Caple CR 9210 Instruction Manual

Caple CR 9210 Instruction Manual

Twin oven gas cooker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Twin Oven
Gas Cooker
CR 9210
Model:
GB
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for Caple CR 9210

Summary of Contents for Caple CR 9210

  • Page 1 Twin Oven Gas Cooker CR 9210 Model: Instruction Manual...
  • Page 2 Thank you for buying your new CAPLE cooker. To ensure that you get the best results from your new CAPLE cooker, we strongly suggest that you read this instruc- tion manual thoroughly before use. This manual contains installation advice, cleaning tips and a cooking guide, as well as other important facts about your CAPLE cooker.

  • Page 3: Safety Reminders

    The Grill Burner that any servicing or repairs are carried out only by an authorised CAPLE SERVICE is exposed, so take great care when plac- ENGINEER. ing food in the oven or removing it. Use the grill pan handles or gloves.

  • Page 4: Electrical Installation

    1 - Electrical Installation For your safety please read the following information: This appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. This appliance has to be equipped with a 13 amp three pin mains plug with a 3 amp fuse fitted.
  • Page 5 Warning! Before effecting any intervention on the electrical parts the appliance must be disconnected from the network. Replacement of the electrical feeder cable To connect the feeder cable to the cooker it is necessary to: – Remove the screw that hold shield “A” behind the cooker (fig. 1.2). –...

  • Page 6: For The Installer

    FOR THE INSTALLER 2 - Location The cooker must be installed by a qualified technician and in compliance with local safety standards. This cookers has class “2/1” overheating protection so that it can be installed next to a cabinet. If the cooker is installed adjacent to furniture which is higher than the gas hob cooktop, a gap of at least 200 mm must be left between the side of the cooker and the furniture.

  • Page 7: Fitting The Adjustable Feet

    Backguard Before installing the cooker, assemble the backguard “C” (fig. 2.2). 1. The backguard “C” can be found packed at the rear of the cooker. 2. Before assembling remove any protective film/adhesive tape. 3. Remove the two spacers “A” and the screw “B” from the rear of the cooktop. 4.
  • Page 8 WARNING When raising cooker to upright posi- tion always ensure two people carry out this manoeuvre to prevent dam- age to the adjustable feet (fig. 2.5). WARNING Be carefull: do not lift the cooker by the door handle when raising to the upright position (fig.
  • Page 9 Provison for ventilation The room containing the cooker should have an air supply in accordance with BS.5540: Part 2: 1989. All rooms require an openable window or equivalent while some rooms require a per- manent vent in addition to the openable window. The cooker should not be installed in a bed-sitting room, of volume less than 21 m Where a DOMESTIC COOKER is installed in a room or internal space, that room or internal space shall be provided with a permanent opening which communicates directly...

  • Page 10: Gas Connection

    3 - Gas connection Gas installation Gas connection Important note The installation of the cooker to Natural Gas or LP Gas must be carried out by This appliance is supplied for use on a qualified gas engineer. Installers shall NATURAL GAS only and cannot be used take due account of the provisions of the on any other gas without modification.
  • Page 11 Gas connection The gas supply must be connected to the gas inlet which is located at the left or the right hand rear of the appliance (fig. 3.1). The pipe does not cross the cooker. When screwing the connecting tube operate with two spanners (fig.

  • Page 12: Conversion To Lpg

    Conversion to LPG Conversion procedure Injectors replacement Select the injectors to be replaced according to the “Table for the choice of the injectors” (page 13). Injectors supplied obtained from After-Sales Service. To replace the injectors proceed as fol- lows: - Remove pan supports and burners from the cooktop.
  • Page 13 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 20 G 30 - 28-30 mbar Reduced Nominal 20 mbar G 31 - 37 mbar Power Power BURNERS Tube ring Tube ring By-pass By-pass Ø injector Ø injector [kW] [kW] opening opening [1/100 mm]...
  • Page 14 LEFT OVEN Oven burner and grill burner replacement of injectors a) oven burner Fig. 3.6 – Lift and remove the lower panel inside the oven. – Remove the burner securing screw (fig. 3.6). – Withdraw the burner as shown in fig- ure 3.7 and rest it inside the oven.
  • Page 15 Regulation of air supply to oven and grill burners Using a cross-head screwdriver, slacken the screw securing the air flow regulation collar (fig. 3.10 and 3.11) and move the collar forward or backward to increase or reduce the air aperture in accordance with gas type and the indications in the “ TABLE FOR THE CHOICE OF THE INJECTORS ”.
  • Page 16 RIGHT OVEN Oven burner and grill burner replacement of injectors a) oven burner Fig. 3.12 – Lift and remove the lower panel inside the oven. – Remove the 2 burner securing screws (fig. 3.12). – Withdraw the burner as shown in fig- ure 3.13 and rest it inside the oven.
  • Page 17 Regulation of air supply to oven and grill burners Using a screwdriver, slacken the screw securing the air flow regulation collar (fig. 3.16 and 3.17) and rotate the collar clockwise or anti-clockwise to increase or reduce the air aperture in accordance with gas type and the indications in the “ TABLE FOR THE CHOICE OF THE INJECTORS ”.

  • Page 18: Lubrication Of The Gas Taps

    LEFT and RIGHT OVENS Regulating of the oven minimum To be effected only for the oven burner (as the grill burner has an only fixed input) operating on the thermostat as fol- lows: – Light the oven taking the knob to Max. position.

  • Page 19: Features And Technical Data

    4 - Features and Technical Data Fig. 4.1 Cooking hob - (Fig. 4.1) 1. Auxiliary burner (A) 1,00 kW 2. Semi-rapid burner (SR) 1,75 kW 3. Rapid burner (R) 3,00 kW 4. Triple-ring burner (TC) 3,50 kW...

  • Page 20: Control Panel

    Control Panel Fig. 4.2 Control panel (Fig. 4.2) 1. Left oven - Gas oven / gas grill control knob 2. Left oven - Oven light control knob 3. Minute counter 4. Right oven - Rotisserie / oven light control knob 5.

  • Page 21: How To Use The Hob Burners

    How To Use the Hob Burners Hob burners Each hob burner is controlled by a separate gas tap operated by a control knob (fig. 4.3) which has 3 positions marked on the knob, these are: – Symbol : tap closed (burner off) –...
  • Page 22 Choice of burner The burner must be chosen according to the diameter of the pans and energy required. Fig. 4.4 Burners Pan diameter Auxiliary 12 ÷ 14 cm Semi-rapid 16 ÷ 24 cm Rapid 24 ÷ 26 cm Triple-ring 26 ÷ 28 cm max 36 cm do not use pans with concave or convex bases Saucepans with handles which are excessively heavy, in relationship to the weight of...
  • Page 23 Correct use of triple-ring burner The flat-bottomed pans are to be placed directly onto the pan-support. To use the WOK you need to place the proper stand in order to avoid any faulty operation of the triple-ring burner (Fig. 4.5 - 4.6). IMPORTANT: The special grille for wok pans (fig.

  • Page 24: Minute Counter

    5 - Minute counter Minute counter The minute counter is a timed acoustic warning device which can be set for a maximum of 60 minutes. The knob (Fig. 5.1) must be rotated clockwise as far as the 60 minute position and then set to the required time by rotating it anticlockwise.

  • Page 25: General Features

    6 - How To Use the “Left Gas Oven” Oven thermostat Attention: the oven door becomes very hot during operation. The oven thermostat (fig. 6.1) is marked Keep children away. with numbers, these correspond to the oven temperature, in addition the “OFF” position is shown by the symbol “...

  • Page 26: Oven Cooking

    Ignition of the oven burner 1) Open the oven door to the full extent. WARNING: Risk of explosion! The oven door must be open during this operation. 2) Lightly press and turn the thermostat knob anti-clockwise to max position fig. 6.3). 3) Press the knob firmly until the burner lights.
  • Page 27 Ignition of the grill burner Very important: the grill must always be used with the oven door ajar and with shield "A” mounted. Attention: the oven door becomes very hot during operation. Keep children away. 1) Open the oven door to the full extent.

  • Page 28: Use Of The Grill

    Use of the grill Very important: the grill must always be used with the oven door slightly open and with shield "A” mounted (Fig. 6.6). Mount shield “A” which serves to protect the control panel from the heat. Turn on the grill, as explained in the pre- ceding paragraphs and let the oven pre- heat for about 5 minutes with the door ajar.
  • Page 29 7 - How To Use the “Right Gas Oven” Oven thermostat Attention: the oven door becomes very hot during operation. The oven thermostat (fig. 7.1) is marked Keep children away. with numbers, these correspond to the oven temperature, in addition the “OFF” position is shown by the symbol “...
  • Page 30 Ignition of the oven burner Oven cooking For efficient oven preheating, we rec- 1) Open the oven door to the full ommend that grill trays and racks are extent. removed from the oven and replaced WARNING: Risk of explosion! The after about 15 minutes.
  • Page 31 Ignition of the grill burner Very important: the grill must always be used with the oven door ajar and with shield "A” mounted. Attention: the oven door becomes very hot during operation. Keep children away. The grill burner generates the infra-red rays for grilling.
  • Page 32 Use of the grill Very important: the grill must always be used with the oven door slightly open and with shield "A” mounted (Fig. 7.6). Mount shield “A” which serves to protect the control panel from the heat. Turn on the grill, as explained in the pre- ceding paragraphs and let the oven pre- heat for about 5 minutes with the door ajar.
  • Page 33 Rotisserie This is used for spit roasting under the grill and comprises: – an electric motor fitted to the rear of the oven – a stainless steel skewer provided with slide-out heatless handgrip and two sets of adjustable forks – a skewer support to be fitted in the middle runner.
  • Page 34 8 - Recommended cooking temperature Food °C °F Shelf Cooking Position Time (approx) CAKES Victoria sandwich 2 or 3 20-25 mins Small cakes/buns 1 and 2 15-20 mins Maidera cake 2 or 3 20 mins 3 /4 Fruit cake hours 1 /2 Rich fruit cake 3 or 4...

  • Page 35: Cleaning And Maintenance

    9 - Cleaning and Maintenance General advice – When the appliance is not being used, it is advisable to keep the gas tap closed. – Every now and then check to make sure that the flexible tube that connects the gas line or the gas cylinder to the appliance is in perfect condition and eventually substitute it if it shows signs of wearing or damage.

  • Page 36: Stainless Steel Surfaces

    Cleaning All the enamelled parts must be cleaned with a sponge and soapy water or other non- abrasive products. Dry preferably with a soft cloth. Acidic substances like lemon juice, tomato sauce, vinegar etc. can damage the enamel if left too long. Stainless steel surfaces The stainless steel front panels on this cooker (facia, oven door, storage compartment) are protected by a finger-print proof lacquer.
  • Page 37 Burners They can be removed and washed only with soapy water. Detergents can be used but must not be abrasive or corrosive. Do not use abrasive sponges or pads. Do not put in dishwasher. After each cleaning, make sure that the burner-caps, as well as the burners, have been well wiped off and CORRECTLY POSITIONED.
  • Page 38 Triple ring burner The triple ring burner must be correctly positioned (see fig. 9.5); the burner rib must be enter in their logement as shown by the arrow see fig. 9.3). Then position the cap A and the ring B (fig. 9.4 - 9.5). The burner correctly positioned must not rotate (fig.

  • Page 39: Storage Compartment

    Fig. 9.6 Fig. 9.7 Oven door Storage compartment The internal glass panel can be easily The storage compartment is accessible removed for cleaning by unscrewing the through the pivoting panel (fig. 9.7). retaining screws (Fig. 9.6) Do not store flammable material in the oven or in the storage compart- ment.

  • Page 40: Replacing The Oven Light Bulb

    Replacing the oven light Assembly and dismantling bulb of the side runner frames Switch the cooker off at the mains. – Fit the side runner frames into the holes on the side walls inside the When the oven is cool unscrew and oven (Fig.

  • Page 41: Removing The Oven Door

    Removing the oven door Fig. 9.10A The oven door can easily be removed as follows: – Open the door to the full extent (fig. 9.10A). – Attach the retaining rings to the hooks on the left and right hinges (fig. 9.10B).

  • Page 42: Helpful Advice

    Changing the Oven Cavity Light Bulb. If you are in any doubt about carrying out these checks, call the CAPLE Helpline on 0870 241 1142. A charge will be made if the appliance is found to be in working order, or if it...

  • Page 44: Your Guarantee

    YOUR GUARANTEE CAPLE guarantees all parts of this product for one year from the date of pur- chase. During that time, should it become necessary CAPLE engineers will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear, such as lightbulbs.
