- Page 1 FRS22ZRGB1 FRS22ZRG 134A black FRS22ZRGD1 FRS22ZRG 134A almond FRS22ZRGW1 FRS22ZRG 134A white 101 Masters Blvd. Anderson, SC 29624 Publication No. 5995310777 980723 -EN/SERVICE /JLT ©1998 White Consolidated Industries, Inc. All rights reserved...
-
Page 2: Freezer Door
Publication No. FRS22ZRG 5995310777 FREEZER DOOR 07/98... - Page 3 FRS22ZRG Publication No. 5995310777 FREEZER DOOR A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 215598900 A B C Washer-flat,.691 x 1 x .05 ,zinc ,I&W hinge brkt 5303917276 A B C Insulation-door,fiberglass ,(bulk) 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C...
-
Page 4: Refrigerator Door
Publication No. FRS22ZRG 5995310777 REFRIGERATOR DOOR 07/98... - Page 5 FRS22ZRG Publication No. 5995310777 REFRIGERATOR DOOR A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215734324 A - - Gasket-refr door,black ,magnetic 215390401 A B C Panel-inner door,refr 218807011...
- Page 6 Publication No. FRS22ZRG 5995310777 CABINET 07/98...
- Page 7 FRS22ZRG Publication No. 5995310777 CABINET A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 215637602 A B C Cover-air duct 215637401 A B C Cover-evap coil,lower 5303208309 A B C Plug-hole,factory test 215230400 A B C Plug-harness hole 5303289043 A B C Support-air duct cvr,2.55"...
- Page 8 Publication No. FRS22ZRG 5995310777 SHELVES 07/98...
- Page 9 FRS22ZRG Publication No. 5995310777 SHELVES A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 5303298147 A B C Trim-basket 218298001 A B C Shelf-freezer,sliding ,wire 218159700 A B C Spacer-shelf 5303289504 A B C Shelf-freezer,fixed wire 218815501 A B C Shelf-pizza,24B 215406128...
- Page 10 Publication No. FRS22ZRG 5995310777 CONTROLS 07/98...
- Page 11 FRS22ZRG Publication No. 5995310777 CONTROLS A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 215290100 A B C Screw-solenoid valve,hx hd-slot wshr ,12-24 x 3/4 218646000 A B C Harness-wiring,filter heater 218710300 A B C Wrench-filter 215028605 A B C Knob-damper control 5308000010...
- Page 12 Publication No. FRS22ZRG 5995310777 DISPENSER 07/98...
- Page 13 FRS22ZRG Publication No. 5995310777 DISPENSER A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 218787800 A B C Condenser 5303208866 A B C Spacer-tube 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C Block-evap coil,styrofoam ,(2) 218541000 A B C...
- Page 14 Publication No. FRS22ZRG 5995310777 SYSTEM 07/98...
- Page 15 FRS22ZRG Publication No. 5995310777 SYSTEM A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 5318582501 A B C Tube-water inlet,93" ,plastic ,cut-to-size 215294101 A B C Tube-water inlet,formed ,plastic ,dispenser 218703400 A B C Tube-water inlet,inlet valve ,to filter 218505301 - - C Deflector-ice disp,white...
-
Page 16: Ice Container
Publication No. FRS22ZRG 5995310777 ICE CONTAINER 07/98... - Page 17 FRS22ZRG Publication No. 5995310777 ICE CONTAINER A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C Front-ice container 5304404337...
-
Page 18: Ice Maker
Publication No. FRS22ZRG 5995310777 ICE MAKER 07/98... - Page 19 FRS22ZRG Publication No. 5995310777 ICE MAKER A = FRS22ZRG (FRS22ZRGB1) B = FRS22ZRG (FRS22ZRGD1) C = FRS22ZRG (FRS22ZRGW1) 5318582501 A B C Tube-water inlet,93" ,plastic ,cut-to-size 218658301 A B C Tube-water inlet,filter ,to filter valve,w/elbow 218703400 A B C Tube-water inlet,inlet valve ,to filter 218770401 A B C Tube-water inlet,inlet valve ,to filter...
- Page 20 Publication No. FRS22ZRG 5995310777 WIRING 07/98...
- Page 21 FRS22ZRG Publication No. 5995310777 WIRING # = Fast-moving Parts 07/98 * = Non-Illustrated Parts...
