Appendix A
2. Select the Service from the
3. Enter the IP Address of the server that you want the
Internet users to access. For example, if the web
server's Ethernet adapter IP address is 192.168.1.100,
you would enter 100 in the field provided. Then check
the Enable checkbox for the entry. Consider the
examples below:
Appli- Start Proto-
cation and End col
7777 to
UT Both
27900
27015 to
Halflife Both
27015
PC 5631 to
UDP
Anywhere 5631
500 to
VPN IPSEC UDP
500
4. Configure as many entries as you like.
When you have completed the configuration, click Save
Settings.
I can't get an Internet game, server, or application to work.
If you are having difficulties getting any Internet game,
server, or application to function properly, consider
exposing one PC to the Internet using DeMilitarized
Zone (DMZ) hosting. This option is available when an
application requires too many ports or when you are not
sure which port services to use. Make sure you disable all
the forwarding entries if you want to successfully use DMZ
hosting, since forwarding has priority over DMZ hosting.
(In other words, data that enters the Router will be checked
first by the forwarding settings. If the port number that
the data enters from does not have port forwarding, then
the Router will send the data to whichever PC or network
device you set for DMZ hosting.) Follow these steps to set
DMZ hosting:
1. Access the Router's Web-based Utility by going to
http://192.168.1.1 or the IP address of the Router. Go
to the Firewall -> Single Port Forwarding tab.
2. Disable the entries you have entered for forwarding.
3. Go to the Setup -> DMZ tab.
4. Enter the Ethernet adapter's IP address of the computer
you want exposed to the Internet. This will bypass the
NAT security for that computer.
5. Select Enable to enable DMZ Hosting.
When you have completed the configuration, click Save
Settings.
4-Port Gigabit Security Router with VPN
Application column.
IP Address Enable
192.168.1.100 X
192.168.1.105 X
192.168.1.102 X
192.168.1.100 X
I forgot my password, or the password prompt always
appears when saving settings to the Router.
Reset the Router to factory defaults by pressing the Reset
button for ten seconds and then releasing it. If you are still
getting prompted for a password when saving settings,
then perform the following steps:
1. Access the Router's web interface by going to
http://192.168.1.1 or the IP address of the Router.
Enter the default password admin, and click the
Administration -> Management tab.
2. Enter the old password in the
3. Enter a different password in the
and enter the new password in the Confirm New
Password field to confirm the password.
Save Settings.
4. Click
I am a PPPoE user, and I need to remove the proxy
settings or the dial-up pop-up window.
If you have proxy settings, you need to disable these on
your computer. Because the Router is the gateway for the
Internet connection, the computer does not need any
proxy settings to gain access. Please follow these directions
to verify that you do not have any proxy settings and that
the browser you use is set to connect directly to the LAN.
For Microsoft Internet Explorer 5.0 or higher:
Start, Settings, and Control Panel. Double-click
1. Click
Internet Options.
2. Click the Connections tab.
3. Click LAN settings and remove anything that is
checked.
4. Click OK to go back to the previous screen.
5. Click the option Never dial a connection. This will
remove any dial-up pop-ups for PPPoE users.
For Netscape 4.7 or higher:
Netscape Navigator, and click Edit, Preferences,
1. Start
Advanced, and Proxies.
2. Make sure you have Direct connection to the Internet
selected on this screen.
3. Close all the windows to finish.
To start over, I need to set the Router to factory default.
Hold the Reset button for up to 30 seconds and then
release it. This will return the password, forwarding, and
other settings on the Router to the factory default settings.
In other words, the Router will revert to its original factory
configuration.
Troubleshooting
Old Password field.
New Password field,
36
