE MODEL NO. FRT21RRJD0 FRT21RRJ FRT21RRJW0 FRT21RRJ MARKET North America WIRING DIAGRAM - #218663500 OWNER’S GUIDE - #218971800 SERVICE DATA SHEET - # 218901900 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR 134A almond...
- Page 2 Publication No. FRT21RRJ 5995337135 DOOR 04/00...
- Page 3 A = FRT21RRJ (FRT21RRJW0) B = FRT21RRJ (FRT21RRJD0) POS. NO 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRT21RRJ DOOR PART NO DESCRIPTION 215608915 Gasket-frzr door,white ,magnetic 218730614 Gasket-refr door,white ,magnetic 218979001 Door-Refr interior,panel 218763647 Rack-door 218763648 Rack-door 218763649...
- Page 4 Publication No. FRT21RRJ 5995337135 CABINET 04/00...
- Page 5 A = FRT21RRJ (FRT21RRJW0) B = FRT21RRJ (FRT21RRJD0) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21RRJ CABINET PART NO DESCRIPTION 215937600 Shroud-evap fan mtg 5303292398 Fan Blade 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 5303294238 Cover-evap coil...
- Page 6 Publication No. FRT21RRJ 5995337135 CABINET 04/00...
- Page 7 A = FRT21RRJ (FRT21RRJW0) B = FRT21RRJ (FRT21RRJD0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21RRJ CABINET PART NO DESCRIPTION 5303001479 Screw-hinge mtg,hex hd ,1/4-20 x 0.875 218362601 Plug-grille,white 218362602 Plug-grille,almond 5303319993 Cover-air duct 218044800 Seal-air duct cover...
- Page 8 Publication No. FRT21RRJ 5995337135 SHELVES 04/00...
- Page 9 A = FRT21RRJ (FRT21RRJW0) B = FRT21RRJ (FRT21RRJD0) POS. NO 8* # 14 # 15 # 16A# 19 # 21 # 23 # 121* # = Fast-moving Parts * = Non-Illustrated Parts FRT21RRJ SHELVES PART NO DESCRIPTION 218652300 Mullion,white 218752300...
- Page 10 Publication No. FRT21RRJ 5995337135 SYSTEM 04/00...
- Page 11 A = FRT21RRJ (FRT21RRJW0) B = FRT21RRJ (FRT21RRJD0) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21RRJ SYSTEM PART NO DESCRIPTION 218787700...
-
Page 12: Wiring Schematic
Publication No. FRT21RRJ 5995337135 WIRING SCHEMATIC 04/00... -
Page 13: Wiring Diagram
FRT21RRJ Publication No. 5995337135 WIRING DIAGRAM # = Fast-moving Parts 04/00 * = Non-Illustrated Parts...
