Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21P5AB3
FRT21P5A
FRT21P5AQ3
FRT21P5A
FRT21P5AW3
FRT21P5A
MARKET
North America
WIRING DIAGRAM - # 240398801
OWNER'S GUIDE - # 240400105
SERVICE DATA SHEET -# 240379007
Electrolux Home Products, Inc.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995364006
020117
-EN/SERVICE /BLT
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P5A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT21P5A
Summary of Contents for Frigidaire FRT21P5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21P5AB3 FRT21P5A R134a black FRT21P5AQ3 FRT21P5A R134a bisque FRT21P5AW3 FRT21P5A R134a white MARKET North America WIRING DIAGRAM - # 240398801 OWNER’S GUIDE - # 240400105 TOP MOUNT SERVICE DATA SHEET -# 240379007 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21P5A 5995364006 DOOR 01/02...
- Page 3 FRT21P5A Publication No. 5995364006 DOOR A = FRT21P5A (FRT21P5AB3) B = FRT21P5A (FRT21P5AQ3) C = FRT21P5A (FRT21P5AW3) POS. NO PART NO DESCRIPTION 240514611 A - - Gasket-frzr door,black ,magnetic 240514607 - B C Gasket-frzr door,white ,magnetic 240514612 A - - Gasket-refr door,black ,magnetic 240514608 - B C...
- Page 4 Publication No. FRT21P5A 5995364006 CABINET 01/02...
- Page 5 FRT21P5A Publication No. 5995364006 CABINET A = FRT21P5A (FRT21P5AB3) B = FRT21P5A (FRT21P5AQ3) C = FRT21P5A (FRT21P5AW3) POS. NO PART NO DESCRIPTION 240355402 A B C Cover-fan 240433201 A B C Screw,hex washer head ,8-18 x 0.375 240367001 A B C Knob-damper control 5303001028 A B C...
- Page 6 Publication No. FRT21P5A 5995364006 SHELVES 01/02...
- Page 7 FRT21P5A Publication No. 5995364006 SHELVES A = FRT21P5A (FRT21P5AB3) B = FRT21P5A (FRT21P5AQ3) C = FRT21P5A (FRT21P5AW3) POS. NO PART NO DESCRIPTION 215667501 A B C Tray-ice,plastic 240358003 A B C Shelf-freezer 5303299664 A B C Spacer-shelf 240380202 A B C Diffuser-air,top 240362601 A B C...
- Page 8 Publication No. FRT21P5A 5995364006 SYSTEM 01/02...
- Page 9 FRT21P5A Publication No. 5995364006 SYSTEM A = FRT21P5A (FRT21P5AB3) B = FRT21P5A (FRT21P5AQ3) C = FRT21P5A (FRT21P5AW3) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240388701 A B C Wiring Harness,control box 240496101 A B C Wiring Harness,machine compt...
-
Page 10: Wiring Schematic
Publication No. FRT21P5A 5995364006 WIRING SCHEMATIC 01/02... -
Page 11: Wiring Diagram
FRT21P5A Publication No. 5995364006 WIRING DIAGRAM # = Fast-moving Parts 01/02 * = Non-Illustrated Parts...
