  • Page 1 Transport GT20 B5151 Service Engineer’s Manual...
  • Page 3 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
  • Page 4 Federal Communications Commission (FCC) Notice for the USA Compliance Information State- ment (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received including inter- ference that may cause undesired operation.
  • Page 5 About this Manual This manual provides you with instructions on installing your Transport GT20. This manual is intended for experienced users and integrators with hardware knowledge of personal computers. This manual consists of the following parts Chapter 1: Provides an Introduction to the Transport GT20 B5151 barebone, packing list, describes the external components, gives a table of key compo- nents, and provides block diagrams of the system.
  • Page 6 SAFETY INFORMATION Before installing and using the Transport GT20, take note of the fol- lowing precautions: – Read all instructions carefully. – Do not place the unit on an unstable surface, cart, or stand. – Do not block the slots and opening on the unit, which are pro- vided for ventilation.

  • Page 7: Table Of Contents

    Table of Contents Chapter 1:Overview 1.1 About the Transport GT20 B5151 ......1 1.2 Features ..........2 1.3 Unpacking .
  • Page 8 3.7.1 M1010 Adapter Board Features..... 45 3.7.2 System Fan Layout ......46 3.7.3 M1010 Adapter Board Connector Pin Definition .

  • Page 9: Chapter 1:Overview

    Chapter 1: Overview About the Transport GT20 B5151 Congratulations on your purchase of the TYAN Transport GT20 (B5151), a highly-optimized rack-mountable barebone system. The Transport GT20 (B5151) offers the latest proces- sor server system, providing a rich feature set and incredible ®...

  • Page 10: Features

    Back I/O Ports • Supports TYAN Server Manage- • One 9-pin COM port ment (TSM) • One 15-pin VGA port • Optional TYAN SMDC IPMI V1.5 • PS/2 mouse and keyboard ports server management • Two USB 2.0 ports Power Supply •...

  • Page 11: Unpacking

    If any items are missing or appear damaged, contact your retailer or browse to TYAN’s Web site for service: http://www.tyan.com. The Web site also provides information on other TYAN prod- ucts, plus FAQs, compatibility lists, BIOS settings, and more. 1 x Tyan driver CD...
  • Page 12 Mainboard Manual Barebone Manual Heatsink x 1 Rail Kit Front Rear Sliding Brackets Front L-Bracket x 2 Rear L-Bracket x 2 Mounting Bracket x 4 Sliding Rails x 2 Screws Kit Chapter 1: Overview...

  • Page 13: About The Product

    About the Product The following views show you the product. 1.4.1 Front View Reset switch Warning LED HDD activity LED Power LED *Reserved USB ports CD-ROM Drive Power switch LAN LED Hard Drive Bay x 4 *Reserved: reserved for future upgrade 1.4.2 Rear View Power Supply Socket PS/2 Mouse/Keyboard Ports...

  • Page 14: Led Definition

    1.4.3 LED Definition Front Panel Color State Description Power Green Power ON Power OFF HDD Activity Amber Radom Blink HDD access activity No disk activity LAN1/LAN2 Activity Green Blink LAN access activity Warning Reserved LED for future upgrade. It is not functional in the B5151 barebone now.
  • Page 15 RJ45 NIC3 Linkage Green LAN linked (Left Side) Green Blinking LAN accessing No LAN linked RJ45 NIC3 Mode Green 100M mode (Right Side) 10M mode NOTE: “Right” or “Left” is viewed from the rear. Chapter 1: Overview...

  • Page 16: Internal View

    1.4.4 Internal View 1. PCI-X Slot 9. LED Control Board Cable 2. Link Bar 10. Tyan TARO Connector 3. Memory Slots 11. SATA Cable 4. EPS 12V Power Supply 12. CD-ROM Cable 5. Air Duct 13. USB Cable 6. System Fans (Left to right: 14.

  • Page 17: Motherboard Block Diagram

    1.4.5 Motherboard Block Diagram Chapter 1: Overview...

  • Page 18: Motherboard Layout

    1.4.6 Motherboard Layout PS/2 USBX2 PORT JP22 64bit 133/100/66MHz PCI-X JP23 JP17 JP17 32-bit 33MHz (5V) PCI JP18 X1 PCI Express SO-DIMM BROADCOM SMDC 5721 X1 PCI Express JP16 SATA4 SATA3 BROADCOM BROADCOM J 25 JP24 5721 5721 SATA1 JP26 SATA2 JP4/JP5/JP6/JP7 JP15...
  • Page 19 Jumpers & Connectors Jumper Function /Connector COM2 port SO-DIMM socket J20/J21/J22/J23 Serial ATA RAID connectors JP1/JP2/JP3 LAN2/LAN1/LAN3 disabled headers JP4/JP7 Front panel LAN1/LAN2 speed LED pin-headers JP5/JP6 Front panel LAN1/LAN2 link and active LED connec- tors Chassis fan connector JP20 SMDC connector JP12/JP13 Front panel USB2.0 connectors...
  • Page 20 Memo Chapter 1: Overview...

  • Page 21: Chapter 2:Setting Up

    Chapter 2: Setting Up 2.0.1 Before You Begin This chapter explains how to install the CPU, CPU heatsink, memory modules, and hard drives. Instructions on inserting a PCI card are also given. Take note of the precautions mentioned in this section when installing your system.

  • Page 22: Precautions

    2.0.4 Precautions Components and electronic circuit boards can be damaged by discharges of static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Transport GT20 or injury to yourself. •...

  • Page 23: Rack Mounting

    Rack Mounting The Transport GT20 can be mounted in a rack using the sup- plied rack mounting kit. Rack mounting kit Sliding Rails x 2: Sliding Brackets x 4 (Front x 2, Rear x 2) Mounting Ears x 2 Mounting Brackets x 4 Screws Kit x 1 2.1.1 Installing the Server in a Rack Follow these instructions to mount the Transport GT20...
  • Page 24 2. Using two screws from the supplied screws kit to secure the sliding rail to the bracket. Sliding Bracke Front Rear 3. Slide each sliding rail to the side of Transport GT20 as shown. 4. Using two screws from the supplied screws kit to secure the sliding rail to the side of Transport GT20.
  • Page 25 5. Locate the mounting bracket from the supplied kit. Screw the bracket to rack using 2 screws for each side. Be care- ful that the mounting bracket should be secured from the inside, not outside, of rack. See the picture below for the correct direction.
  • Page 26 6. Lift the unit into place in the rack (A). Ensure the unit is completely inserted into the rack (B). Then screw the unit into place as shown (C). Note: To avoid injury, it is strongly recom- mended that two people lift the Transport GT20 into place while a third per- son screws it to the rack.

  • Page 27: Installing Motherboard Components

    Installing Motherboard Components This section describes how to install components on to the motherboard, including CPU, memory modules and PCI card. 2.2.1 Removing the Chassis Cover Follow these instructions to remove the Transport GT20 chassis cover. 1. Release the screw on the back side. Then slide the chas- sis cover in the direction of arrow.

  • Page 28: Installing The Cpu, Heatsink And Air Duct

    2.2.2 Installing the CPU, Heatsink and Air Duct Follow these instructions to install the CPU, CPU heatsink and air duct. 1. Release the pre-installed air duct. Then locate the CPU socket. CPU socket 2. Remove the cover on the CPU socket. Chapter 2: Setting Up...
  • Page 29 3. Locate the lever of CPU socket. 4. Press the lever in the direction as shown to release the CPU socket. 5. Pull the lever in the direction. Chapter 2: Setting Up...
  • Page 30 6. Open the CPU socket. 7. Place CPU on the socket, ensuring that the edge with tri- angle mark aims at the edge of socket with triangle mark. 8. Close the cover and secure the CPU socket in the reverse procedures from step 1 to 6. Chapter 2: Setting Up...
  • Page 31 9. Secure the heatsink using 4 screws. Heatsink Screw 10. Secure the air duct using 2 screws. Chapter 2: Setting Up...

  • Page 32: Installing The Memory

    2.2.3 Installing the Memory Follow these instructions to install the memory modules on the motherboard. 1. Locate the memory slots on the motherboard. Memory slots 2. Press the memory slot locking levers in the direction of the arrows as shown in the following illustration. 3.

  • Page 33: Installing A Pci Card

    4. Insert the memory module into the slot as shown. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module. NOTE: When installing memory, always install the memory beginning with DIMM4, not DIMM1. That means starting the installation from the memory module near the power supply.
  • Page 34 2. Move the bracket to right as shown and then take off the bracket. 3. Insert the PCI card in the directions of arrow. 4. Push the tab of PCI slot on the rear panel in the direction as shown to fix PCI card. Chapter 2: Setting Up...

  • Page 35: Installing The Hard Drive

    Installing the Hard Drive The Transport GT20 barebone system supports Serial ATA hard drives. Follow these instructions to install a SATA hard drive. 1. Press the locking lever latch in the direction of arrow (A) and then pull the locking lever open (B). 2.
  • Page 36 4. Secure SATA hard drive using 4 screws 5. Reinsert the drive bay into the chassis (A), ensuring that the drive bay is completely inserted into the chassis (B). 6. Press the locking lever to secure the hard drive bay. Chapter 2: Setting Up...

  • Page 37: Installing The Slim Fdd (Option)

    Installing the Slim FDD (Option) 1. Locate the two FDD rails and screws from the FDD kit. Secure the two rails to FDD using four screws. FDD Rails & Screws 2. Connect the FFC cable to FDD. 3. Using a screw driver to pull open the door of FDD tray. 4.
  • Page 38 5. Connect the FFC cable to the connector on M1010 adapter board. 6. Locate the FDD cable from FDD kit. Connect the wrinkle side to the connector on M1010 adapter board. Refer to the picture below for the correct direction. For Mainboard For M1010 7.

  • Page 39: Chapter 3:Replacing Pre-Installed Components

    Chapter 3: Replacing Pre-Installed Components Introduction This chapter explains how to replace pre installed compo- nents including the motherboard, LED control board, HDD, and CD-ROM drive. Take note of the precautions in this section when installing your system. 3.1.1 Work Area Make sure you have a stable, clean working environment.

  • Page 40: Precautions

    3.1.3 Precautions Components and electronic circuit boards can be damaged by static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Transport GT20 or injury to yourself.

  • Page 41: Disassembly Flowchart

    Disassembly Flowchart The following flowchart outlines the disassembly procedure. Rear Components DIMMs Chass rear cover CPU/heatsink assembly Air duct PCI card Mainboard Mainboard Power supply Front Components Chassis rear cover PCBs CD-ROM Control M1010 Board Adapter Board HDD Backplane Chapter 3: Replacing Pre-Installed Components...

  • Page 42: Removing The Cover

    Removing the Cover Before replacing any parts you must remove the chassis cover. Follow these instructions to remove the cover of the Transport GT20 chassis cover. 1. Release the screw on the back side. Then slide the chas- sis cover in the direction of arrow. 2.

  • Page 43: Replacing Motherboard Components

    Replacing Motherboard Components Follow these instructions to replace motherboard compo- nents, including the motherboard. 3.4.1 Disconnecting All Motherboard Cables Before replacing the motherboard or certain components, remove cables connected to the motherboard. Follow these instructions to remove all motherboard cabling. Main Power EPS 12V Power PS/2...
  • Page 44 1. Disconnect ATX power cables EPS 12V Power Main Power 2. Disconnect CD-ROM drive cable. Chapter 3: Replacing Pre-Installed Components...
  • Page 45 3. Disconnect the cables from SATA, FAN and Front Panel connectors. Fan Cables SATA Cables Front Panel Cable 4. Disconnect the LAN LED cables. Chapter 3: Replacing Pre-Installed Components...

  • Page 46: Removing The Motherboard

    3.4.2 Removing the Motherboard After removing all cables, follow these instructions to remove the motherboard from the chassis. 1. Remove the link bar. 2. Remove the ten screws securing the motherboard to chassis. 3. Remove the motherboard. Chapter 3: Replacing Pre-Installed Components...

  • Page 47: Replacing The Slim Cd-Rom

    Replacing the Slim CD-ROM Follow these instructions to replace the CD-ROM. 1. Remove power and data cables from the slim CD-ROM adapter. Power Cable Data Cable 2. Press the tab in the directions as shown to release the CD-ROM drive. Chapter 3: Replacing Pre-Installed Components...
  • Page 48 3. The CD-ROM drive will be freed from the drive bay after pressing the tab. 4. Remove two screws that secure CD-ROM drive to the bracket. 5. Replace the CD-ROM drive. 6. Secure CD-ROM to the bracket using two screws. Then replace the unit into the drive bay and connect the CD- ROM power and data cables.

  • Page 49: Replacing The Led Control Board

    Replacing the LED Control Board Follow these instructions to replace the LED control board. 1. Remove two screws securing LED control board unit to the chassis. 2. Lift the LED control board unit free of the chassis. 3. Unplug the ribbon cable from the connector. Chapter 3: Replacing Pre-Installed Components...
  • Page 50 4. Unplug the USB cable from the connector. 5. Remove three screws securing LED control board to the bracket 6. Lift the LED control board free from the chassis. After replacement, insert the unit into the chassis following the reverse procedures from step 1~4. Chapter 3: Replacing Pre-Installed Components...

  • Page 51: Replacing The M1010 Adapter Board

    Replacing the M1010 Adapter Board 1. Disconnect the cables connectoed to the M1010 adapter baord, including Fan, PWM, Front Panel, and LAN/ID LED. Front Panel LAN LED 2. Disconnect the power cables connected to the M1010 adapter board and HDD backplane. 3.
  • Page 52 4. Disconnect the five fan cables connected to the M1010 adapter board. 5. Remove the six screws securing the M1010 adapter board. Chapter 3: Replacing Pre-Installed Components...

  • Page 53: M1010 Adapter Board Features

    3.7.1 M1010 Adapter Board Features for B5350 J14: Fan Tach Connector J1: Front Panel Connector FDD1 Connector J16: LCM Connector J7:Fan Tach & PWM Connector J3: LAN/ID LED Connector JP1: Fan Input Select Connector J19:CD-ROM Power Connector J5: Fan Connector J9: Fan Connector J11: Fan Connector J10: Fan Connector...

  • Page 54: System Fan Layout

    3.7.2 System Fan Layout The following picture provides the information for system fan layout. Refer to the tables on p.47 for information on connec- tion. Chapter 3: Replacing Pre-Installed Components...
  • Page 55 System Fan Speed Control Signal M1010 Adapter Board Connect to Motherboard J7 PWM Connector P1 Fan System Fan Monitoring Signal Barebone System Fan Connect to Motherboard Fan Fan 2 (Fan J13) Fan 4 Fan 3 (Fan J14) Fan 2 Fan 4 (J7 PWM) P1 Fan Fan 5 (Fan 14) Fan 3...

  • Page 56: M1010 Adapter Board Connector Pin Definition

    3.7.3 M1010 Adapter Board Connector Pin Definition J1 TYFP Front Panel Connector HDLED+ PW_LED+ HDLED - PW_LED - RESET- PWR_SW+ RESET+ PWR_SW - VOLTAGE5 WLED+ EXT_INT WLED- V5SB KEY PIN ICH_SMBDAT ICH_SMBCLK INTRU# J2 Front Panel Connector HDLED+ HDLED- RESET+ RESET- PW_LED+ PW_LED-...
  • Page 57 J3 LAN/ID LED Connector LAN1_LED+ LAN1_LED- LAN2_LED+ LAN2_LED- LAN3_LED+ LAN3_LED- ID_LED+ ID_LED- ID_SW+ ID_SW- KEY PIN FAN Signal Related Connector Pin Definition NOTE: The FAN signal naming is based on HW circuit design only. It might be different from the system fan naming. J7 Fan TACH &...
  • Page 58 J14 Fan TACH Connector FAN4_TACH FAN5_TACH FAN6_TACH FAN7_TACH FAN8_TACH FAN9_TACH FAN10_TACH KEY PIN J6 Fan Connector FAN1_12VPWM FAN1_TACH FAN2_TACH FAN2_12VPWM J10 Fan Connector FAN3_12VPWM FAN3_TACH FAN4_TACH FAN4_12VPWM Chapter 3: Replacing Pre-Installed Components...
  • Page 59 J11 Fan Connector FAN5_12VPWM FAN5_TACH FAN6_TACH FAN6_12VPWM J9 Fan Connector FAN7_12VPWM FAN7_TACH FAN8_TACH FAN8_12VPWM J5 Fan Connector FAN9_12VPWM FAN9_TACH FAN10_TACH FAN10_12VPWM Chapter 3: Replacing Pre-Installed Components...
  • Page 60 J15 & J16 LCM Connectors LCM_+5V LCM_SIN KEY PIN LCM_+5VSB LCM_SOUT JP1 Fan Input Select Connector Pin1 & Pin2 Close Fan PWM signal from J8 Pin2 & Pin3 Close Fan PWM signal from J7 Chapter 3: Replacing Pre-Installed Components...

  • Page 61: Replacing The Sata Backplane

    Replacing the SATA Backplane 1. After removing the M1010 adapter board, disconnect those cables connected to the SATA backplane, including SATA and power cables. 2. Grab the two tabs to lift the SATA backplane off. 3. Remove ten screws that secure the bracket to the adapter board.
  • Page 62 4. Release the adapter board free from the bracket. 5. After replacement, place and secure the unit into the chassis following the reverse procedures from step 1 to Chapter 3: Replacing Pre-Installed Components...

  • Page 63: Sata Backplane Features

    3.8.1 SATA Backplane Features U4, SATA 4 Connector U3, SATA 3 Connector U2, SATA 2 Connector HDD Power LED HDD Active LED U1, SATA 1 Connector Chapter 3: Replacing Pre-Installed Components...
  • Page 64 PW1 Power Connector PW2 Power Connector J4, SATA 4 Connector J3, SATA 3 Connector J4, HDD Access J2, SATA 2 Connector LED Connector 1 JP1, HDD Access J1, SATA 1 Connector LED Connector 2 Chapter 3: Replacing Pre-Installed Components...

  • Page 65: Replacing The Power Supply

    Replacing the Power Supply 1. Remove the screw securing the power supply to the chassis. 2. Remove the screws securing fan assembly to the chas- sis. Chapter 3: Replacing Pre-Installed Components...
  • Page 66 3. Lift the power supply free from the chassis. After replace- ment, place and secure the unit into the chassis following the reverse procedures from steps 1 to 2. Chapter 3: Replacing Pre-Installed Components...

  • Page 67: Appendix I: Bios Differences

    Appendix I: BIOS Differences The BIOS of B5151 is similar to the BIOS of S5151. However, there is something different. You may refer to the attached motherboard manual for the complete BIOS information. The difference between B5151 and S5151 is on the menu “PC Health Status”.
  • Page 68 B5151 System BIOS Phoenix - AwardBIOS CMOS Setup Utility PC Health Status Item Specific Auto FAN Power Control [Enabled] Help PWM Duty Cycle [30%] CPU Temperature Current System Temp VDIMM Vccp 3.3VSB VBat Vcc33 Fan1 Speed Fan2 Speed Fan3 Speed Fan4 Speed Fan5 Speed : Move...

  • Page 69: Appendix Ii: Cable Connection Tables

    Appendix II: Cable Connection Tables SATA Cable Table 1: B5151G20S4H Model M1204 SATA Backplane Connect to Motherboard SATA 1 SATA 1 SATA 2 SATA 2 SATA 3 SATA 3 SATA 4 SATA 4 FAN Cable Table 2: System Fan to M1010 Adapter Board System Fan Connect to M1010...
  • Page 70 Power Supply Cable Table 4: Power Supply to Motherboard Power Supply Connect to Motherboard P1 24-pin power cable PW1 24-pin connector P2 8-pin power cable PW2 8-pin connector Table 5: Power Supply to M1010 Adapter Board Power Supply Connect to M1010 P3 4-pin power cable PW2 4-pin connector...
  • Page 71 Table 9: CD-ROM Related Cable Motherboard IDE17 CD-ROM Backplane connector M1010 J19 power connector CD-ROM Backplane Table 10: Chassis Intrusion Cable Chassis intrusion switch Motherboard J16 Pin 16 & Pin 18 Table 11: FDD Related Cable (Option) M1010 FDD1 connector Motherboard FDD J9 M1010 FDD2 connector Slim FDD drive...

  • Page 72: Technical Support

    (which can have expensive consequences). If these options are not available for you then Tyan Computer Corporation can help.Besides designing innovative and qual- ity products for over a decade, Tyan has continuously offered customers service beyond their expectations.
  • Page 73 RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed pre- paid. TYAN will pay to have the board shipped back to you. Transport GT20, B5151 Service Engineer’s Manual v1.0 Document part No. D1688-100...
