PRODUCT NO.
BASE MODEL NO.
FRS26ZGHB3
FRS26ZGH
FRS26ZGHD3
FRS26ZGH
FRS26ZGHW3
FRS26ZGH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995337549
000508
-EN/SERVICE/KHB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZGH
©2000 White Consolidated Industries, Inc.
©2000 White Consolidated Industries, Inc.
All rights reserved
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26ZGH and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26ZGH

Summary of Contents for Frigidaire FRS26ZGH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZGHB3 FRS26ZGH R134a black FRS26ZGHD3 FRS26ZGH R134a almond FRS26ZGHW3 FRS26ZGH R134a white MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS26ZGH 5995337549 FREEZER DOOR 05/00...
  • Page 3 FRS26ZGH Publication No. 5995337549 FREEZER DOOR A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734313 - B C Gasket-frzr door,white ,magnetic 5303288950 A B C Support-door rack,RH/LH 5303323484 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZGH 5995337549 REFRIGERATOR DOOR 05/00...
  • Page 5 FRS26ZGH Publication No. 5995337549 REFRIGERATOR DOOR A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734314 - B C Gasket-refr door,white ,magnetic 215403201 A B C Panel-inner door,refr 5304404909 A B C...
  • Page 6 Publication No. FRS26ZGH 5995337549 CABINET 05/00...
  • Page 7 FRS26ZGH Publication No. 5995337549 CABINET A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg 215637401 A B C Cover-evap coil,lower 5303208309 A B C...
  • Page 8 Publication No. FRS26ZGH 5995337549 SHELVES 05/00...
  • Page 9 FRS26ZGH Publication No. 5995337549 SHELVES A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 5303298147 A B C Trim-basket 218298003 A B C Shelf-freezer,sliding ,wire 218298004 A B C Shelf-freezer,sliding ,wire 240324101 A B C Shelf-pizza 215029002...
  • Page 10 Publication No. FRS26ZGH 5995337549 CONTROLS 05/00...
  • Page 11 FRS26ZGH Publication No. 5995337549 CONTROLS A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS26ZGH 5995337549 SYSTEM 05/00...
  • Page 13 FRS26ZGH Publication No. 5995337549 SYSTEM A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 218787900 A B C Condenser 5303208866 A B C Spacer-cond tube,black 5303289026 A B C Spacer-tube 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg 5303289029 A B C...
  • Page 14 Publication No. FRS26ZGH 5995337549 DISPENSER 05/00...
  • Page 15 FRS26ZGH Publication No. 5995337549 DISPENSER A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93" ,plastic 218832301 A B C Tube-water inlet, inlet valve, to filter 218859901 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No. FRS26ZGH 5995337549 ICE CONTAINER 05/00...
  • Page 17 FRS26ZGH Publication No. 5995337549 ICE CONTAINER A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS26ZGH 5995337549 ICE MAKER 05/00...
  • Page 19 FRS26ZGH Publication No. 5995337549 ICE MAKER A = FRS26ZGH (FRS26ZGHB3) B = FRS26ZGH (FRS26ZGHD3) C = FRS26ZGH (FRS26ZGHW3) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93" ,plastic 218832301 A B C Tube-water inlet, inlet valve, to filter 218859901 A B C Tube-water inlet, inlet valve, to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZGH 5995337549 WIRING SCHEMATIC 05/00...

  • Page 21: Wiring Diagram

    FRS26ZGH Publication No. 5995337549 WIRING DIAGRAM # = Fast-moving Parts 05/00 * = Non-Illustrated Parts...
