Frigidaire FSC23F7D Parts Catalog

Frigidaire FSC23F7D Parts Catalog

Side-by-side refrigerator
Hide thumbs Also See for FSC23F7D:
Table of Contents

Advertisement

Quick Links

Download this manual
E23CS75DSS0.eps N58FCFEFA0.eps N58RCFCHA0.eps N58BABAAD0.eps
N58SEHLBC1.eps N58TBAAAB1.eps N58CAAAAC1.eps N58XEAAAA0.eps
N58YDAAACO.eps N58I115T.eps W241516401A.eps S241516401A.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FSC23F7DB3 FSC23F7DW3
Series
counter depth counter depth
Color
black
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241540301
Market
North America North America
Energy Guide
240598639
Service Data Sheet 241532603
Publication No.
5995435632
05/04/27
(EN/SERVICE/DCS)
357
white
115
241516401A
241540301
240598639
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7D
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSC23F7D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FSC23F7D

Summary of Contents for Frigidaire FSC23F7D

  • Page 1 Product No. FSC23F7DB3 FSC23F7DW3 Series counter depth counter depth Color black white Volts Wiring Diagram 241516401A 241516401A Owner's Guide 241540301 241540301 Market North America North America Energy Guide 240598639 240598639 Service Data Sheet 241532603 241532603 SIDE-BY-SIDE E23CS75DSS0.eps N58FCFEFA0.eps N58RCFCHA0.eps N58BABAAD0.eps REFRIGERATOR N58SEHLBC1.eps N58TBAAAB1.eps N58CAAAAC1.eps N58XEAAAA0.eps N58YDAAACO.eps N58I115T.eps W241516401A.eps S241516401A.eps...

  • Page 2: Freezer Door

    Publication No: 5995435632 FSC23F7D FREEZER DOOR N58FCFEFA0 04/05...
  • Page 3 FSC23F7D Publication No: 5995435632 FREEZER DOOR Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241510202 Gasket-frzr door, white, magnetic 241511602 Bin-door 241545001 Bin-tilt out, tilt-out 240554271 Door-frzr, black, complete assy 240554270 Door-frzr, white, complete assy 240537106...

  • Page 4: Refrigerator Door

    Publication No: 5995435632 FSC23F7D REFRIGERATOR DOOR N58RCFCHA0 04/05...
  • Page 5 FSC23F7D Publication No: 5995435632 REFRIGERATOR DOOR Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241510201 Gasket-refr door, white, magnetic 241516102 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 240449710 Nameplate 240449708 Nameplate 240537105 Door Stop, black, ref 240537101...
  • Page 6 Publication No: 5995435632 FSC23F7D CABINET N58BABAAD0 04/05...
  • Page 7 FSC23F7D Publication No: 5995435632 CABINET Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 241509802 Cover-air duct 240475907 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252200 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240457701...
  • Page 8 Publication No: 5995435632 FSC23F7D SHELVES N58SEHLBC1 04/05...
  • Page 9 FSC23F7D Publication No: 5995435632 SHELVES Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 241510605 Trim-basket 240443357 Shelf-freezer, glass, lower 240443358 Shelf-freezer, glass, upper 241552801 Light Bulb 241507803 Socket-light 16A* 241523201 Harness-wiring 240355240 Shelf-"Spill-Safe", fixed, (3) 240350129 Shelf-"Spill-Safe", cantilever, sliding 240599301...
  • Page 10 Publication No: 5995435632 FSC23F7D CONTROLS N58TBAAAB1 04/05...
  • Page 11 FSC23F7D Publication No: 5995435632 CONTROLS Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509401 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor...
  • Page 12 Publication No: 5995435632 FSC23F7D SYSTEM N58CAAAAC1 04/05...
  • Page 13 FSC23F7D Publication No: 5995435632 SYSTEM Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241516901 Cord-service 241510801 Harness-wiring 241519901 Harness-wiring 241601701 Harness-wiring, machine compt 14 # 240316107 Heater-defrost 15 #...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995435632 FSC23F7D ICE & WATER DISPENSER 04/05...
  • Page 15 FSC23F7D Publication No: 5995435632 ICE & WATER DISPENSER Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976903 Tube-water inlet, inlet valve, to filter 218976911 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 5304422012 Cover-module, black 5304421822...

  • Page 16: Ice Container

    Publication No: 5995435632 FSC23F7D ICE CONTAINER 37A 34 34 33 N58YDAAAC0 04/05...
  • Page 17 FSC23F7D Publication No: 5995435632 ICE CONTAINER Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 5304436634 Auger-ice 5304404343 Cam-drive 241515201 Container-ice, bucket only 5304404346 Drum-ice disp 241515301 Front-ice container 241624801 Bar-drive 5304404359 Gate 241555401 Light Bulb 241559801 Socket-light 5304404345...

  • Page 18: Ice Maker

    Publication No: 5995435632 FSC23F7D ICE MAKER INSTALLATION PARTS N58I115T 04/05...
  • Page 19 FSC23F7D Publication No: 5995435632 ICE MAKER Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube-water inlet, inlet valve, to ice maker 218976903 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 241604801...
  • Page 20 Publication No: 5995435632 FSC23F7D ICE MAKER INSTALLATION PARTS N58I115T 04/05...
  • Page 21 FSC23F7D Publication No: 5995435632 ICE MAKER Model Index: A FSC23F7D (FSC23F7DB3) B FSC23F7D (FSC23F7DW3) POS. NO PART NO. DESCRIPTION 240542901 Cap-water valve 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5303001549 Clamp, 0.31 ID, steel, copper wtr line 5304436611 Bracket-ice maker 5304436612 Switch, on/off...

  • Page 22: Wiring Schematic

    Publication No: 5995435632 FSC23F7D WIRING SCHEMATIC 04/05...

  • Page 23: Wiring Diagram

    FSC23F7D Publication No: 5995435632 WIRING DIAGRAM 04/05 # Functional Parts * Non-Illustrated Parts...
