Controls, features and connections

1/11 Power switch, motor unit with stepped drive pulley
2 Drive belt *
3 Platter
4 Tonearm counterweight *
5 Tonearm lift lever
6/16 Tonearm rest and removable transport lock
7 Tonearm tube
8 Power supply socket
9 Phono output sockets and earth connection
10 Anti-skating weight *
12 Anti-skating weight support hoop
13 Anti-skating weight adjustment scale
14 Headshell with finger lift and fitted Ortofon OM 3E or Ortofon 2M Red
Connection cable (not shown) *
Power supply (not shown) *
Stylus pressure gauge - white plastic instrument with mN scale (not shown) *
Hexagonal key (not shown) *
2
© Audio Trade GmbH · Pro-Ject RPM 1.3 Genie / Ort OM 3E - Ort 2M Red · Revision 2012.7.1
8
3
9
10
4
13
12
5
6
16
7
14
