- Page 1 Instruction manual PG2SS Pythagora 30 cm 2 Burner gas domino hob...
- Page 3 GAS HOBS USER AND INSTALLATION INSTRUCTIONS HT Mod 05/07/06...
- Page 4 For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….
- Page 5 CONTENTS General Information page 4 Warning and Safety Instructions page 5 Instructions for Use pages 6–7 Instructions for Installation Pages 8–12 Technical Data Pages 12–14 Conditions of Guarantee Back cover...
-
Page 6: General Information
The aforegoing does not affect your statutory rights. The Warrantee applies to Great Britain and Northern Ireland only. In the event that you require any After Sales Service or advice, please contact the Baumatic Service Department on telephone number – 0118 933 6911. - Page 7 Corgi registered (all Baumatic Engineers are Corgi registered) and for electrical installations, NICEIC registration is recommended. Baumatic Ltd declines any responsibility for injury or damage to persons or property as a result of improper use or installation of this appliance.
- Page 8 USER INSTRUCTIONS INSTRUCTIONS FOR USE These User Instructions should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance. The following models are covered by these instructions: B17.5 BC45 B17.6 BF45 B16.5 B17.7 AS24 BT62...
- Page 9 USER INSTRUCTIONS HELPFUL HINTS Always use the correct diameter pan, one that is the same or slightly larger than the flame ring. The flame should never exceed the diameter of the pan. For model PF75 please make sure you comply with maximum pans' diameters allowed as showed in the picture: The bottom of the pan should be flat and wherever possible, keep the lid on the pan when cooking.
- Page 10 UK Regulations and Safety Standards or their European Norm Replacements: NOTE : UK law stipulates that gas appliances must be installed and repaired by a CORGI Registered Installer (all Baumatic Engineers are CORGI Registered). Gas safety Regulations (Installation & Use)
- Page 11 INSTALLATION INSTRUCTIONS INSTALLATION NOTES 1. Cut the aperture to the dimensions shown below or use the template if printed on the packaging. 2. Invert the Hob and apply the sealing agent provided to match the outer perimeter edge. 3. If the sealing agent is a strip type, the protective covering must be removed from both sides.
-
Page 12: Ventilation Of Rooms
INSTALLATION INSTRUCTIONS VENTILATION OF ROOMS The actual ventilation requirements must be determined by reference to the Statutory Regulations in force. GAS CONNECTION With one exception these appliances must be connected to the gas supply by use of the ½ BSP Elbow, seal and copper pipe and an isolation tap fitted in an easily accessible position. -
Page 13: Installation Instructions
In order to adjust the minimum gas flow proceed as follows: Ignite the burner and turn down to the minimum setting. Remove the control Knob from the gas tap. Adjust the flow either clockwise to decrease or anti-clockwise to increase the flame. Use a screwdriver inserted down the gas tap rod or via the screw head adjacent to the rod for models fitted with a Flame Supervision Device. -
Page 14: Technical Data
MAINTENANCE During the guarantee period, in case of need all service intervention should be referred back to the Baumatic Ltd Service department. Please note that intervention or repair by any unauthorised personnel will invalidate such guarantee, Before carrying out any maintenance, disconnect the appliance from the gas and electricity supplies. - Page 15 BURNER TYPES AND POWER INPUTS : kW Model Large Medium Small Fish Total Max/Min Max/Min Max/Min Max/Min Max/Min 3.0/0.75 1.75/0.44 1.0/0.3 7.50 1.75/0.44 1.0/0.3 3.3/1.5 7.80 1.75/0.44 1.0/0.3 3.3/1.5 7.80 BT62 1.75/0.44 1.0/0.3 3.3/1.5 7.80 3.0/0.75 1.75/0.44 1.0/0.3 3.3/1.5 10.80 3.0/0.75 1.75/0.44 1.0/0.3...
- Page 16 JET SIZING CONVERSION TABLE: NATURAL GAS / LPG Model Large Medium Small Fish NG/LPG NG/LPG NG/LPG NG/LPG NG/LPG 1.15/0.85 0.97/0.65 0.72/0.50 0.97/0.65 0.72/0.50 1.24/0.91 0.97/0.65 0.72/0.50 1.24/0.91 BT62 0.97/0.65 0.72/0.50 1.24/0.91 1.15/0.85 0.97/0.65 0.72/0.50 1.24/0.91 1.15/0.85 0.97/0.65 0.72/0.50 1.24/0.91 1.15/0.85 0.97/0.65 0.72/0.50 1.24/0.91 B16.5 1.15/0.85 0.97/0.65 0.72/0.50...
- Page 17 Baumatic appliance. * In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date.
- Page 18 Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911 Service Fax +44 118 986 9124 Spares Telephone...
-
Page 19: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. - Page 20 Baumatic ® w w w . b a u m a t i c . c o m...
