Compaq SANworksNetwork Specification

QuickSpecs
P D
R O D U C T E S C R I P T I O N
SANworks TM Network View by Compaq is a SAN management application providing a consolidation point for storage network visualization, monitoring
and configuration. SAN devices, their Fibre Channel interconnects, and associated status are automatically discovered and represented in an intuitive
topographical display. SAN device management is made easy by double clicking on a device icon. System performance bottlenecks are identified for
proactive resolution and planning. A Java based design allows remote SAN management from any Web browser. SANworks Network View is easily
installed on the Management Appliance and because it is an appliance application; host operating system integration is not a necessity.
C B
U S T O M E R E N E F I T S
Consolidation and integration point for managing all storage networked devices
Reduced IT resource needs through consolidation
Remote access from any network or internet connected PC
At-a-glance visualization of storage fabric and associated status
Proactive SAN availability monitoring
Proactive SAN and storage array performance monitoring for system bottleneck resolution
Management and monitoring of numerous Compaq and third party devices
Operating system agnostic without the need for a server-client-agent setup
Easy installation and setup
Integration into network management tools through SANworks Open SAN Manager by Compaq and the SANworks Management Appliance by
Compaq
Scalable for future growth
S F
O F T W A R E E A T U R E S
Automated in-band and out-of-band device discovery
Graphical SAN topology mapping of all Fibre Channel connected devices and their interconnects
Graphical status display
Automated SAN availability monitoring and notification via e mail and text pager when faults arise
SNMP trap forwarding
Custom notification set up
Performance monitoring and graphical trending of numerous switch and StorageWorks™ array performance metrics
Launch capability for all browser enabled device management tools
Support for numerous Compaq and third party devices
H S
A R D W A R E U P P O R T
SANworks Network View supports the following hardware devices running the software, firmware, or driver versions listed in the software pre-requisite
section. Support is defined as capability for device discovery and monitoring.
SANworks Management Appliance by Compaq
StorageWorks Fibre Channel Storage Hub 12 by Compaq (with management option)
StorageWorks Modular Data Router by Compaq
Fibre Channel switches:
DA-10852 Canada — Version 7 — April 9, 2002
/ O
V E R V I E W
/ F
U N C T I O N A L I T Y
SANworks Network View V2.0A by Compaq
