ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FSC23F7DB1 FSC23F7DB2
Series
counter depth counter depth
Color
black
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241540301
Market
North America North America
Energy Guide
240598639
Service Data Sheet 241532603
Publication No.
5995426854
05/01/18
(EN/SERVICE/KHB)
357
black
115
241516401A
241540301
240598639
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7D
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FSC23F7D
Summary of Contents for Frigidaire FSC23F7D
- Page 1 Product No. FSC23F7DB1 FSC23F7DB2 Series counter depth counter depth Color black black Volts Wiring Diagram 241516401A 241516401A Owner's Guide 241540301 241540301 Market North America North America Energy Guide 240598639 240598639 Service Data Sheet 241532603 241532603 SIDE-BY-SIDE E23CS75DSS0.eps N58FCFEFA0.eps N58RCFCHA0.eps N58BABAAD0.eps REFRIGERATOR N58SEDLBC11.eps N58TBAAAB1.eps N58CAAAAC0.eps N58XEAAAA0.eps N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps...
-
Page 2: Freezer Door
Publication No: 5995426854 FSC23F7D FREEZER DOOR N58FCFEFA0 01/05... - Page 3 FSC23F7D Publication No: 5995426854 FREEZER DOOR Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241511602 Bin-door 241545001 Bin-tilt out, tilt-out 240554271 Door-frzr, black, complete assy 240537106 Door Stop, black, frzr 240359108 Handle-door, black, LH 218781100...
-
Page 4: Refrigerator Door
Publication No: 5995426854 FSC23F7D REFRIGERATOR DOOR N58RCFCHA0 01/05... - Page 5 FSC23F7D Publication No: 5995426854 REFRIGERATOR DOOR Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241516102 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 240449710 Nameplate 240537105 Door Stop, black, ref 241534505 Door-refr, complete assy 240359103 Handle-door, black, RH 218781100...
- Page 6 Publication No: 5995426854 FSC23F7D CABINET N58BABAAD0 01/05...
- Page 7 FSC23F7D Publication No: 5995426854 CABINET Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 241509802 Cover-air duct 240475907 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252200 Screw, #8 truss hd, 10-32CA x 0.500 240457701 Plate-door closer 240457702...
- Page 8 Publication No: 5995426854 FSC23F7D SHELVES N58SEDLBC11 01/05...
- Page 9 FSC23F7D Publication No: 5995426854 SHELVES Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 241510605 Trim-basket 240443357 Shelf-freezer, glass, lower 240443358 Shelf-freezer, glass, upper 241552801 Light Bulb 241507803 Socket-light 16A* 241523201 Harness-wiring 240355240 Shelf-"Spill-Safe", fixed, (3) 240350129 Shelf-"Spill-Safe", cantilever, sliding 240599301...
- Page 10 Publication No: 5995426854 FSC23F7D CONTROLS N58TBAAAB1 01/05...
- Page 11 FSC23F7D Publication No: 5995426854 CONTROLS Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509401 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor...
- Page 12 Publication No: 5995426854 FSC23F7D SYSTEM 01/05...
- Page 13 FSC23F7D Publication No: 5995426854 SYSTEM Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241543701 Harness-wiring, machine compt 241601701 Harness-wiring, machine compt 6* # 241516901 Cord-service 241510801 Harness-wiring...
-
Page 14: Ice And Water Dispenser
Publication No: 5995426854 FSC23F7D ICE & WATER DISPENSER 01/05... - Page 15 FSC23F7D Publication No: 5995426854 ICE & WATER DISPENSER Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976903 Tube-water inlet, inlet valve, to filter 218976911 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304422012...
-
Page 16: Ice Container
Publication No: 5995426854 FSC23F7D ICE CONTAINER 37A 34 34 33 N58YDAAAC0 01/05... - Page 17 FSC23F7D Publication No: 5995426854 ICE CONTAINER Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 5304436634 Auger-ice 5304404343 Cam-drive 241515201 Container-ice, bucket only 5304404346 Drum-ice disp 241515301 Front-ice container 5304404337 Bar-drive 5304404359 Gate 241555401 Light Bulb 241559801 Socket-light 5304404345...
-
Page 18: Ice Maker
Publication No: 5995426854 FSC23F7D ICE MAKER INSTALLATION PARTS N58I115T 01/05... - Page 19 FSC23F7D Publication No: 5995426854 ICE MAKER Model Index: A FSC23F7D (FSC23F7DB1) B FSC23F7D (FSC23F7DB2) POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976903 Tube-water inlet, inlet valve, to filter 218976911 Tube-water inlet, inlet valve, to filter 218976912 Tube-water inlet, valve to door 241604801 Seal-water inlet, inlet valve, to ice maker 5304436616...
-
Page 20: Wiring Schematic
Publication No: 5995426854 FSC23F7D WIRING SCHEMATIC 01/05... -
Page 21: Wiring Diagram
FSC23F7D Publication No: 5995426854 WIRING DIAGRAM 01/05 # Functional Parts * Non-Illustrated Parts...
