- Page 1 Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2022...
-
Page 2: Table Of Contents
Dimming Frequency DMX Fail Fan Settings System Reset DMX Values In-Depth 5. Appendix Keeping Your Verismo™ Fresnel As Good As New Returns (Gasp!) Shipping Issues Tech Specs! Page 2 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 3: Getting Started
Disclaimer: The information contained in this document are subject to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. We reserve the right to update the existing, or create a new document to correct any errors or omissions at any time. -
Page 4: Safety Instructions
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www.blizzardpro.com/support. Page 4 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 5: Meet The Verismo™ Fresnel Ww
3-CH 4-CH 6-CH What It Does Dimmer (0% <--> 100%) Dimmer Fine (0% <--> 100%) Zoom (wide <--> narrow) Strobe (slow <--> fast) Dimming Speed Dimming Curves Page 5 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 6: Verismo™ Fresnel Ww Pin-Up Picture
COB LED and Fresnel Lens The Rear Connections Safety Loop Control Menu Locking Locking Knob Knob 3/5-pin DMX Out 3/5-pin DMX In Power Out Power In Fuse Holder Page 6 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 7: Setup
• Maximum capacitance between conductors – 30 pF/ft. • Maximum capacitance between conductor & shield – 55 pF/ft. • Maximum resistance of 20 ohms / 1000 ft. • Nominal impedance 100 – 140 ohms Page 7 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 8: Cable Connectors
Place a DMX Next terminator on the output of the final fixture to Fixture in Chain ensure best communication. DMX IN DMX OUT Page 8 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 9: Fixture Linking
Overhead mounting requires extensive experience, which includes calculating working load limits, knowledge of the installation material being used, and periodic safety inspections. If you lack these qualifications, do not attempt the installation yourself. Page 9 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 10: Operating Adjustments
<ENTER> button to select the menu function currently displayed, or to enable a menu option. To return to the previous option or menu without changing the value, press the <MENU> button. Page 10 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 11: Control Panel Menu Structure
RDM UID Unique RDM ID Usage Time Power on Total running hrs. LED total LED running hrs. Temperature Celsius (°C) Fahrenheit (°F) Reset Yes/No Load factory defaults Page 11 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 12: Static Mode
2.) Use the <UP/DOWN> buttons to select Dim Speed. Press <ENTER>. 3.) Then use the <UP/DOWN> buttons highlight Off, Low, Medium, or High, then press the <ENTER> button. Page 12 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 13: Dimming Frequency
Medium 091 <-> 255 High Dimming Curves 000 <-> 050 Linear 051 <-> 100 Square law 101 <-> 150 Inverse square law 151 <-> 255 S curve Page 13 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 14: Appendix
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 14 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... -
Page 15: Tech Specs
2-year limited warranty, does not cover malfunction Warranty caused by damage to LEDs. Dimensional Drawings 8.6" (217 mm) 17" Ø 9" (430 mm) (230 mm) 12" (303 mm) Page 15 Verismo™ Fresnel WW - Rev. A © 2022 Blizzard Lighting, LLC... - Page 16 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
