PRODUCT NO.
BASE MODEL NO.
FRT21INLHB3
FRT21INLH
FRT21INLHD3
FRT21INLH
FRT21INLHW3
FRT21INLH
MARKET
North America
WIRING DIAGRAM - #193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a System
almond
R134a System
white
Publication No.
5995332508
000201
-EN/SERVICE/KHB
357
REFRIGERATOR
VOLTS
115
115
115
REFRIGERATOR
Model No.
FRT21INLH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21INLH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21INLH

Summary of Contents for Frigidaire FRT21INLH

  • Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21INLHB3 FRT21INLH R134a System black FRT21INLHD3 FRT21INLH R134a System almond FRT21INLHW3 FRT21INLH R134a System white MARKET North America WIRING DIAGRAM - #193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No.
  • Page 2 Publication No. FRT21INLH 5995332508 DOOR 02/00...
  • Page 3 FRT21INLH Publication No. 5995332508 DOOR A = FRT21INLH (FRT21INLHB3) B = FRT21INLH (FRT21INLHD3) C = FRT21INLH (FRT21INLHW3) POS. NO PART NO DESCRIPTION 215608923 A - - Gasket-frzr door,black ,magnetic 215608913 - B C Gasket-frzr door,white ,magnetic 218730622 A - - Gasket-refr door,black ,magnetic 218730609 - B C...
  • Page 4 Publication No. FRT21INLH 5995332508 CABINET 02/00...
  • Page 5 FRT21INLH Publication No. 5995332508 CABINET A = FRT21INLH (FRT21INLHB3) B = FRT21INLH (FRT21INLHD3) C = FRT21INLH (FRT21INLHW3) POS. NO PART NO DESCRIPTION 5304402655 A B C Cover-fan 5303307351 A B C Knob-damper control 5303001028 A B C Nut,push-on 218722200 A B C Damper-fan cover,black 218649000 A B C...
  • Page 6 Publication No. FRT21INLH 5995332508 SHELVES 02/00...
  • Page 7 FRT21INLH Publication No. 5995332508 SHELVES A = FRT21INLH (FRT21INLHB3) B = FRT21INLH (FRT21INLHD3) C = FRT21INLH (FRT21INLHW3) POS. NO PART NO DESCRIPTION 218651902 A - - Mullion,black 218651901 - B - Mullion,almond 218651900 - - C Mullion,white 218781002 A B C Heater-mullion 218845602 A B C...
  • Page 8 Publication No. FRT21INLH 5995332508 SYSTEM 02/00...
  • Page 9 FRT21INLH Publication No. 5995332508 SYSTEM A = FRT21INLH (FRT21INLHB3) B = FRT21INLH (FRT21INLHD3) C = FRT21INLH (FRT21INLHW3) POS. NO PART NO DESCRIPTION 218657100 A B C Condenser 5304406039 A B C Spacer-tube,5/8 OD x 3" lg 5304406040 A B C Spacer-tube,5/8 OD x 12"...

  • Page 10: Ice Maker

    Publication No. FRT21INLH 5995332508 ICE MAKER 02/00...
  • Page 11 FRT21INLH Publication No. 5995332508 ICE MAKER A = FRT21INLH (FRT21INLHB3) B = FRT21INLH (FRT21INLHD3) C = FRT21INLH (FRT21INLHW3) POS. NO PART NO DESCRIPTION 5303015131 A B C Tube-water,71" ,valve-to-IM 3206348 A B C Spring,shut-off arm 3206299 A B C Label,ID plate 3206301 A B C Gear...

  • Page 12: Wiring Schematic

    Publication No. FRT21INLH 5995332508 WIRING SCHEMATIC 02/00...

  • Page 13: Wiring Diagram

    FRT21INLH Publication No. 5995332508 WIRING DIAGRAM # = Fast-moving Parts 02/00 * = Non-Illustrated Parts...

This manual is also suitable for:

Frt21inlhb3Frt21inlhd3Frt21inlhw3
