LG LDE3031ST Service Manual

30” freestanding electric range
Hide thumbs Also See for LDE3031ST:
Table of Contents

Advertisement

Quick Links

Download this manual
삼
흥
정
판
30" Freestanding Electric Range
SERVICE MANUAL
MODEL: LDE3031ST
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL37118325
February, 2013
Printed in Korea

Advertisement

Table of Contents
loading

Related Manuals for LG LDE3031ST

Summary of Contents for LG LDE3031ST

  • Page 1 삼 흥 정 판 30” Freestanding Electric Range SERVICE MANUAL MODEL: LDE3031ST CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. February, 2013 P/NO : MFL37118325 Printed in Korea...
  • Page 2 SAFETY PRECAUTIONS • Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs may result in dangerous situations. If you need repairs, contact an LG Service Center or your dealer. • If the power cord is defective, it must be replaced by a qualified service agent with a UL listed range cord.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS GENERAL- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1-1 ~ 1-5 •...
  • Page 4 (Page) COMPONENT TEST - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4-1 ~ 4-4 •...

  • Page 5: General

    GENERAL IMPOR ANT SAFETY INSTRUCTIONS IMPOR ANT SAFETY INSTRUCTIONS Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, injury to person, or damage when using the range. This guide don’t cover all possible conditions that may occur. For further assistance contact your service agent or manufacturer.
  • Page 6 GENERAL IMPOR ANT SAFETY INSTRUCTIONS IMPOR ANT SAFETY INSTRUCTIONS • Be sure your appliance is properly installed and grounded by a WARNING qualified technician. • Do not repair or replace any part of the appliance unless • DO NOT touch heating elements or specifically recommended in the manual.
  • Page 7 GENERAL IMPOR ANT SAFETY INSTRUCTIONS IMPOR ANT SAFETY INSTRUCTIONS • Do Not Leave Children Alone - Children should not be left alone or SELF-CLEAN OVENS unattended in area where appliance is in use. They should never be • Do Not Clean Door Gasket – The door gasket is essential for a allowed to sit or stand on any part of the appliance.

  • Page 8: Model & Serial Number Label And Tech Sheet Locations

    GENERAL MODEL & SERIAL NUMBER LABEL MODEL & SERIAL NUMBER LABEL AND TECH SHEET LOCA TIONS AND TECH SHEET LOCA TIONS The Model/Serial Number label and Tech Sheet locations are shown below. Model & Serial Number Location Tech Sheet Location (On Low Rear Cover)
  • Page 9 GENERAL SPECIFICA TIONS SPECIFICA TIONS Model Number LDE3031ST Category Double oven range Overall Width 30" Installation type Freestanding Color availability Control Oven Keypad(Membrane) Cooktop Keypad(Membrane) Display Green LED Electronic clock & timer Control lock capability Audible preheat signal Special function Setting(5 categories) 1.

  • Page 10: Using Your Range

    USING YOUR RANGE GENERAL INFORMA TION GENERAL INFORMA TION Upper oven Rating Label Broil element Model numbers are recorded on the rating label. Rating label is located on the upper front left corner of the upper oven frame. It can be seen by opening the upper oven door.

  • Page 11: Control Panel Features

    USING YOUR RANGE CONTROL P ANEL FEA TURES CONTROL P ANEL FEA TURES single single 9 10 11 12 Left Rear element Right Rear element 17 18 16 19 20 single single Left Front element Right Front element UPPER OVEN LOWER OVEN ❶...
  • Page 12 USING YOUR RANGE CONTROL P ANEL FEA TURES CONTROL P ANEL FEA TURES COMMON FUNCTION Single element : Left Rear, Right Rear, Left Front, Right Front Indicator CLOCK : Use to set the time of day. SETTING : Use to set the time of day. START TIME : Use to set delay time.

  • Page 13: Setting The Clock

    USING YOUR RANGE To turn on a SINGLE 4. TIMER ON/OFF surface unit (FOR BOTH THE UPPER & LOWER OVEN) (Left Rear, Right Rear, Left Front, Right Front) UPPER UPPER 1. Press ON/OFF pad for the desired element TIMER ON/OFF TIMER ON/OFF position.

  • Page 14: Timed Cook, Delayed Timed Cook

    USING YOUR RANGE To decrease the oven temperature 6. TIMED COOK, DELAYED TIMED COOK For the Lower oven temperature adjustment. (For the Upper & Lower Bake) 1. Press SETTING pad 2 times for the lower Desired oven, “L-Aj” will appear in the display. START BAKE temperature...

  • Page 15: Sabbath Mode

    USING YOUR RANGE 11 SABBATH MODE (For both the Upper & Lower oven) Press and hold the SETTING pad 3 seconds (In order to activate or deactivate SABBATH MODE) 12. LOCKOUT (For the Upper & Lower Door lock, Oven & Cooktop control lock) Press and hold the START pad 3 seconds (In order to activate or deactivate LOCKOUT) 13.

  • Page 16: Component Access

    COMPONENT ACCESS This section instructs you on how to service each component inside the range. The components and their locations are shown below. COMPONENT LOCA TIONS COMPONENT LOCA TIONS Display Oven PCB Cooktop PCB SMPS Surface Elements Upper Broil Heater Oven Sensor Upper Door Latch Door Locking Motor...

  • Page 17: Removing The Back, Control Cover And Key Membrane Assembly

    COMPONENT ACCESS REMOVING THE BACK, CONTROL COVER REMOVING THE BACK, CONTROL COVER AND KEY MEMBRANE ASSEMBL AND KEY MEMBRANE ASSEMBL 6. Remove the 4 screws of the cook-top display PCB WARNING after taking a Relay PCB out. Now, you can take all PCBs out of the controller.

  • Page 18: Removeing The Control Power Supply And Power Control Board (Pcb)

    COMPONENT ACCESS REMOVING THE CONTROL POWER SUPPL REMOVING THE CONTROL POWER SUPPL AND POWER CONTROL BOARD (PCB) AND POWER CONTROL BOARD (PCB) 4. There are 3 PCB's (power control board). When WARNING you check PCB, check the proper pcb in default mode and check main pcb.
  • Page 19 COMPONENT ACCESS REMOVING THE SURF ACE ELEMENTS REMOVING THE SURF ACE ELEMENTS AND THE CERAMIC GLASS COOKT AND THE CERAMIC GLASS COOKT Step. 5 WARNING Protect the cooktop surface • DISCONNET power supply cord and turn the assembly over. from the outlet before servicing. •...
  • Page 20 COMPONENT ACCESS REMOVING THE DOOR LA TCH & UPPER DOOR SWITCH REMOVING THE DOOR LA TCH & UPPER DOOR SWITCH (For the Upper oven only) (For the Upper oven only) 5. To remove the upper door switch: WARNING a) If not already done, raise the cooktop (see page 3-4 for the procedure).
  • Page 21 COMPONENT ACCESS REMOVING THE DOOR LA TCH & LOWER DOOR SWITCH REMOVING THE DOOR LA TCH & LOWER DOOR SWITCH (For the Lower oven only) (For the Lower oven only) b) Remove 4 screws to detach 2 hinge suppoters. WARNING •...
  • Page 22 COMPONENT ACCESS f) Remove a screw from a actuating rod guide and unhook the actuating rod Actuarating Rod Actuarating Rod 5. To remove the lower door switch: a) If not already done, raise the cooktop (see page 3-4 for the procedure). b) Remove the lower door switch from the range.

  • Page 23: Removing The Broil Element

    COMPONENT ACCESS REMOVING THE BROIL ELEMENT REMOVING THE BROIL ELEMENT (For the Upper Oven and Lower Oven) (For the Upper Oven and Lower Oven) b) Pull the element forward so that you can WARNING access the terminals and disconnect the wires. •...

  • Page 24: Removing The Exposed Bake Element

    COMPONENT ACCESS REMOVING THE EXPOSED BAKE ELEMENT REMOVING THE EXPOSED BAKE ELEMENT (For the Upper Oven and Lower oven) (For the Upper Oven and Lower oven) b) Pull the element forward so that you can WARNING access the terminals and disconnect the wires. •...

  • Page 25: Removing The Oven Light & Socket Assembly

    COMPONENT ACCESS REMOVING THE OVEN LIGHT & SOCKET ASSEMBL REMOVING THE OVEN LIGHT & SOCKET ASSEMBL (For both the Upper & Lower oven) (For both the Upper & Lower oven) WARNING CAUTION • DISCONNET power supply cord • Be careful not to scratch or chip the from the outlet before servicing.

  • Page 26: Removing The Latch Drive Assembly

    COMPONENT ACCESS REMOVING THE LA TCH DRIVE ASSEMBL REMOVING THE LA TCH DRIVE ASSEMBL (For both the Upper & Lower oven) (For both the Upper & Lower oven) DOOR LOCKING MECHANISM WARNING The door lock assembly is located at the back side •...

  • Page 27: Removing The Oven Temperature Sensor

    COMPONENT ACCESS REMOVING THE OVEN TEMPERA TURE SENSORS REMOVING THE OVEN TEMPERA TURE SENSORS (For both the Upper & Lower oven temperature sensor) (For both the Upper & Lower oven temperature sensor) 5. To remove an oven temperature sensor, WARNING disconnect the connector from the main harness and remove the two mounting screws in oven •...

  • Page 28: Removing & Replacing The Lift-Off Oven Door

    COMPONENT ACCESS REMOVING & REPLACING THE LIFT -OFF OVEN DOOR REMOVING & REPLACING THE LIFT -OFF OVEN DOOR (For the Upper door) (For the Upper door) To replace the door: CAUTION Step. 1 • Be careful when removing and Be sure both hinges are lifting the door.
  • Page 29 COMPONENT ACCESS REMOVING & REPLACING THE LIFT -OFF OVEN DOOR REMOVING & REPLACING THE LIFT -OFF OVEN DOOR (For the Lower door) (For the Lower door) To replace the door: CAUTION Step. 1 • Be careful when removing and Firmly grasp both sides of the door at the top. lifting the door.

  • Page 30: Removing The Upper Oven Door Handle & Glass

    COMPONENT ACCESS REMOVING THE UPPER OVEN DOOR HANDLE & GLASS (For the Upper door) REMOVING THE UPPER OVEN DOOR HANDLE & GLASS (For the Upper door) 6. To remove the door handle & trim (for Stainless model) WARNING a) Remove the 4 door handle screws and lift the door handle off door trim and slide up the door trim.
  • Page 31 COMPONENT ACCESS 7. To remove a hinge receptacle assembly: c) Lift the inner oven door glass and bracket a) Remove the 4 top liner screws assembly out of the door liner. (See step 3 on page 3-16) b) Place the door liner assembly on a padded work surface with the hinge receptacles over the edge.

  • Page 32: Removing The Oven Door Handle & Glass

    COMPONENT ACCESS REMOVING THE OVEN DOOR HANDLE & GLASS (For the Lower door) REMOVING THE OVEN DOOR HANDLE & GLASS (For the Lower door) 6. To remove the door handle & trim (for Stainless model) WARNING a) Remove the 4 door handle screws and lift the door handle off door trim and slide up the door trim.
  • Page 33 COMPONENT ACCESS 7. To remove a hinge hanger assembly: d) Lift the inner oven door glass and bracket a) Remove the 4 top liner screws assembly out of the door liner. (See step 3 on page 3-18) b) Place the door liner assembly on a padded work surface with the hinge hangers over the edge.

  • Page 34: Removing The Oven Door Gasket

    COMPONENT ACCESS REMOVING THE OVEN DOOR GASKET REMOVING THE OVEN DOOR GASKET (For the Upper &Lower door gaskets) (For the Upper &Lower door gaskets) 3. Pull the ends of the gasket out of the liner holes. WARNING Liner Hole • DISCONNET power supply cord from the outlet before servicing.

  • Page 35: Removing A Side Panel

    COMPONENT ACCESS REMOVING A SIDE P ANEL REMOVING A SIDE P ANEL 7. Remove the two screws from the left or right side WARNING panel. • DISCONNET power supply cord from the outlet before servicing. • Replace all panels and parts before operating.

  • Page 36: Component Test

    COMPONENT TEST Before testing any of components, perform the following checks: NOTE: 1. The most common cause for control failure is corrosion on connectors. Therefore, disconnecting and reconnecting wires will be necessary throughout test procedures 2. ALL units in the first few days of use should be checked for mis-wiring or loose connections 1.

  • Page 37: Oven Sensor

    Components Test procedures Results Normal: Approximately Oven Sensor 1. Refer to page 3-13 for the servicing procedure 1.09 kΩ ± 10% 2. Measure the resistance after cooling down If not replace (Multiple meter scale: R x 1000) NOTE: Ω Value was tested at room temperature (77F/25˚C) Door switch...
  • Page 38 Components Test procedures Results Normal : Approximately 26.6Ω Upper oven 1. Remove wire leads Bake heater Abnomal : Infinite(opened) 2. Measure resistance after cooling down NOTE: Ω Value was tested at room temperature (77F/25˚C) Be careful the element is sensitive to temperature. Lower oven Normal : Approximately 14.7Ω...

  • Page 39: Single Surface Unit(Lf,Rf,Lr, Rr)

    Components Test procedures Results Single surface units: 1. Refer to page 3-5 for the servicing procedure Left Front (LF) 2. Set the Multiple meter scale to the R x 1 Right Front (RF) 3. Disconnect wires from cook-top elements Left Rear (LR) 4.

  • Page 40: Composition Of Control

    COMPOSITION OF CONTROL Key Matrix Key Matrix Oven Keypad Cook-top Keypad...
  • Page 41 COMPOSITION OF CONTROL Oven System PCB (Loc No.: 2006) Oven Relay PCB (Loc No.: 5070) Front Oven Display PCB (Loc No.: 2031) Back SMPS PCB Loc No.: 2009) Back Cover Cooktop System PCB (Loc No.: 2030) Controller assembly Cooktop System PCB (Loc No.: 2131)

  • Page 42: Oven System Pcb

    COMPOSITION OF CONTROL Oven system PCB Oven system PCB CN401 CN712 CN03 CN403 CN402 CN04 CN01 CN51 Cooktop system PCB Cooktop system PCB CN26 CN25 CN21 CN33 CN29 CN30 CN10 CN11 CN12...

  • Page 43: Oven Relay Pcb

    COMPOSITION OF CONTROL Oven relay PCB Oven relay PCB CN03 CN12 CN11 CN01 SMPS PCB SMPS PCB...

  • Page 44: Cooktop Display

    COMPOSITION OF CONTROL Cooktop display Cooktop display Oven display (LED) Oven display (LED)

  • Page 45: Diagnosis Through Schematic

    DIAGNOSIS THROUGH SCHEMATIC Symptom : Oven Lamp not operating - Check : Lamps coil’s resistance : Normal : approximately 20~40Ω ) Symptom : No heating (F-9, F-19) - Check : Heater and Relay Open/ short Symptom : Oven hot (F-6, F-16) - Check : Heater Relay Short Symptom : Cooktop no Heating...

  • Page 46: Check The Failure Code (F-Code)

    CHECK THE FAILURE CODE (F-code) When the oven has some failure on cooking, -. Oven may stop operating and F-code will display in display window. -. Some F-codes display immediately(F-3,F-9,F-19), but other codes will store in EEPROM memory and not displayed F-codes can only be viewed by following the below Step 1.

  • Page 47: Safety Caution & Error Code Summary

    SAFETY CAUTION & ERROR CODE SUMMARY 1.1 Safety Caution • Unless SVC manual indicate that ‘power is on’, normal state is power off. 1.2 Error Code Summary Code Description Operation Opened Sensor Upper Oven Thermistor remains open for over 1 min, after cook starts during cooking.

  • Page 48: Checking Flow Chart By Failure

    CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. Power Failure 1. Check Electric Wiring (Dead) 2. Check the thermostat. 2. No Display 3. Check the SMPS PCB EBR64624703...

  • Page 49: No Display (No Power)

    CHECKING FLOW CHART BY FAIRURE No Display (No Power) Control Dead Check AC input of SMPS PCB - SMPS PCB, CN1 (Pin 1 and Pin 3) Select a function Any beeping Sound? Replace the Oven System 120V AC? Normal? Replace the Oven Display PCB Replace the SMPS PCB Normal? Replace the SMPS PCB...
  • Page 50 CHECKING FLOW CHART BY FAIRURE No Display (No Power) Check thermostat Normal? Check the connection of L1 and N Replace thermostat from power inlet. Normal? Fix or replace the lead wire...
  • Page 51 CHECKING FLOW CHART BY FAIRURE No Display (No Power) Check and fix the connection 1. Between Cooktop SYSTEM and SMPS PCB. 2. Between Cooktop SYSTEM and Oven system PCB. 3. Between Oven Display and Oven system PCB. Normal? Replace the Oven System PCB...
  • Page 52 CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. No heating 1. Check Electric Wiring 2. F-9 2. The Heater’s Resistance. 3. F-19 3. Check the Sensor. (Thermister) Heater resistor Check the sensor...
  • Page 53 CHECKING FLOW CHART BY FAIRURE Oven does not heat (including F-9, F-19 Error) No heating Disconnect power Check the electric wiring 1. Harness of Relay connection. 2. Each heater’s connection. 3. Oven System and Relay PCB connection(CN11, CN12) UPPER LOWER Harness connection check Normal? Fix or replace the lead wire...
  • Page 54 CHECKING FLOW CHART BY FAIRURE Oven does not heat (Including F-9, F-19 Error) Measure the Resistor of each heater Between the DLB Relay’s L2 and each heater Relay’s Harness point of Figure 1 (①, ② and ⑤) (measure the resistance after cooling down) UPPER Normal Resistor...

  • Page 55: Oven Does Not Heat

    CHECKING FLOW CHART BY FAIRURE Oven does not heat (Including F-9, F-19 Error) Normal? Replace the error heater Connect the power Check the value of Thermister by using the test mode • To enter the test mode, follow these steps: 1.
  • Page 56 CHECKING FLOW CHART BY FAIRURE Oven does not heat (Including F-9, F-19 Error) Normal? Disconnect the oven sensor and check the value (measure the resistance after cooling down) Normal:approximately 1.06 kΩ at 65°F ~ 1.12 kΩ at 85°F. Normal? Replace the oven sensor Replace the Relay PCB Replace the Oven SYSTEM PCB...
  • Page 57 CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. Cooktop Not 1. Check Electric Wiring working 2. Check the Heater Resistance Check the Heater Resistance 9-10...

  • Page 58: Cooktop Does Not Heat

    CHECKING FLOW CHART BY FAIRURE Cooktop does not heat No heating (All or a part of cooktop heaters) Disconnect power Check the loose connection cook-top heater and harness Normal? Reconnect. If defective harness, replace or fix Check the loose connection (Oven System PCB and Cooktop PCB) Normal? Reconnect.
  • Page 59 CHECKING FLOW CHART BY FAIRURE Cooktop does not heat Check the cooktop heaters (measure the resistance between CN10,CN11,CN12,TAB11,TAB09 and SMPS CN1 pin 3) RY18 RY19 DLB Out1 DLB Out2 DLB Out1 DLB Out2 Normal : approximately 100Ω 9-12...
  • Page 60 CHECKING FLOW CHART BY FAIRURE Cooktop does not heat Normal? Replace the Cook-top heater Replace the Cook-top system 9-13...
  • Page 61 CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. Door Lock System 1. Check the Electric wiring Failure 2. Check the Motor’s Resistance 2. F-10, F-20 9-14...

  • Page 62: Door Lock System Error

    CHECKING FLOW CHART BY FAIRURE → → F-10, F-20 Error Door lock system error Just after self-clean start,the door lock motor starts to rotate. During that time if the door lock switch does not operate properly after rotating twice, then supervising circuit detects a Door Lock failure and the F-10, F-20 error code appears.
  • Page 63 CHECKING FLOW CHART BY FAIRURE Door lock system error → → F-10, F-20 Error Check the door locking motor (measure the resistance) normal: approximately 2.6 kΩ abnormal: infinite or below 5 Ω Normal? Replace the door locking Check the looseness of CN08 motor Normal? Reconnect...
  • Page 64 CHECKING FLOW CHART BY FAIRURE Door lock system error → → F-10, F-20 Error Check the Oven Relay PCB’s electric connection (CN01, CN03) Check the connection between Oven System PCB and Relay PCB(CN11, CN12) Normal? Reconnect Replace the Oven Relay PCB Normal? Replace the Oven System PCB 9-17...
  • Page 65 CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. Sensing Fail 1. Check the electric wiring 2. F-1 2. Check the test Mode 3. F-2 3. Check the Sensor (Thermistor) resistance 4. F-4 (approximately 1.06 kΩ at 65°F ~ 1.12 kΩ at 85°F.) 5.

  • Page 66: Oven Sensing Error

    CHECKING FLOW CHART BY FAIRURE Oven sensing error → → F-1, F-2, F-3, F-4 error Main oven sensing failed Connect the power Check the value of thermistor by using the test mode • To enter the testmode, follow these steps: 1.
  • Page 67 CHECKING FLOW CHART BY FAIRURE Oven sensing error → → F-1, F-2, F-3, F-4 error Normal? Disconnect the oven sensor and check the value (measure the resistance after cooling down) Normal:approximately 1.06 kΩ at 65°F ~ 1.12 kΩ at 85°F. Normal? Replace the oven sensor Replace the Oven Relay PCB...

  • Page 68: Oven Hot Error

    CHECKING FLOW CHART BY FAIRURE Symptom Check Point 1. Oven hot 1. Check the Resistance of the Relay. 2. F-6 2. Check the Sensor (thermistor) resistance 3. F-16 (approximately 1.06 kΩ at 65°F ~ 1.12 kΩ at 85°F.) Check the resistance of relays Check the Sensor (thermistor) resistance 9-21...
  • Page 69 CHECKING FLOW CHART BY FAIRURE Oven hot error → → F-6, F-16 error Oven is hot (F-6, F-16) Disconnect the power and oven sensor. Check the oven sensor value (measure the resistance after cooling down) Normal:approximately 1.06 kΩ at 65°F ~ 1.12 kΩ at 85°F Normal? Replace the oven sensor Remove the Relay PCB harness...
  • Page 70 CHECKING FLOW CHART BY FAIRURE Oven hot error → → F-6, F-16 error Normal? Replace the Relay PCB Replace the Oven SYSTEM PCB 9-23...

  • Page 71: No Key Input

    CHECKING FLOW CHART BY FAIRURE No key input Or F-3 Key does not input(including F-3) If the key error occurred in the Oven Display LED, check the oven system. If the problem happened in the Cooktop Display LED, check the cooktop system. Check the connection between Oven System PCB’s CN03 and Cooktop Systme PCB’s CN21 Normal? Reconnect...

  • Page 72: Error (Communication Error)

    CHECKING FLOW CHART BY FAIRURE F-11 error (communication error) F-11 error Check the connection between Oven System PCB’S CN06 and Oven System PCB’S CN13 This Harness Normal? Reconnect Replace the Oven System PCB Reset failure log and Check the F-code. 1.

  • Page 73: Trouble Shooting

    TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES & FAULTS SOLUTIONS Oven not operating. • Bad power control board (PCB) • Test and/or replace PCB • Power outage • Verify power is present at unit. • Verify that the circuit breaker is not tripped •...
  • Page 74 TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES & FAULTS SOLUTIONS Electronic timer will not • Failed main power control board • Replace power control board(PCB) accept Programming. Electronic timer will not • Failed main power control board • Replace power control board(PCB) accept Programming.
  • Page 75 TROUBLE SHOOTING PROBLEMS POSSIBLE CAUSES & FAULTS SOLUTIONS Oven door sagging on one • Hinge loose or out of position to • Adjust hinges or replace hinges side oven liner Door does not close • Broken or misadjusted door spring •...

  • Page 76: Schematic Diagram

    SCHEMATIC DIAGRAM WARNING • DISCONNET power supply cord from the outlet before servicing. • Replace all panels and parts before operating. • RECONNECT all grounding devices. - Failure to do so can result in severe personal injury, death or electrical shock. RADIANT COOK-TOP Wattage RR:1200W...

  • Page 77: Strip Circuits

    STRIP CIRCUITS STRIP CIRCUITS Complete the following steps before checking electric oven circuit : 1.Check the line voltage, household fuse or circuit breaker. 2.Check for loose wiring or mis-wiring within electric range. NOTE: The following individual circuits are for use in diagnosis, and are shown in the ON position. UPPER BAKE/WARM LOWER BAKE 11-2...
  • Page 78 LOWER WARM/PROOF UPPER BROIL LOWER BROIL 11-3...
  • Page 79 UPPER SELFCLEAN LOWER SELFCLEAN 11-4...
  • Page 80 OVEN LAMP LR (Cooktop element) 11-5...
  • Page 81 RR (Cooktop element) LF (Cooktop element) RF (Cooktop element) 11-6...

  • Page 82: Exploded View

    #EV# EXPLODED VIEW INTRODUCTION MODEL: Customer Model Product Code SVC Model CONTROLLER PARTS COOKTOP PARTS DOOR PARTS CAVITY PARTS -12-1-...
  • Page 83 #EV# UPPER DOOR PARTS 102U W243 1722 1000 W225 1733 103S 1008 1703 1015 1009 1703 W225 W256 103S 1733 1020 1721 1021 1455 -12-2-...
  • Page 84 #EV# LOWER DOOR PARTS 102U W243 1733 W225 1100 102S 1734 1018 1120 W222 1115 1041 W225 1009 W101 1734 1733 W101 102S 1704 1704 -12-3-...
  • Page 85 #EV# CONTROLLER PARTS 2048 2046 2047 2131 2045 2042 2041 3006 2043 2028 2044 2030 2385 2382 2031 2006 2009 3006 2033 2002 3006 2037 2036 -12-4-...
  • Page 86 #EV# COOKTOP PARTS 3014 3056 3401 3057 3302 3302 3402 3058 3074 3301 3006 3301 3402 -12-5-...
  • Page 87 #EV# UPPER CAVITY PARTS 5501 5063 5537 5545 5535 3006 5032 5091 5539 5078 5502 5505 5551 W301 5116 5515 W230 5206 5037 5515 W301 W301 4002 5019 W256 5021 5505 W256 5541 5531 5511 5078 5516 -12-6-...
  • Page 88 #EV# LOWER CAVITY PARTS 5517 3013 5014 5510 5508 3007 5132 5518 3063 5041 5511 W235 5504 5001 5546 5513 3006 5502 5501 3006 5505 5116 5063 5558 5515 5512 5505 5070 5611 5509 5505 5512 4002 5515 5700 5536 5505 5021 5503...
