Page 1: Mystacl™ Z
Blizzard Lighting, LLC http://www.blizzardpro.com Waukesha, WI USA Copyright (c) 2019... -
Page 2: Table Of Contents
Auto & Sound Active Modes Manual Adjustments DMX Channel Values In-Depth 5. Appendix Keeping Your MystACL™ Z As Good As New Returns (Gasp!) Shipping Issues Tech Specs Dimensional Drawings Page 2 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 3: Getting Started
Blizzard Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the right to update the existing document or to create a new document to correct any errors or omissions at any time. -
Page 4: Safety Instructions (Don't Stick Your Hand In The Toaster!)
Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please open a support ticket at www. blizzardpro.com/support. Page 4 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 5: Meet The Mystacl™ Z
Pixel Group 3+4 R/G/B/W Intensity 15-18 Pixel Group 5+6 R/G/B/W Intensity 19-22 Pixel Group 7+8 R/G/B/W Intensity 23-26 Pixel Group 9+10 R/G/B/W Intensity 7-46 Individual Pixels 1-10 R/G/B/W Intensity Page 5 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 6: The Mystacl™ Z Pin-Up Picture
Full Color, 5-Button LCD Control Panel Figure 2: The Front Panel Power Fuse RJ45 3-Pin DMX Input Holder Display In/Out In/Out Power Power Menu 5-Pin DMX Output Switch Buttons In/Out Page 6 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 7: Setup
Maximum capacitance between conductors – 30 pF/ft. Maximum capacitance between conductor & shield – 55 pF/ft. Maximum resistance of 20 ohms / 1000 ft. Nominal impedance 100 – 140 ohms Page 7 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 8: Cable Connectors
Step 3: Connect other fixtures in the chain from output to input as above. Place a DMX terminator on the output of the final fixture to ensure best communication. Page 8 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 9: Fixture Linking (Master/Slave Mode)
• Safety cables MUST ALWAYS be used. • Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Page 9 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 10: Mounting Points
Please be aware, you should have a qualified electrician performing all of your electrical connection needs. Be sure to complete all rigging and installation procedures before connecting the main power cord to the appropriate wall outlet. Page 10 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 11: Clamp Mounting
3.) ¼ Turn Quick Lock Fasteners Securing the Fixture Regardless of the rigging option you choose for your fixtures always be sure to secure your fixture with a safety cable. Page 11 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 12: Operating Adjustments
Use the <UP>, <DOWN>, and <RIGHT> buttons to navigate the menu op- tions. Press the <OK> button to enable a menu option. To return to the previ- ous option or menu without changing the value, press the <LEFT> button. Page 12 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 13: Control Panel Menu Structure
DMX Tilt 000-255 value functions. Function 000-255 Dimmer 000-255 Strobe 000-255 Macro 000-255 000-255 Green 000-255 Blue 000-255 White 000-255 Chase 000-255 Chase Speed 000-255 Reset All Reset Page 13 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 14: Dmx Mode
2.) Use the <UP/DOWN> buttons to highlight any function, press <RIGHT>. 3.) Now use the <UP/DOWN> buttons scroll through the values ranging from 000-255, press <OK>. (see DMX Values In-Depth) Page 14 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 15: Dmx Channel Values In-Depth
Pattern 10 175 <-> 190 Pattern 11 191 <-> 206 Pattern 12 207 <-> 222 Pattern 13 223 <-> 255 Pattern 14 000 <-> 255 Pattern Macro Speed Page 15 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... - Page 16 000 <-> 255 Pixel Group 1 - Red 000 <-> 255 Pixel Group 1 - Green 000 <-> 255 Pixel Group 1 - Blue 000 <-> 255 Pixel Group 1- White Page 16 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC...
- Page 17 000 <-> 255 Pixel 10 - Red 000 <-> 255 Pixel 10 - Green 000 <-> 255 Pixel 10 - Blue 000 <-> 255 Pixel 10 - White Page 17 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC...
-
Page 18: Appendix
Damage incurred in shipping is the responsibility of the shipper, and must be reported to the carrier immediately upon receipt of the items. Claims must be made within seven (7) days of receipt. Page 18 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... -
Page 19: Tech Specs
Neutrik AG, Neutrik USA, or any related entity. Neutrik® and power- CON® are registered trademarks of Neutrik AG. Dimensional Drawings 5.5” 20.3" (513.9 mm) (137.8 mm) Page 19 MystACL™ Z Manual Rev. A © 2019 Blizzard Lighting, LLC... - Page 20 Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
