Chapter 5
UPnP
Universal Plug and Play (UPnP) can used to set up public
services on your network. When the UPnP function is
enabled, Windows XP can add or delete entries to the
underlined UPnP Forwarding Table. Some Internet games
require enabling UPnP.
UPnP If you want to use UPnP, keep the default setting,
Enable. Otherwise, select Disable.
Administration > Log
Administration > Log
Log Setting
Log Level Select the log level(s) that the Router should
record. Log levels and their meanings are:
Log Levels
Level Severity Name
7 LOG_DEBUG
6 LOG_INFO
5 LOG_NOTICE Normal but significant condition
4 LOG_WARNING
3 LOG_ERR
2 LOG_CRIT
1 LOG_ALERT
0 LOG_EMERG
4-Port Gigabit Security Router with VPN
Description
Debug-level message
Informational messages only
Warning conditions
Error conditions
Critical conditions
Immediate action needed
System unusable
Setting Up and Configuring the Router
Outgoing Log Select Enable to cause all outgoing
packets to be logged. You can then click View Outgoing
Table to display information on the outgoing packets
including Source IP, Destination IP, and Service/Port
number.
Incoming Log Select Enable to cause all incoming packets
to be logged. You can then click View Incoming Table to
display information on incoming packets including Source
IP, Destination IP, and Service/Port number.
Email Alerts
Email Alerts Select Enable to cause an e-mail to be sent
immediately if a DoS (Denial of Service) attack is detected.
If enabled, fill in the e-mail address information in the
remaining fields in this section.
Denial of Service Thresholds
(Denial of Service) attacks which need to be blocked by
the built-in Firewall before an e-mail alert is sent. The
minimum value is 20, the maximum value is 100.
Log Queue Length The default is 50 entries (Router will
e-mail the log if there are more than 50 entries).
Log Time Threshold The default is 10 minutes (Router
will e-mail the log every 10 minutes).
SMTP Mail Server Enter the address (domain name) or
IP address of the SMTP (Simple Mail Transport Protocol)
Server you use for outgoing e-mail.
Email Address for Alert Logs
the Log is to be sent to.
Return Email Address The e-mail will show this address
as the Sender's address.
Enable SMTP Authentication
requires Authentication, you can enable it here, and enter
the Username and Password.
E-mail Log Now Press this button to cause the log to be
e-mailed immediately.
Syslog
Enable Syslog
Select the checkbox if you want to use
this feature.
Syslog Server Enter the IP Address in this field when
Enable Syslog is checked.
Local Log
Local Log Enable this if you want to see a log of all
incoming and outgoing URLs or IP addresses.
View Log Click this button when you wish to view the
logs. A new window will appear with the log data.
Enter the number of DoS
Enter the e-mail address
If your SMTP server
25
