- Page 1 Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2019...
-
Page 2: Table Of Contents
Auto Mode Sound Active Mode Manual Adjustments Dimming Mode Settings DMX Channel Values In-Depth 5. Appendix Keeping Your Lux Capacitor™ As Good As New Returns (Gasp!) Shipping Issues Tech Specs Page 2 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 3: Lux Capacitor
Congratulations on purchasing the Lux Capacitor™, the ultra-warm white retro blinder with intense background color effects. Now that you’ve got your Lux Capacitor™, you should carefully unpack the box and check the contents to ensure that all parts are present and in good condition. -
Page 4: Safety Instructions (Don't Stick Your Hand In The Toaster!)
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www. blizzardpro.com/support. Page 4 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 5: Meet The Lux Capacitor
2. MEET THE LUX CAPACITOR™ MAIN FEATURES • 3* 60W warm white LEDs (2200K) • 48* 0.5W RGB LEDs (background effects) • Individual control of warm white LEDs • 30 speed controllable built-in programs • Sound active mode available via standalone or DMX •... -
Page 6: The Lux Capacitor™ Pin-Up Picture
Figure 1: The Lux Capacitor™ Pin-Up Picture 3* 60W Warm White LEDs Locking Knobs 48* 0.5W Mounting Bracket Background LEDs Figure 2: The Rear Connections DMX IN DMX OUT FUSE: POWER IN POWER OUT 10A, 250V Power Power Fuse 4-Button... -
Page 7: Setup
Reattach the fuse holder, and then reconnect power. Connecting A Bunch of Lux Capacitor™ Fixtures You will need a serial data link to run light shows using a DMX-512 controller or to run shows on two or more fixtures set to sync in mas- ter/slave operating mode. -
Page 8: Cable Connectors
Step 3: Connect other fixtures in the chain from output to input as above. Place a DMX terminator on the output of the final fixture to ensure best communication. Page 8 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 9: Fixture Linking (Master/Slave Mode)
• Safety cables MUST ALWAYS be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Page 9 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 10: Operating Adjustments
4. OPERATING ADJUSTMENTS The Control Panel All the features and different modes possible with the Lux Capacitor™ are accessed by using the control panel. There are 4 control buttons below the display which allow you to navigate through the various control panel menus. -
Page 11: Control Panel Menu Structure
1.) Daisy chain fixtures together via DMX input/output connections. 2.) The first fixture in the DMX chain is the master fixture, and the following units will operate in unison with the master. Page 11 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 12: Auto Mode
1.) Navigate the main menu to reach Settings, press <ENTER>. 2.) Use the <UP/DOWN> buttons to highlight Dimmer Mode, press <ENTER>. 3.) Highlight either Fast or Slow, and press <ENTER> to confirm. Page 12 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 13: Dmx Channel Values In-Depth
224 <--> 239 Program 14 240 <--> 255 Program 15 000 <--> 255 Built-in Program Speed (slow <--> fast) 000 <--> 255 Sound Active Mode (sensitivity: high <--> low) Page 13 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 14: Appendix
5. APPENDIX Keeping Your Lux Capacitor™ As Good As New The fixture you’ve received is a rugged, tough piece of pro lighting equipment, and as long as you take care of it, it will take care of you. That said, like any- thing, you’ll need to take care of it if you want it to operate as designed. -
Page 15: Tech Specs
Neutrik AG, Neutrik USA, or any related entity. Neutrik® and power- CON® are registered trademarks of Neutrik AG. Dimensional Drawings 6.5” 12.6” (320mm) (164mm) 3” (74mm) Page 15 Lux Capacitor™ Manual Rev. A © 2019 Blizzard Lighting, LLC... - Page 16 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
