Frigidaire FRS22ZGH Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS22ZGH:

Advertisement

Table of Contents

PRODUCT NO.
BASE MODEL NO.
FRS22ZGHB0
FRS22ZGH
FRS22ZGHD0
FRS22ZGH
FRS22ZGHW0
FRS22ZGH
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218908400
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995324265
990603
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS22ZGH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS22ZGH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS22ZGH

Summary of Contents for Frigidaire FRS22ZGH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS22ZGHB0 FRS22ZGH R134a black FRS22ZGHD0 FRS22ZGH R134a almond FRS22ZGHW0 FRS22ZGH R134a white MARKET North America WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218908400 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS22ZGH 5995324265 FREEZER DOOR 06/99...
  • Page 3 FRS22ZGH Publication No. 5995324265 FREEZER DOOR A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C Gasket-frzr door,white ,magnetic 5303288950 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS22ZGH 5995324265 REFRIGERATOR DOOR 06/99...
  • Page 5 FRS22ZGH Publication No. 5995324265 REFRIGERATOR DOOR A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215390401 A B C...
  • Page 6 Publication No. FRS22ZGH 5995324265 CABINET 06/99...
  • Page 7 FRS22ZGH Publication No. 5995324265 CABINET A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 5308009617 A B C Washer,ext tooth lock ,#10 ,grounding 215637401 A B C Cover-evap coil,lower 5303208309 A B C...
  • Page 8 Publication No. FRS22ZGH 5995324265 SHELVES 06/99...
  • Page 9 FRS22ZGH Publication No. 5995324265 SHELVES A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298001 A B C Shelf-freezer,sliding ,wire 218298002 A B C Shelf-freezer,sliding ,wire 218815501 A B C Shelf-pizza,24B 215406135...
  • Page 10 Publication No. FRS22ZGH 5995324265 CONTROLS 06/99...
  • Page 11 FRS22ZGH Publication No. 5995324265 CONTROLS A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS22ZGH 5995324265 SYSTEM 06/99...
  • Page 13 FRS22ZGH Publication No. 5995324265 SYSTEM A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 218787800 A B C Condenser 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C Block-evap coil,styrofoam ,(2) 218541000 A B C...
  • Page 14 Publication No. FRS22ZGH 5995324265 DISPENSER 06/99...
  • Page 15 FRS22ZGH Publication No. 5995324265 DISPENSER A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet, 93", plastic, cut-to-size 215294101 A B C Tube-water inlet, formed, plastic, dispenser 218832301 A B C Tube-water inlet,inlet valve ,to filter...

  • Page 16: Ice Container

    Publication No. FRS22ZGH 5995324265 ICE CONTAINER 06/99...
  • Page 17 FRS22ZGH Publication No. 5995324265 ICE CONTAINER A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS22ZGH 5995324265 ICE MAKER 06/99...
  • Page 19 FRS22ZGH Publication No. 5995324265 ICE MAKER A = FRS22ZGH (FRS22ZGHB0) B = FRS22ZGH (FRS22ZGHD0) C = FRS22ZGH (FRS22ZGHW0) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet, 93", plastic, cut-to-size 215294101 A B C Tube-water inlet, formed, plastic, dispenser 218832301 A B C Tube-water inlet,inlet valve ,to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS22ZGH 5995324265 WIRING SCHEMATIC 06/99...

  • Page 21: Wiring Diagram

    FRS22ZGH Publication No. 5995324265 WIRING DIAGRAM # = Fast-moving Parts 06/99 * = Non-Illustrated Parts...

This manual is also suitable for:

Frs22zghb0Frs22zghd0Frs22zghw0

Table of Contents
