Configure Internet Protocol (IP) Mode on an

RV Series Router

Objective

The Internet Protocol (IP) Mode tells your router what IP version your local network is using

in comparison to what version the Wide Area Network (WAN) uses. It is important to

configure this option correctly as certain features may or may not be available on your router

depending on what the state of your network is.

This article aims to show you how to configure the IP Mode on an RV Series Router.

RV Series

1.0.3.16 — RV130, RV130W

1.0.0.17 — RV132W

1.0.0.21 — RV134W

Step 1. Log in to the web-based utility and choose Networking > IP Mode.

Note: The images on this article are taken from the RV130W router. Menu options may vary

per model.

Step 2. In the IP Mode field, choose an option from the drop-down list.

Table of Contents

Do you have a question about the RV Series and is the answer not in the manual?

Page 1 This article aims to show you how to configure the IP Mode on an RV Series Router. Applicable Devices...
Page 2 If you are using RV130 or RV130W, the options are: LAN:IPv4, WAN:IPv4 — Both the LAN and the WAN use IPv4. LAN:IPv6, WAN:IPv4 — Use this if the LAN only uses IPv6 but the WAN uses IPv4. If you choose this option, you may proceed to the Static 6to4 DNS section.
Page 3 Step 2. In the Domain 01 field, enter a domain that you want to redirect to an IP address. You can use up to five domains. Note: In this example, the domain used is cisco.com. Step 3. For each domain, enter the IP address on the corresponding IP field.
Page 4 IP address of the router. If the page is not redirected automatically in 2-3 minutes, please enter the new IPv4 or IPv6 address to log in to the router. You should now have successfully configured the IP mode on your RV Series Router.
