Frigidaire FSC23F7TD Factory Parts Catalog

Counter depth series

Hide thumbs Also See for FSC23F7TD:

Factory parts catalog (24 pages)

Factory parts catalog (22 pages)

page of 23

/ 23
Bookmarks

Quick Links

Download this manual

E23CS75DSS0.eps N58FKGCFA0.eps N58RKGCHB0.eps N58BABAAD1.eps

N58SEDLBC13.eps N58TBAAAB1.eps N58CAAAAC1.eps N58XEBAAA1.eps

N58YDAAAC0.eps N58I115T.eps W241516401A.eps S241516401A.eps

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378

Augusta, GA 30917

Product No.

FSC23F7TDB3 FSC23F7TDS3 FSC23F7TDW3

Series

counter depth

Color

black

Volts

115

Wiring Diagram

241516401A

Owner's Guide

241540301

Market

North America North America North America

Energy Guide

241585919

Service Data Sheet 241532603

Publication No.

5995430583

05/03/03

(EN/SERVICE/DCS)

357

counter depth

stainless

white

115

241516401A

241540301

241585919

241532603

SIDE-BY-SIDE

REFRIGERATOR

Model No.

FSC23F7TD

Need help?

Do you have a question about the FSC23F7TD and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FSC23F7TD

Page 1 Product No. FSC23F7TDB3 FSC23F7TDS3 FSC23F7TDW3 Series counter depth counter depth counter depth Color black stainless white Volts Wiring Diagram 241516401A 241516401A 241516401A Owner's Guide 241540301 241540301 241540301 Market North America North America North America Energy Guide 241585919 241585919 241585919 Service Data Sheet 241532603 241532603 241532603 SIDE-BY-SIDE...
Page 2 Publication No: 5995430583 FSC23F7TD FREEZER DOOR N58FKGCFA0 03/05...
Page 3 FSC23F7TD Publication No: 5995430583 FREEZER DOOR Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 241510204 A B - Gasket-frzr door, black, magnetic 241510202 - - C Gasket-frzr door, white, magnetic 241511602 A B C Bin-door 241545001 A B C...
Page 4 Publication No: 5995430583 FSC23F7TD REFRIGERATOR DOOR N58RKGCHB0 03/05...
Page 5 FSC23F7TD Publication No: 5995430583 REFRIGERATOR DOOR Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 241510203 A B - Gasket-refr door, black, magnetic 241510201 - - C Gasket-refr door, white, magnetic 241516102 A B C Rack-can 241515901 A B C...
Page 6 Publication No: 5995430583 FSC23F7TD CABINET N58BABAAD1 03/05...
Page 7 FSC23F7TD Publication No: 5995430583 CABINET Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 241509802 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 241547901 A B C Switch-light/lamp, frzr door...
Page 8 Publication No: 5995430583 FSC23F7TD SHELVES N58SEDLBC13 03/05...
Page 9 FSC23F7TD Publication No: 5995430583 SHELVES Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 241510605 A B C Trim-basket 240443357 A B C Shelf-freezer, glass, lower 240443358 A B C Shelf-freezer, glass, upper 241552801 A B C Light Bulb...
Page 10 Publication No: 5995430583 FSC23F7TD CONTROLS N58TBAAAB1 03/05...
Page 11 FSC23F7TD Publication No: 5995430583 CONTROLS Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241518301 A B C Bushing, motor mounting...
Page 12 Publication No: 5995430583 FSC23F7TD SYSTEM N58CAAAAC1 03/05...
Page 13 FSC23F7TD Publication No: 5995430583 SYSTEM Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241516901 A B C Cord-service...
Page 14 Publication No: 5995430583 FSC23F7TD ICE & WATER DISPENSER N58XEBAAA1 03/05...
Page 15 FSC23F7TD Publication No: 5995430583 ICE & WATER DISPENSER Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976903 A B C Tube-water inlet, inlet valve, to filter 218976911 A B C Tube-water inlet, inlet valve, to filter 218976912...
Page 16 Publication No: 5995430583 FSC23F7TD ICE CONTAINER 37A 34 34 33 N58YDAAAC0 03/05...
Page 17 FSC23F7TD Publication No: 5995430583 ICE CONTAINER Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 5304436634 A B C Auger-ice 5304404343 A B C Cam-drive 241515201 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241515301...
Page 18 Publication No: 5995430583 FSC23F7TD ICE MAKER INSTALLATION PARTS N58I115T 03/05...
Page 19 FSC23F7TD Publication No: 5995430583 ICE MAKER Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976912 A B C...
Page 20 Publication No: 5995430583 FSC23F7TD ICE MAKER INSTALLATION PARTS N58I115T 03/05...
Page 21 FSC23F7TD Publication No: 5995430583 ICE MAKER Model Index: A FSC23F7TD (FSC23F7TDB3) B FSC23F7TD (FSC23F7TDS3) C FSC23F7TD (FSC23F7TDW3) POS. NO PART NO. DESCRIPTION 240542901 A B C Cap-water valve 5303001343 A B C Screw, hex washer head, 8-15A x 0.500 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line 5304436611...
Page 22 Publication No: 5995430583 FSC23F7TD WIRING SCHEMATIC 03/05...
Page 23 FSC23F7TD Publication No: 5995430583 WIRING DIAGRAM 03/05 # Functional Parts * Non-Illustrated Parts...
