OPERATOR'S MANUAL
14.4 Volt 1/2 in. (13 mm) Drill-Driver
R83015
Two Speed/Reversible
R
This new drill has been engineered and manufactured to our high standards for dependability, ease of operation, and operator
safety. When properly cared for, the drill will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
Thank you for buying a RIDGID product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
1
®
X
Advertisement
Table of Contents
Related Manuals for RIDGID R83015
Summary of Contents for RIDGID R83015
- Page 1 OPERATOR’S MANUAL 14.4 Volt 1/2 in. (13 mm) Drill-Driver ® R83015 Two Speed/Reversible This new drill has been engineered and manufactured to our high standards for dependability, ease of operation, and operator safety. When properly cared for, the drill will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ■ Introduction ..................................2 ■ General Safety Rules ..............................3-4 ■ Specific Safety Rules ............................... 4 ■ Important Safety Instructions for Charger ........................5 ■ Symbols ................................... 6 ■ Specifications .................................. 7 ■ Unpacking ..................................7 ■ Applications ..................................7 ■... -
Page 3: General Safety Rules
GENERAL SAFETY RULES ■ Remove adjusting keys or wrenches before turning WARNING: the tool on. A wrench or a key that is left attached to a rotating part of the tool may result in personal injury. Read and understand all instructions. Failure to follow all instructions listed below, may result in ■... -
Page 4: Specific Safety Rules
GENERAL SAFETY RULES ■ When servicing a tool, use only identical replace- SERVICE ment parts. Follow instructions in the Maintenance ■ Tool service must be performed only by qualified section of this manual. Use of unauthorized parts or repair personnel. Service or maintenance performed failure to follow Maintenance Instructions may create a by unqualified personnel may result in a risk of injury. -
Page 5: Important Safety Instructions For Charger
IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER c. That wire size is large enough for AC ampere WARNING: rating of charger as specified below: Read and understand all instructions. Failure to Cord Length (Feet) 100' follow all instructions listed below, may result in Cord Size (AWG) electric shock, fire and/or serious personal injury. -
Page 6: Symbols
SYMBOLS Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz... -
Page 7: Specifications
SPECIFICATIONS Chuck ............................... 1/2 in. (13 mm) Keyless Motor .................................. 14.4 Volt DC Switch ................................Variable Speed Gear Train ................................. 2 Speed No Load Speed ............................0-400/0-1600/min. Clutch .................................. 24 Positions Charger Input ............................120 V, 60 Hz, AC only Charge Rate ................................ -
Page 8: Features
FEATURES Before using this tool, familiarize yourself with all operating TWO SPEED GEAR TRAIN features and safety requirements. However, do not let The drill-driver has a two-speed gear train designed for familiarity with the tool make you careless. drilling or driving at LO (1) or HI (2) speeds. A slide switch is located on top of your drill to select either LO (1) or HI (2) WARNING: speed. -
Page 9: Features
FEATURES TWO-SPEED GEAR TRAIN (HI-LO) KEYLESS CHUCK DIRECTION OF ROTATION SELECTOR (FORWARD/REVERSE/LOCK OFF) STORAGE BATTERY PACK TORQUE ADJUSTMENT RING DUAL PORT CHARGER 4-1/8 in. Fig. 1... -
Page 10: Operation
OPERATION WARNING: Do not allow familiarity with the drill-driver to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. CHARGING BATTERY PACK The battery pack for this tool has been shipped in a low charge condition to prevent possible problems. - Page 11 OPERATION LED FUNCTION OF CHARGER See Figure 3. BATTERY GREEN ACTION INDICATOR PACK Power Without battery pack Ready to charge battery pack Evaluate Hot battery pack Flashing When battery pack reaches cooled temperature, charger begins fast charge mode Evaluate Cold battery pack Flashing When battery pack reaches warmed temperature, charger...
- Page 12 OPERATION FORWARD/REVERSE/LOCK OFF TO INSTALL BATTERY PACK SELECTOR ■ Lock the switch trigger on the drill by placing the direction of rotation (forward-reverse) selector in center position. See Figure 4. ■ Place battery pack in the drill. Align raised rib on battery pack with the groove inside the drill.
- Page 13 OPERATION TWO SPEED REVERSIBLE GEAR TRAIN (HI-LO) See Figure 4. This tool has the feature of being reversible. The direction SPEED of rotation is controlled by a selector located above the switch trigger. With the drill held in normal operating position, the direction of rotation selector should be positioned to the left of the switch for drilling.
- Page 14 OPERATION INSTALLING BITS UNLOCK See Figure 9. (RELEASE) ■ Lock the switch trigger by placing the direction of rotation selector in center position. See Figure 4. ■ Open or close chuck jaws to a point where the opening is slightly larger than the bit size you intend to use. Also, raise the front of the drill slightly to keep the bit from falling out of the chuck jaws.
- Page 15 OPERATION ADJUSTING ADJUSTABLE TORQUE CLUTCH TO DECREASE RING TORQUE This drill is equipped with an adjustable torque clutch for driving different types of screws into different materials. The proper setting depends on the type of material and the size of screw you are using. TO ADJUST TORQUE ■...
- Page 16 OPERATION DRILLING See Figure 13. When drilling hard smooth surfaces use a center punch to mark desired hole location. This will prevent the drill bit from slipping off center as the hole is started. However, the low speed feature allows starting holes without center punch- ing if desired.
- Page 17 OPERATION CHUCK REMOVAL See Figures 14, 15, and 16. The chuck must be removed in order to use some accesso- ries. To remove: ■ Lock the switch trigger by placing the direction of rota- tion selector in center position. See Figure 4. ■...
-
Page 18: Maintenance
MAINTENANCE BATTERIES WARNING: The battery pack for your tool is equipped with nickel- When servicing use only identical RIDGID ® replace- cadmium rechargeable batteries. Length of service from ment parts. Use of any other parts may create a each charging will depend on the type of work you are doing. hazard or cause product damage. -
Page 19: Warranty
WARRANTY ® RIDGID HAND HELD AND STATIONARY POWER TOOL LIMITED THREE YEAR WARRANTY AND 90-DAY SATISFACTION GUARANTEE POLICY This product is manufactured under license from Ridgid, Inc. WHAT IS NOT COVERED by One World Technologies, Inc. All warranty communications This warranty applies only to the original purchaser at retail should be directed to One World Technologies, Inc. -
Page 20: Customer Service Information
OPERATOR’S MANUAL 14.4 Volt 1/2 in. (13 mm) Drill-Driver ® R83015 Two Speed/Reversible Customer Service Information: For parts or service, contact your nearest RIDGID authorized service center. Be sure to provide all relevant information when you call or visit. For the location of the authorized service center nearest you, please call 1-866-539-1710 or visit us online at www.ridgidwoodworking.com.
