E23CS75DSS0.eps N58FCFEFA1.eps N58RCFCHA5.eps N58BABAAD5.eps
N58SEHLBC13.eps N58TBAAAB4.eps N58CAAAAC10.eps N58XEAAAA1.eps
N58YDAAAC4.eps N58I115TServo.eps W241516401A.eps S241516401A.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FSC23F7HB7 FSC23F7HW7 FSC23F7HSB7 FSC23F7HSB9
Series
counter depth counter depth counter depth
Color
black
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241857500
Market
North America North America North America North America
Energy Guide
241615434
Service Data Sheet 241532603
Publication No.
(EN/SERVICE/KHB)
white
stain/blk
115
115
241516401A
241516401A
241857500
241857500
241615434
241615435
241532603
241532603
5995514337
08/05/15
137
Copyright
counter depth
stain/blk
115
241516401A
241857500
241615435
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7H
©
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FSC23F7H
Summary of Contents for Frigidaire FSC23F7H
- Page 1 Product No. FSC23F7HB7 FSC23F7HW7 FSC23F7HSB7 FSC23F7HSB9 Series counter depth counter depth counter depth counter depth Color black white stain/blk stain/blk Volts Wiring Diagram 241516401A 241516401A 241516401A 241516401A Owner's Guide 241857500 241857500 241857500 241857500 Market North America North America North America North America Energy Guide 241615434 241615434...
-
Page 2: Freezer Door
Publication No: 5995514337 FSC23F7H FREEZER DOOR Stainless Handle N58FCFEFA1 05/08... - Page 3 FSC23F7H Publication No: 5995514337 FREEZER DOOR Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 241510204 A - C D Gasket-frzr door, black, magnetic 241510202 - B - - Gasket-frzr door, white, magnetic 241511602 A B C D Bin-door...
-
Page 4: Refrigerator Door
Publication No: 5995514337 FSC23F7H REFRIGERATOR DOOR Stainless Handle N58RCFCHA5 05/08... - Page 5 FSC23F7H Publication No: 5995514337 REFRIGERATOR DOOR Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 241510203 A - C D Gasket-refr door, black, magnetic 241510201 - B - - Gasket-refr door, white, magnetic 241516102 A B C D Rack-can...
- Page 6 Publication No: 5995514337 FSC23F7H CABINET N58BABAAD5 05/08...
- Page 7 FSC23F7H Publication No: 5995514337 CABINET Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 241509804 A B C D Cover-air duct 241719711 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 241547901...
- Page 8 Publication No: 5995514337 FSC23F7H SHELVES N58SEHLBC13 05/08...
- Page 9 FSC23F7H Publication No: 5995514337 SHELVES Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 241510605 A B C D Trim-basket 240443357 A B C D Shelf-freezer, glass, lower 240443358 A B C D Shelf-freezer, glass, upper 241552801 A B C D...
- Page 10 Publication No: 5995514337 FSC23F7H CONTROLS N58TBAAAB4 05/08...
- Page 11 FSC23F7H Publication No: 5995514337 CONTROLS Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241518301 A B C D Bushing, motor mounting...
- Page 12 Publication No: 5995514337 FSC23F7H SYSTEM N58CAAAAC10 05/08...
- Page 13 FSC23F7H Publication No: 5995514337 SYSTEM Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 240333605 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241516901...
-
Page 14: Ice And Water Dispenser
Publication No: 5995514337 FSC23F7H ICE & WATER DISPENSER N58XEAAAA1 05/08... - Page 15 FSC23F7H Publication No: 5995514337 ICE & WATER DISPENSER Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976421 A B C D...
-
Page 16: Ice Container
Publication No: 5995514337 FSC23F7H ICE CONTAINER 37A 34 34 33 N58YDAAAC4 05/08... - Page 17 FSC23F7H Publication No: 5995514337 ICE CONTAINER Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 241684701 A B C D Auger-ice 241685201 A B C D Cam-drive 241515202 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995514337 FSC23F7H ICE MAKER INSTALLATION PARTS N58I115TServo 05/08... - Page 19 FSC23F7H Publication No: 5995514337 ICE MAKER Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976421 A B C D Tube-water inlet, valve to door...
- Page 20 Publication No: 5995514337 FSC23F7H ICE MAKER INSTALLATION PARTS N58I115TServo 05/08...
- Page 21 FSC23F7H Publication No: 5995514337 ICE MAKER Model Index: A FSC23F7H (FSC23F7HB7) B FSC23F7H (FSC23F7HW7) C FSC23F7H (FSC23F7HSB7) D FSC23F7H (FSC23F7HSB9) POS. NO PART NO. DESCRIPTION 240363602 A B C D Screw-shoulder 240542901 A B C D Cap-water valve 5304455651 A B C D Screw, hex washer head, 8-15A x 0.500 5304455846 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995514337 FSC23F7H WIRING SCHEMATIC 05/08... -
Page 23: Wiring Diagram
FSC23F7H Publication No: 5995514337 WIRING DIAGRAM 05/08 # Functional Parts * Non-Illustrated Parts...
