18
USING THE COOKTOP
To turn on a DUAL element (left and right front
elements):
The front two elements on the cooktop are dual
elements. You are able to adjust the dual elements
according to the pot/pan size that you are using.
Inner element
A
1. Press the ON/OFF button that controls the element
that you would like to use (refer to the below
cooktop element control image).
2. Press the SELECT button to select either the inner
(smaller) or outer (larger) element function. The dual
elements default to the inner element function. The
light bars above the SELECT button indicate whether
the element is adjusted for the inner or outer
element function. One bar will display for the inner
element and two bars will display for outer element.
3. Press the + button once to adjust the element
temperature to Hi, or the – button once to adjust the
element temperature to Lo.
4. Use the – / + buttons to adjust the element
temperature settings. The element temperature
settings are adjustable at all times.
5. To turn off the element after cooking, press the ON/
OFF button once.
Warming zone control
Dual element controls
Outer element
B
Single element
controls
NOTE
• Hi is the highest temperature available.
• Lo is the lowest temperature available.
• Press and hold the + or – buttons to quickly scroll
through the temperature settings.
To turn on the Warming Zone (center element):
Use the Warming Zone to keep food warm after it has
already been cooked.
The warming zone is not meant for cooking food.
Attempting to cook uncooked or cold food on the
warming zone could result in a food borne illness.
1. Press the warming zone ON/OFF button. The
warming zone indicator light will flash.
2. Press the + button once to adjust the temperature
to Hi, or the – button once to adjust the temperature
to Lo. Power level sequence is from – Lo, 2, 3, 4, Hi or
from + Hi, 4, 3, 2, Lo.
3. Use the – / + buttons to adjust the temperature
settings. The temperature settings are adjustable at
all times.
4. To turn off the warming zone, press the ON/OFF
button once.
CAUTION
• Only use cookware and dishes that are safe for
oven and cooktop use.
• Always use oven mitts when removing food from
the cooktop and oven.
• Do not place sealed containers on the cooktop.
• DO NOT use plastic wrap to cover food while on
the cooktop. Plastic may melt onto the surface and
be very difficult to clean.
• When using the warming zone, food should be
kept in its container and covered with a lid or
aluminum foil to maintain food quality.
• DO NOT leave food on the warming zone for more
than two hours.
