Frigidaire FSC23F7DS Factory Parts Catalog

Frigidaire FSC23F7DS Factory Parts Catalog

Counter depth series
Hide thumbs Also See for FSC23F7DS:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
E23CS75DSS0.eps N58FFDCFA0.eps N58RFDCIA0.eps N58BABAAD3.eps
N58SEHLBC11.eps N58TBAAAB2.eps N58CAAAAC1.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FSC23F7DSBN
Series
counter depth
Color
stain/blk
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241540601
Market
North America
Energy Guide
241585916
Service Data Sheet 241532603
Publication No.
5995441424
05/07/12
(EN/SERVICE/KHB)
357
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7DS
©
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSC23F7DS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FSC23F7DS

Summary of Contents for Frigidaire FSC23F7DS

  • Page 1 Product No. FSC23F7DSBN Series counter depth Color stain/blk Volts Wiring Diagram 241516401A Owner's Guide 241540601 Market North America Energy Guide 241585916 Service Data Sheet 241532603 SIDE-BY-SIDE E23CS75DSS0.eps N58FFDCFA0.eps N58RFDCIA0.eps N58BABAAD3.eps REFRIGERATOR N58SEHLBC11.eps N58TBAAAB2.eps N58CAAAAC1.eps N58XEAAAA0.eps N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps Model No. North &...

  • Page 2: Freezer Door

    Publication No: 5995441424 FSC23F7DSBN FREEZER DOOR N58FFDCFA0 07/05...
  • Page 3 FSC23F7DSBN Publication No: 5995441424 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241511602 Bin-door 241545001 Bin-tilt out, tilt-out 240554279 Door-frzr, stainless, complete assy 240581906 Door Stop, black, frzr 240536801 Handle-door, stainless steel, with insert 240598401 Screw, 10-32 x 1/2 240328204 Bearing-hinge(frz), black, closer 240328404...

  • Page 4: Refrigerator Door

    Publication No: 5995441424 FSC23F7DSBN REFRIGERATOR DOOR N58RFDCIA0 07/05...
  • Page 5 FSC23F7DSBN Publication No: 5995441424 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241516102 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 240449710 Nameplate 240581905 Door Stop, black, ref 241534509 Door-refr, stainless, complete assy 240536801 Handle-door, stainless steel, with insert 240598401 Screw, 10-32 x 1/2 240328203...
  • Page 6 Publication No: 5995441424 FSC23F7DSBN CABINET N58BABAAD3 07/05...
  • Page 7 FSC23F7DSBN Publication No: 5995441424 CABINET POS. NO PART NO. DESCRIPTION 241509802 Cover-air duct 240475907 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252200 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special 241603701...
  • Page 8 Publication No: 5995441424 FSC23F7DSBN SHELVES N58SEHLBC11 07/05...
  • Page 9 FSC23F7DSBN Publication No: 5995441424 SHELVES POS. NO PART NO. DESCRIPTION 241510605 Trim-basket 240443357 Shelf-freezer, glass, lower 240443358 Shelf-freezer, glass, upper 241552801 Light Bulb 241622802 Socket-light 16A* 241523201 Harness-wiring 240355240 Shelf-"Spill-Safe", fixed, (3) 240350129 Shelf-"Spill-Safe", cantilever, sliding 240599301 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240350902...
  • Page 10 Publication No: 5995441424 FSC23F7DSBN CONTROLS N58TBAAAB2 07/05...
  • Page 11 FSC23F7DSBN Publication No: 5995441424 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509401 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor 241552801 Light Bulb 241507803 Socket-light 241516201...
  • Page 12 Publication No: 5995441424 FSC23F7DSBN SYSTEM N58CAAAAC1 07/05...
  • Page 13 FSC23F7DSBN Publication No: 5995441424 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241516901 Cord-service 241510801 Harness-wiring 241519901 Harness-wiring 241635601 Harness-wiring, machine compt 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2) 5303918214...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995441424 FSC23F7DSBN ICE & WATER DISPENSER 07/05...
  • Page 15 FSC23F7DSBN Publication No: 5995441424 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube-water inlet, inlet valve, to ice maker 218976903 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304422012 Cover-module, black 5304424549...

  • Page 16: Ice Container

    Publication No: 5995441424 FSC23F7DSBN ICE CONTAINER 37A 34 34 33 N58YDAAAC0 07/05...
  • Page 17 FSC23F7DSBN Publication No: 5995441424 ICE CONTAINER POS. NO PART NO. DESCRIPTION 5304436634 Auger-ice 5304404343 Cam-drive 241515201 Container-ice, bucket only 5304404346 Drum-ice disp 241515301 Front-ice container 241624801 Bar-drive 5304404359 Gate 241555401 Light Bulb 241559801 Socket-light 5304404345 Drive Blade 18 # 5304440392 Motor-auger 241522901 Harness-wiring, icmkr/container...

  • Page 18: Ice Maker

    Publication No: 5995441424 FSC23F7DSBN ICE MAKER INSTALLATION PARTS N58I115T 07/05...
  • Page 19 FSC23F7DSBN Publication No: 5995441424 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube-water inlet, inlet valve, to ice maker 218976903 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304436616 Spring, torsion 3206301...

  • Page 20: Wiring Schematic

    Publication No: 5995441424 FSC23F7DSBN WIRING SCHEMATIC 07/05...

  • Page 21: Wiring Diagram

    FSC23F7DSBN Publication No: 5995441424 WIRING DIAGRAM 07/05 # Functional Parts * Non-Illustrated Parts...
