PRODUCT NO.
BASE MODEL NO.
FRS22ZGGB4
FRS22ZGG
FRS22ZGGD4
FRS22ZGG
FRS22ZGGW4
FRS22ZGG
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218851800A
SERVICE DATA SHEET - # 218905000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995318788
990301
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS22ZGG
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS22ZGG and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS22ZGG

Summary of Contents for Frigidaire FRS22ZGG

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS22ZGGB4 FRS22ZGG R134a black FRS22ZGGD4 FRS22ZGG R134a almond FRS22ZGGW4 FRS22ZGG R134a white MARKET North America WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218851800A SERVICE DATA SHEET - # 218905000 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS22ZGG 5995318788 FREEZER DOOR 03/99...
  • Page 3 FRS22ZGG Publication No. 5995318788 FREEZER DOOR A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 215734323 A - - Gasket-frzr door,black ,magnetic 215734303 - B - Gasket-frzr door,almond ,magnetic 215734313 - - C Gasket-frzr door,white ,magnetic 5303288950 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS22ZGG 5995318788 REFRIGERATOR DOOR 03/99...
  • Page 5 FRS22ZGG Publication No. 5995318788 REFRIGERATOR DOOR A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 215734324 A - - Gasket-refr door,black ,magnetic 215734304 - B - Gasket-refr door,almond ,magnetic 215734314 - - C Gasket-refr door,white ,magnetic 215390401 A B C...
  • Page 6 Publication No. FRS22ZGG 5995318788 CABINET 03/99...
  • Page 7 FRS22ZGG Publication No. 5995318788 CABINET A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 215637602 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 A B C Cover-evap coil,lower 5303208309 A B C...
  • Page 8 Publication No. FRS22ZGG 5995318788 SHELVES 03/99...
  • Page 9 FRS22ZGG Publication No. 5995318788 SHELVES A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 218383601 A B C Handle-frzr basket 218298001 A B C Shelf-freezer,sliding ,wire 218298002 A B C Shelf-freezer,sliding ,wire 218815501 A B C Shelf-pizza,24B...
  • Page 10 Publication No. FRS22ZGG 5995318788 CONTROLS 03/99...
  • Page 11 FRS22ZGG Publication No. 5995318788 CONTROLS A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS22ZGG 5995318788 SYSTEM 03/99...
  • Page 13 FRS22ZGG Publication No. 5995318788 SYSTEM A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 218787800 A B C Condenser 5303208866 A B C Spacer-tube 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C...
  • Page 14 Publication No. FRS22ZGG 5995318788 DISPENSER 03/99...
  • Page 15 FRS22ZGG Publication No. 5995318788 DISPENSER A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet, 93", plastic, cut-to-size 215294101 A B C Tube-water inlet, formed, plastic, dispenser 218832301 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No. FRS22ZGG 5995318788 ICE CONTAINER 03/99...
  • Page 17 FRS22ZGG Publication No. 5995318788 ICE CONTAINER A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS22ZGG 5995318788 ICE MAKER 03/99...
  • Page 19 FRS22ZGG Publication No. 5995318788 ICE MAKER A = FRS22ZGG (FRS22ZGGB4) B = FRS22ZGG (FRS22ZGGD4) C = FRS22ZGG (FRS22ZGGW4) POS. NO PART NO DESCRIPTION 5318582501 A B C Tube-water inlet, 93", plastic, cut-to-size 218832301 A B C Tube-water inlet, inlet valve, to filter 218859801 A B C Tube-water inlet, inlet valve, to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS22ZGG 5995318788 WIRING SCHEMATIC 03/99...

  • Page 21: Wiring Diagram

    FRS22ZGG Publication No. 5995318788 WIRING DIAGRAM # = Fast-moving Parts 03/99 * = Non-Illustrated Parts...
