PRODUCT NO.
FRS20ZSGB0
FRS20ZSGB1
WIRING DIAGRAM - # 218682800
OWNER'S GUIDE - # 218854500
SERVICE DATA SHEET - # 218789700
101 Masters Blvd.
Anderson, SC 29624
BASE MODEL NO.
SERIES
FRS20ZSG
R134a
FRS20ZSG
R134a
Publication No.
5995308599
-EN/SERVICE /JLT
FACTORY PARTS CATALOG
REFRIGERATOR
COLOR
stainlessw/blk
stainlessw/blk
980612
357
©1998 White Consolidated Industries, Inc.
All rights reserved

SIDE BY SIDE

VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZSGB0
FRS20ZSGB1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS22ZRG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS22ZRG

Summary of Contents for Frigidaire FRS22ZRG

  • Page 1: Side By Side

    FRS20ZSG FRS20ZSGB1 FRS20ZSG WIRING DIAGRAM - # 218682800 OWNER’S GUIDE - # 218854500 SERVICE DATA SHEET - # 218789700 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR R134a stainlessw/blk R134a stainlessw/blk SIDE BY SIDE REFRIGERATOR FRS20ZSGB0 FRS20ZSGB1 Publication No.

  • Page 2: Freezer Door

    Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 FREEZER DOOR 06/98...
  • Page 3 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 FREEZER DOOR PART NO DESCRIPTION 215734321 Gasket-frzr door,black ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 5303320231 Rack-door 215474047 Rack-door...

  • Page 4: Refrigerator Door

    Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 REFRIGERATOR DOOR 06/98...
  • Page 5 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 REFRIGERATOR DOOR PART NO DESCRIPTION 215734322 Gasket-refr door,black ,magnetic 218749301 Panel-inner door,refr 5303320230 Rack-door 5303288950 Support-door rack,RH/LH 5303308347 Door-dairy 218395401 Nameplate,black...
  • Page 6 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 CABINET 06/98...
  • Page 7 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 CABINET PART NO DESCRIPTION 218748901 Cover-air duct 5303209814 Nut,"U" type ,8-15(A) ,fan mtr mtg 218751301 Cover-evap coil,lower 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55"...
  • Page 8 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 SHELVES 06/98...
  • Page 9 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 11B* 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 SHELVES PART NO DESCRIPTION 218747101 Handle-frzr basket 218298005 Shelf-freezer,sliding ,wire 5303288963 Shelf-freezer,fixed wire 218159700 Spacer-shelf 218746001 Shelf-"Spill-Safe",sliding ,(3) 218015301 Trim-storage pan cvr,snap-on ,front 218015401...
  • Page 10 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 CONTROLS 06/98...
  • Page 11 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 13 # 16 # 17A* 21 # 23 # 114# 115# 125# 137# 141# 141# # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 CONTROLS PART NO DESCRIPTION 5303307883 Knob-damper control,white/teal line 5308000010 Fan Blade,red 5308000124...
  • Page 12 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 SYSTEM 06/98...
  • Page 13 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 31 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 SYSTEM PART NO DESCRIPTION 218787700 Condenser...
  • Page 14 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 DISPENSER 06/98...
  • Page 15 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 17A* 33 # 35 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 DISPENSER PART NO DESCRIPTION 5308010366 Tube-water inlet,93" ,plastic , cut-to-size 5318582501 Tube-water inlet,93" ,plastic , cut-to-size 215294101 Tube-water inlet,formed ,plastic ,...

  • Page 16: Ice Container

    Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 ICE CONTAINER 06/98...
  • Page 17 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 ICE CONTAINER PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359...

  • Page 18: Ice Maker

    Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 ICE MAKER 06/98...
  • Page 19 A = FRS20ZSG (FRS20ZSGB0) B = FRS20ZSG (FRS20ZSGB1) POS. NO 11 # 12 # 13 # 15 # 17 # 141# 141# # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSGB0,FRS20ZSGB1 ICE MAKER PART NO DESCRIPTION 5308010366 Tube-water inlet,93" ,plastic , cut-to-size 5318582501 Tube-water inlet,93"...
  • Page 20 Publication No. FRS20ZSGB0,FRS20ZSGB1 5995308599 WIRING 06/98...
  • Page 21 FRS20ZSGB0,FRS20ZSGB1 Publication No. 5995308599 WIRING # = Fast-moving Parts 06/98 * = Non-Illustrated Parts...

This manual is also suitable for:

Frs20zsgb0Frs20zsgb1
