System Planner

The information on this form will enable your AT&T Service Technician to install your new MERLIN Plus
system so that it works exactly as you want. It is important that you provide this information PRIOR TO
INSTALLATION. In addition to installing your system, the Service Technician will train you to use it, so
you MUST have someone present during the installation.
What is the name and phone number of the person who will be present when your system is installed?
Name
Fill out the attached System Configuration Form using the following guidelines:
1 Under Dial Signals, check one of the following:
•
"Touch-Tone"
•
"Rotary (Pulse)"
2 Under Long Distance Dialing, check one of the following:
•
Toll-Prefix
•
"Area Code Only"
3 Under Line Assignments:
a Write in the name of the system attendant and the attendant's location next to Intercom (Icom)
No. 10.
b Next to the remaining numbers (11-29), write in the names and work locations of the people who will
have MERLIN system telephones.
NOTE: If you will be using the Call Report Feature, do not write a name next to Icom. No. 19.
4 Under Line Assignments, fill in the appropriate boxes to indicate which lines each person will have by
using an:
"R" _ to indicate that the line will ring at that telephone.
"NR" - to indicate that the line won't ring.
"DR" - to indicate that the line will ring after a delay.
Under Automatic Line Selection Sequence, enter the line letters assigned to each telephone in the order
5
that they will be selected by that telephone.
NOTE: See the example, where the President wants line C, a private line to be selected first, and also
wants access to all of the other lines. The entry is C, A, B, D.
Phone
- if all of your telephone lines are Touch-Tone lines.
- if one or more of the lines are rotary-only lines.
- if you have to dial a 1 or 0 before the area code when
making a long distance call.
- if you don't have to dial a 1 or 0 before the area code.
Customer Name
Address
Phone
DOSS Order No.
System Planner 1
