Frigidaire FSC23F7DS Factory Parts Catalog
Counter depth series
Hide thumbs
Also See for FSC23F7DS:
- Factory parts catalog (22 pages) ,
- Factory parts catalog (22 pages)
Table of Contents
Advertisement
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 241532603
E23CS75DSS0.eps N58FFDCFA0.eps N58RFDCIA0.eps N58BABAAD0.eps
N58SEDLBC12.eps N58TBAAAB1.eps N58CAAAAC0.eps N58XEAAAA0.eps
N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FSC23F7DSB2 FSC23F7DSB3 FSC23F7DSB4 FSC23F7DSB5 FSC23F7DSB7
counter depth
counter depth
counter depth
stain/blk
stain/blk
stain/blk
115
115
115
241516401A
241516401A
241516401A
241540301
241540301
241540301
North America North America North America North America North America
241585916
241585916
241585916
241532603
241532603
Publication No.
5995427050
05/01/19
(EN/SERVICE/KHB)
357
counter depth
counter depth
stain/blk
stain/blk
115
115
241516401A
241516401A
241540301
241540301
241585916
241585916
241532603
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7DS
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.
Advertisement
Table of Contents
Related Manuals for Frigidaire FSC23F7DS
Summary of Contents for Frigidaire FSC23F7DS
- Page 1 Product No. FSC23F7DSB2 FSC23F7DSB3 FSC23F7DSB4 FSC23F7DSB5 FSC23F7DSB7 Series counter depth counter depth counter depth counter depth counter depth Color stain/blk stain/blk stain/blk stain/blk stain/blk Volts Wiring Diagram 241516401A 241516401A 241516401A 241516401A 241516401A Owner's Guide 241540301 241540301 241540301 241540301 241540301 Market North America North America North America North America North America Energy Guide 241585916...
-
Page 2: Freezer Door
Publication No: 5995427050 FSC23F7DS FREEZER DOOR N58FFDCFA0 01/05... - Page 3 FSC23F7DS Publication No: 5995427050 FREEZER DOOR Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 241510204 A B C D E Gasket-frzr door, black, magnetic 241511602 A B C D E Bin-door 241545001 A B C D E...
-
Page 4: Refrigerator Door
Publication No: 5995427050 FSC23F7DS REFRIGERATOR DOOR N58RFDCIA0 01/05... - Page 5 FSC23F7DS Publication No: 5995427050 REFRIGERATOR DOOR Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 241510203 A B C D E Gasket-refr door, black, magnetic 241516102 A B C D E Rack-can 241515901 A B C D E...
- Page 6 Publication No: 5995427050 FSC23F7DS CABINET N58BABAAD0 01/05...
- Page 7 FSC23F7DS Publication No: 5995427050 CABINET Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 241509802 A B C D E Cover-air duct 240475907 A B C D E Cover-evap coil, lower 5303208309 A B C D E...
- Page 8 Publication No: 5995427050 FSC23F7DS SHELVES N58SEDLBC12 01/05...
- Page 9 FSC23F7DS Publication No: 5995427050 SHELVES Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 241510605 A B C D E Trim-basket 240443357 A B C D E Shelf-freezer, glass, lower 240443358 A B C D E...
- Page 10 Publication No: 5995427050 FSC23F7DS CONTROLS N58TBAAAB1 01/05...
- Page 11 FSC23F7DS Publication No: 5995427050 CONTROLS Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E Fan Blade, red, evaporator fan 215474201 A B C D E Washer, "slinger", nylon, evap fan shaft 241518301 A B C D E...
- Page 12 Publication No: 5995427050 FSC23F7DS SYSTEM 01/05...
- Page 13 FSC23F7DS Publication No: 5995427050 SYSTEM Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 240333603 A B C D E Condenser 218679607 A B C D E Block-evap coil, styrofoam, (2) 218944001 A B C D E...
-
Page 14: Ice And Water Dispenser
Publication No: 5995427050 FSC23F7DS ICE & WATER DISPENSER 01/05... - Page 15 FSC23F7DS Publication No: 5995427050 ICE & WATER DISPENSER Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube-water-DOOR 218976903 A B C D E Tube-water inlet, inlet valve, to filter 218976911 A B C D E...
-
Page 16: Ice Container
Publication No: 5995427050 FSC23F7DS ICE CONTAINER 37A 34 34 33 N58YDAAAC0 01/05... - Page 17 FSC23F7DS Publication No: 5995427050 ICE CONTAINER Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 5304436634 A B C D E Auger-ice 5304404343 A B C D E Cam-drive 241515201 A B C D E...
-
Page 18: Ice Maker
Publication No: 5995427050 FSC23F7DS ICE MAKER INSTALLATION PARTS N58I115T 01/05... - Page 19 FSC23F7DS Publication No: 5995427050 ICE MAKER Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube-water-DOOR 218976903 A B C D E Tube-water inlet, inlet valve, to filter 218976911 A B C D E...
- Page 20 Publication No: 5995427050 FSC23F7DS ICE MAKER INSTALLATION PARTS N58I115T 01/05...
- Page 21 FSC23F7DS Publication No: 5995427050 ICE MAKER Model Index: A FSC23F7DS (FSC23F7DSB2) B FSC23F7DS (FSC23F7DSB3) C FSC23F7DS (FSC23F7DSB4) D FSC23F7DS (FSC23F7DSB5) E FSC23F7DS (FSC23F7DSB7) POS. NO PART NO. DESCRIPTION 240363601 A B C D E Screw-shoulder 240542901 A B C D E Cap-water valve 5303001343 A B C D E...
-
Page 22: Wiring Schematic
Publication No: 5995427050 FSC23F7DS WIRING SCHEMATIC 01/05... -
Page 23: Wiring Diagram
FSC23F7DS Publication No: 5995427050 WIRING DIAGRAM 01/05 # Functional Parts * Non-Illustrated Parts...
