E23CS75DSS0.eps N58FCFEFA1.eps N58RCFCHA6.eps N58BABAAD3.eps
N58SEHLBC11.eps N58TBAAAB2.eps N58CAAAAC1.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FSC23F7DB6 FSC23F7DW6 FSC23F7DSB8
Series
counter depth counter depth counter depth
Color
black
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241694601
Market
North America North America North America
Energy Guide
241585639
Service Data Sheet 241532603
Publication No.
5995466165
06/05/10
(EN/SERVICE/WC)
137
white
stainless
115
115
241516401A
241516401A
241694601
241694601
241585639
241585639
241532603
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7D
©
Copyright
2006 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FSC23F7D
Summary of Contents for Frigidaire FSC23F7D
- Page 1 Product No. FSC23F7DB6 FSC23F7DW6 FSC23F7DSB8 Series counter depth counter depth counter depth Color black white stainless Volts Wiring Diagram 241516401A 241516401A 241516401A Owner's Guide 241694601 241694601 241694601 Market North America North America North America Energy Guide 241585639 241585639 241585639 Service Data Sheet 241532603 241532603 241532603 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995466165 FSC23F7D FREEZER DOOR Stainless Handle N58FCFEFA1 05/06... - Page 3 FSC23F7D Publication No: 5995466165 FREEZER DOOR Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 241510204 A - C Gasket-frzr door, black, magnetic 241510202 - B - Gasket-frzr door, white, magnetic 241511602 A B C Bin-door 241545001 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995466165 FSC23F7D REFRIGERATOR DOOR Stainless Handle N58RCFCHA6 05/06... - Page 5 FSC23F7D Publication No: 5995466165 REFRIGERATOR DOOR Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 241510203 A - C Gasket-refr door, black, magnetic 241510201 - B - Gasket-refr door, white, magnetic 241516102 A B C Rack-can 241515901 A B C...
- Page 6 Publication No: 5995466165 FSC23F7D CABINET N58BABAAD3 05/06...
- Page 7 FSC23F7D Publication No: 5995466165 CABINET Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 241509802 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 241547901 A B C Switch-light/lamp, frzr door...
- Page 8 Publication No: 5995466165 FSC23F7D SHELVES N58SEHLBC11 05/06...
- Page 9 FSC23F7D Publication No: 5995466165 SHELVES Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 241510605 A B C Trim-basket 240443357 A B C Shelf-freezer, glass, lower 240443358 A B C Shelf-freezer, glass, upper 241552801 A B C Light Bulb...
- Page 10 Publication No: 5995466165 FSC23F7D CONTROLS N58TBAAAB2 05/06...
- Page 11 FSC23F7D Publication No: 5995466165 CONTROLS Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241518301 A B C Bushing, motor mounting...
- Page 12 Publication No: 5995466165 FSC23F7D SYSTEM N58CAAAAC1 05/06...
- Page 13 FSC23F7D Publication No: 5995466165 SYSTEM Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241516901 A B C Cord-service...
-
Page 14: Ice And Water Dispenser
Publication No: 5995466165 FSC23F7D ICE & WATER DISPENSER 05/06... - Page 15 FSC23F7D Publication No: 5995466165 ICE & WATER DISPENSER Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995466165 FSC23F7D ICE CONTAINER 37A 34 34 33 N58YDAAAC0 05/06... - Page 17 FSC23F7D Publication No: 5995466165 ICE CONTAINER Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 5304436634 A B C Auger-ice 5304404343 A B C Cam-drive 241515201 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241515301...
-
Page 18: Ice Maker
Publication No: 5995466165 FSC23F7D ICE MAKER 05/06... - Page 19 FSC23F7D Publication No: 5995466165 ICE MAKER Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976917 A B C...
- Page 20 Publication No: 5995466165 FSC23F7D ICE MAKER 05/06...
- Page 21 FSC23F7D Publication No: 5995466165 ICE MAKER Model Index: A FSC23F7D (FSC23F7DB6) B FSC23F7D (FSC23F7DW6) C FSC23F7D (FSC23F7DSB8) POS. NO PART NO. DESCRIPTION 240363601 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line...
-
Page 22: Wiring Schematic
Publication No: 5995466165 FSC23F7D WIRING SCHEMATIC 05/06... -
Page 23: Wiring Diagram
FSC23F7D Publication No: 5995466165 WIRING DIAGRAM 05/06 # Functional Parts * Non-Illustrated Parts...
