Connection to the amplifier

Connect the tonearm cables to the Phono input (sometimes labelled gram, disc or RIAA) on your amplifier. Make
sure that the phono input offers correct matching and amplification for the type of cartridge used. Line inputs
(such as CD, Tuner, Tape or Video) are not suitable.
Take care to connect the left and right channels correctly. The right channel is usually marked red, the left
channel black or white. Check the manual supplied with your amplifier for relevant information. An earthing
wire may be connected to the screw terminal on your amplifier you encounter hum problems when using the
record player.
If your amplifier does not have an input suitable for phono cartridges, you will require a separate phono
amplifier stage for MM or MC cartridges which is then connected between the record player and a free line
level input of the amplifier.
For detailed product information regarding Pro-Ject Audio interconnect cables and phono amplifiers please
refer to the Pro-Ject web site www.project-audio.com.

Mains power connection

The turntable is supplied with the universal power supply with 3 exchangeable sockets adapters suitable for all
countries. Select the correct adapter for your country and insert the adapter to the exchangeable part of the
power supply.
Connect the low voltage plug from the power supply to the socket (27) on the rear of the record player before
connecting the power supply to the mains.
Fitting the lid
Fit the lid (dust cover 19) carefully over the hinge prongs and adjust the screws (21) until the lid stays open
where you want it to without being too stiff to open or close.
Switching ON and OFF, changing replay speed
The turntable is equipped with a three-position switch for ON/OFF and electronic speed change. To play
records at 33 rpm. press this switch (4) to the rear side. To play records at 45 rpm. press this switch (4) to the
front side as shown on illustration below.
