  • Page 1 2005 Assembly & Operation Manual Models: 810SS & 8611SS 64060 5/2/05...

  • Page 2: Table Of Contents

    INTRODUCTIONS/TABLE OF CONTENTS Congratulations on purchasing the most advanced, all-season skid steer snowplow available! The Blizzard Power Plow® snowplow is clearing new trails for innovative design, rugged durability, quality craftsmanship and superior performance. Our exclusive products are manufactured and tested in Michigan’s Upper Peninsula, the snow capital of the Midwest.

  • Page 3: Safety

    SAFETY WARNING Prior to operating your Power Plow® snowplow, review the WARNING! label at the passenger’s side rear of the moldboard (shown below). CAUTION NOTE: Read and understand all warnings indicated in this manual prior to operating the snowplow. Warnings and cautions in the manual are indicated by the icons shown at left. NOTE: If at any time the safety labels become illegible, promptly replace them.

  • Page 4: Operation

    OPERATION Your Blizzard Power Plow® snowplow is the most advanced and Compact Position versatile snowplow on the market. The easy-to-use controls (8' or 8'-6" Blade Width) • Primary position when transporting the allow you to automatically adjust the plow blade and wings into snowplow an infinite number of plowing positions.

  • Page 5: Unpacking & Inspection

    UNPACKING & INSPECTION Your Blizzard Power Plow® snowplow has been packaged to withstand transit and weather related damage. Fully inspect all components upon receipt of your plow. In the event of shipping damage or missing parts, immediately contact our Customer Service Department at 1-888-680-8600.

  • Page 6: Technical Specifications

    TECHNICAL SPECIFICATIONS PART SPECIFICATION 8611 PART SPECIFICATION 8611 Length 96” (8’) 102” (8’6”) Angle Cylinders Thickness 12 gauge 11 gauge Stroke 10” Height 31” 34” Ram Diameter 1-3/4” 2” Reinforcement 4 ribs @ 1/4" Bore Diameter 2” 2-1/4” MOLDBOARD CYLINDERS Cutting Edge 1/2”...

  • Page 7: Torque Specifications

    TORQUE SPECIFICATIONS Grade Identification Marking for J429-Grade 5 Bolt Grade Identification Marking for J429-Grade 8 Bolt SAE J429 – Grade 5 SAE J429 – Grade 8 Nominal Nominal Clamp Loads Tightening Torque Clamp Loads Tightening Torque Thread Size Thread Size (lbs) (lbs) “Lubricated”...

  • Page 8: Moldboard Assembly

    MOLDBOARD ASSEMBLY 60005 Remove dust cap from both of the slide box cylinders located at the center/rear of the moldboard. Attach adapters (60007 on the 810SS and 60272 on the 8611SS) to each of the base ports and rod ports. 60007 NOTE: All of the hydraulic adapters can be found packaged with the manifold assembly.

  • Page 9: A-Frame Assembly

    A-FRAME ASSEMBLY The manifold and angle cylinders have been secured to the A-Frame at the factory; however, each contains several components that you will need to install. Remove the A-Frame cover to gain access to the manifold. Each of the hose ports on the manifold are covered with stretch wrap.
  • Page 10 HYDRAULIC GUIDE 64060 (2005-810&8611SkidSteer).doc...
  • Page 11 SCHEMATIC (BOTTOM) (TOP) ELECTRICAL SCHEMATIC LEFT SLIDE BOX RIGHT SLIDE BOX RIGHT ANGLE LEFT ANGLE 3000 PSI 1500 PSI 1500 PSI (2650 PSI) (2650 PSI) 1700 PSI 1700 PSI (2800 PSI) (2800 PSI) 50 PSI 50 PSI 50 PSI 50 PSI 5 PSI 50 PSI HYDRAULIC SCHEMATIC...

  • Page 12: Electrical Assembly

    ELECTRICAL-ASSEMBLY Connect the manifold coil harness to the plow harness. Feed the opposite end of the plow harness through the top access hole in the A-frame (same as 3/4" tank hydraulic hose) located on the driver’s side. GROUND MOUNT Attach the grounds on the coil wire harness and plow HOLE MANIFOLD harness with a 3/8"-16 x 1-1/2"...
  • Page 13 CONTROL SCHEMATIC 64060 (2005-810&8611SkidSteer).doc...
  • Page 14 ELECTRICAL- ASSEMBLY 64060 (2005-810&8611SkidSteer).doc...
  • Page 15 ELECTRICAL ASSEMBLY 64060 (2005-810&8611SkidSteer).doc...
  • Page 16 ELECTRICAL- ASSEMBLY 64060 (2005-810&8611SkidSteer).doc...
  • Page 17 ELECTRICAL-ASSEMBLY-COIL HARNESS SS COIL HARNESS (62136) 64060 (2005-810&8611SkidSteer).doc...
  • Page 18 AUXILIARY CONTROL HARNESS W/ DIODES (OPTIONAL) 64060 (2005-810&8611SkidSteer).doc...

  • Page 19: Mounting & Dismounting Instructions

    MOUNTING & DISMOUNTING INSTRUCTIONS Prior to operating your Power Plow® snowplow, review the Mounting and Dismounting Instructions label on the back of the driver’s side moldboard. NOTE: If at any time the Mounting and Dismounting Instructions label, or any other label attached to your snowplow become illegible, promptly replace them.

  • Page 20: Testing Your Plow

    TESTING 1. To test all of the functions on the Power Plow, your snowplow needs to be properly attached to the skid steer. Refer to the Mounting & Dismounting label on the back of the plow. 2. Complete the hydraulic connections with the skid steer turned off.

  • Page 21: Maintenance

    MAINTENANC MAINTENANCE PERIODICALLY YEARLY Check fasteners for tightness. Torque to specifications. Check hoses for wear and leaks. Check cylinders for leaks; inspect rod ends for corrosion & pitting Lubricate all exposed cylinder rod ends with liquid white lithium grease to prevent corrosion.

  • Page 22: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE SOLUTION S5 coil should magnetize with each S5 coil is not magnetizing. function. Plow functions will not work after all Solenoid cartridge valve may be Determine a damaged cartridge valve connections are made or plow functions contaminated or damaged. A bent or by reversing the driver’s side and are slow.
  • Page 23 NOTES 64060 (2005-810&8611SkidSteer).doc...

  • Page 24: Moldboard & Wing Parts

    MOLDBOARD & WING PARTS 26/27 27/28 31/32 64060 (2005-810&8611SkidSteer).doc...
  • Page 25 MOLDBOARD & WING PARTS QUANTITY PART NUMBER DESCRIPTION 810SS 8611SS 52074 Moldboard Weldment 52085 61170 Label, WARNING! (Blz1013) 63160 Decal, Center Moldboard (Blz1070) 61171 Label, Skid Steer Mounting & Dismounting (Blz1014) 61292 Cutting Edge, Moldboard (1080) 52139 61196 Bolt, 1/2"-13 x 1-1/2" Carriage Gr8 61623 Bolt, 5/8-11 UNC x 2"...

  • Page 26: A-Frame, Pivot Beam & Manifold Parts

    A-FRAME & PIVOT BEAM PARTS SEE VIEW BELOW 9/10 64060 (2005-810&8611SkidSteer).doc...
  • Page 27 A-FRAME & PIVOT BEAM PARTS QUANTITY PART NUMBER DESCRIPTION 810SS 8611SS 41041 Pivot Beam Weldment 41052 61357 Pin, Cotter, 1/4" x 1-1/2" Z 50069 Pin, 3/4"Dia. x 3" Clevis YZ 41051 Pin, 3/4"Dia. x 5" Clevis YZ 61331 Screw, 1"-8 x 9" HHCS Gr8 P 61008 Nut, 1"-8 Top Lock Z 61217...

  • Page 28: Harnesses, Accessories & Kits

    HARNESSES, ACCESSORIES & KITS 9. Rugged and durable, the 10. Integrate all snowplow controls 3/8"thick, 2-ply construction keeps into your skid steer using an snow off of your windshield and in optional auxiliary control harness. its place—on the ground! The one This 7 ft.
  • Page 29 HARNESSES, ACCESSORIES & KITS PART QUANTITY DESCRIPTION NUMBER 810SS 8611SS 62131 Pistol Grip Control Wire Harness Assembly Includes Ref 1-8 62219 Housing, SS Pistol Grip 2 Halves w/ screws (61613) 62211 Circuit Board & 3 Switch Assembly 70040 Mount Bracket, Wire Harness Extension, Vehicle Side 62210 Harness, SS control w/ pipe 70048...

  • Page 30: Warranty

    LIMITED CONSUMER WARRANTY This warranty covers defects in material and workmanship except as set forth below. WARRANTED PARTY: This warranty applies only to the “Original Purchaser” who purchased this plow from an Authorized Blizzard Dealer, for personal, family or household use. TERM OF WARRANTY: This Blizzard snowplow is warranted for the following period: Parts and labor are warranted for one year from date of purchase.
  • Page 31 COMMERCIAL WARRANTY This warranty covers defects in material and workmanship except as set forth below. WARRANTED PARTY: This warranty applies only to the “Original Purchaser” who purchased this plow from an Authorized Blizzard Dealer, for commercial use. TERM OF WARRANTY: This Blizzard snowplow is warranted for the following period: Parts and labor are warranted for one year from date of purchase.
  • Page 32 810SS & 8611SS POWER PLOW™ 95 Airpark Boulevard Calumet, MI 49913 [888] 680-8600 [906] 482-5555 [906] 482-5445 Fax Blizzard, Power Plow, WidePass and BucketBlade are trademarks of Blizzard Corporation. Blizzard and Power Plow are registered in the United States Patent and Trademark Office.
