Mains power connection

The turntable is supplied with a power supply suitable for your country's mains supply. Check the label before
connecting to ensure compliance with the mains rating in your house.
Connect the low voltage plug from the power supply to the socket (13) on the rear of the record player
before connecting the power supply to the mains.

Switching on and off

Pressing the power switch (20) alternately starts or stops the motor.

Changing replay speed

33
Speed Box
SPEED BOX
Press the speed change button (24) to switch between 33 and 45 r.p.m.. The selected speed is shown
respectively by the lit green LED (33 r.p.m.) or red LED (45 r.p.m.).
To replay records at 78 r.p.m. perform the following steps: Remove the platter (5) and using the tool (3a)
from the accessory kit. Fit the belt (3) around the larger diameter step of the pulley (2). Replace the Platter,
start the turntable at 33 r.p.m. and switch the speed to 45 r.p.m., the platter will then revolve at 78 r.p.m..
To play at 45 or 78 r.p.m. please always start the turntable at 33 r.p.m. and then switch to the higher speed
when it has attained full speed.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.
If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.
Always disconnect the record player from the mains power supply as a precaution before maintenance!

Useful tips

The record player should be positioned on a low-resonance surface such as wood or multiple layer ply board
to avoid structural vibrations disturbing replay.
Technical specifications PRO-JECT RPM 6.1 SB / Pro-Ject 9c
* Electronic speed change
Speed variance
Wow and flutter
Signal to noise
Effective tonearm mass
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
6
© Audio Trade GmbH · Pro-Ject RPM 6.1 SB · Revision 2012.7.1
SPEED
45/78
Speed 33 45/78
33/45 and 78 r.p.m.
±0,5 %
±0,08 %
70dB
11g
9 " (230mm)
18mm
6W
16V/500mA AC, suitable for your country's mains supply
385 x 170 x 330mm
8kg
