Agents send unsolicited reports (traps) back to a specified IP address
when a particular network activity occurs. Five traps are supported:
cold start, warm start, authentication failure, link down, and link up.
To open the SNMP Network Administration dialog box, double-click
the SNMP icon in the Control Panel.
1. On the Agent tab, enter the physical location of the terminal in
the Location field.
2. Enter the name of the contact person responsible for the terminal
in the Contact field.
3. Assign the terminal to a community by selecting a community
from the Community Name drop-down list. If you want to create
a new community, do the following:
a. Click the Add Community button. The Community
Configuration dialog is displayed.
b. Enter a name for the new community and click the OK
button.
4. To add a trap destination:
a. Click the Add button. The SNMP Configuration dialog is
displayed.
b. Enter the host name or IP address of the NMS trap server and
click the OK button.
