- Page 12 The Oyster™ Series Phono Cartridges by S U M I K O 2431 Fifth St. Berkeley . CA 94710 . Tel:510.843.4500 . Fa x:510.843.7120 . www.sumikoaudio.net...
- Page 13 Thank you for your purchase of a Sumiko Oyster Series phono cartridge. Sumiko Oyster™ cartridges are products resulting from over three decades of cartridge design. We believe that delivered high performance can be achieved at reasonable prices. The Oyster™ line is the embodiment of this philosophy. Oyster™...
- Page 14 Blue Point Special EVO III note: The Blue Point Special EVO III is supplied without a stylus guard so extra care must be observed when handling. Because of the likelihood of damaging an exposed generator cartridge during the process of removing and reinstalling the stylus guard, the stylus guard has been omitted from this model. When mounting a Blue Point Special EVO III, take care not to touch the semi-exposed wires leading from the four gold plated bars to the coil structure.
- Page 15 Once the cartridge is mounted, balance the tonearm for the proper vertical tracking force indicated for each model cartridge (see specifications at the end of this manual). To set the tracking force, first balance the tonearm. Locate the counterweight. On virtually all pivoted tonearms, it will be located at the rear of the tonearm (meaning at the opposite end from the cartridge).
- Page 16 We recommend the use of a high quality alignment protractor to determine correct cartridge positioning for the minimum tracking error. If none are available, follow the tonearm manufacturer’s guidelines for overhang and offset angle. Then, tighten the mounting bolts. Note: Do not over tighten the mounting bolts as this may cause damage to the cartridge and is not necessary for optimum performance.
- Page 17 recommended optimum tracking force setting is given for each model in the specification section of this manual. Anti-Skate/Bias: Due to the rotational inertia of pivoted tonearms, the friction of the stylus on the record groove produces a force pulling the stylus toward the center of the record. Anti-Skate (or mechanical bias) is added to compensate for this force in order to equalize the stylus tracking on the sides of the groove walls.
- Page 18 applied by playing a record. For this reason, when using one of these cartridges a value of roughly one half that of the tracking force is the ideal value. In other words, the Blue Point Special EVO III has an ideal tracking force of 2.0 grams.
- Page 19 of acoustical music, recorded in real space, to determine the tonal balance and soundstage presentation. Adjust the tonearm pivot height upwards 5 1/6 inch at a time and listen to the changes. When the correct orientation has been achieved, the soundstage will be better defined and the music will have a richer harmonic structure. Additionally, surface noise will be reduced dramatically.
-
Page 20: Maintenance
phono stage relative to a line stage device such as a CD player. Note: If your receiver or pre-amp has capacitance loading capabilities, a Sumiko high output moving coil cartridges should be loaded with a value no higher than 200pf, and ideally below 100pf. Maintenance Cleaning: Optimum performance can only be achieved by maintaining a clean stylus and record surface. - Page 21 Important: Extreme caution should be exercised in cleaning the stylus. A single front to back motion can permanently damage the cantilever. Flux Build-Up: Any phono cartridge that comprises a magnetic circuit for generating electricity is subject to an unwanted magnetic flux build-up (bias). We have designed the cartridges in the Oyster™ Series to be less susceptible to this bias than other cartridge designs currently available.
- Page 22 Stylus Replacement: To preserve your record collection, the stylus should be microscopically inspected yearly for wear. Should stylus replacement become necessary, contact your dealer for details on how to accomplish this for your particular Oyster™ cartridge. Moving magnet models can accept a replacement stylus/cantilever assembly. Moving coil cartridges must be traded-in for a new unit as the stylus/cantilever assembly is not user replaceable.
- Page 23 Fine Print (Warranty) This product is warranted to be free of all defects in material and workmanship for one year from the date of original purchase by the original owner. A purchase receipt or other proof of original purchase will be required before warranty service is rendered. This warranty is not transferable and does not apply to any defects caused by negligence, accidents, misuse, modification, disassembly, or repair by other than the manufacturer, or by other than normal use for which this product was intended.
- Page 24 Technical Specifications Model: Blue Point Special EVO III Blue Point No. 2 Pearl Black Pearl Oyster Cartridge Type Frequency Response 12Hz-50KHz 15Hz-25KHz 12Hz – 30KHz 18Hz – 27KHz 30Hz-20KHz Output Voltage/Channel 2.5mV 2.5mV 3.5mV 2.5mV 4.0mV Channel Separation 35db 32db 30db 28db 25db...
