Red Hat Cluster for Enterprise Linux 5 Configuration page 60

Device — Specify the device file associated with the file system resource.
Options — Mount options.
File System ID — When creating a new file system resource, you can leave this field blank.
Leaving the field blank causes a file system ID to be assigned automatically after you click
OK at the Resource Configuration dialog box. If you need to assign a file system ID expli-
citly, specify it in this field.
Checkboxes — Specify mount and unmount actions when a service is stopped (for ex-
ample, when disabling or relocating a service):
• Force unmount — If checked, forces the file system to unmount. The default setting is
unchecked. Force Unmount kills all processes using the mount point to free up the
mount when it tries to unmount.
• Reboot host node if unmount fails — If checked, reboots the node if unmounting this
file system fails. The default setting is unchecked.
• Check file system before mounting — If checked, causes
system before mounting it. The default setting is unchecked.
IP Address
IP Address — Type the IP address for the resource.
Monitor Link checkbox — Check the box to enable or disable link status monitoring of the
IP address resource
NFS Mount
Name — Create a symbolic name for the NFS mount.
Mount Point — Choose the path to which the file system resource is mounted.
Host — Specify the NFS server name.
Export Path — NFS export on the server.
NFS and NFS4 options — Specify NFS protocol:
• NFS — Specifies using NFSv3 protocol. The default setting is NFS.
• NFS4 — Specifies using NFSv4 protocol.
Options — Mount options. For more information, refer to the nfs(5) man page.
Force Unmount checkbox — If checked, forces the file system to unmount. The default
setting is unchecked. Force Unmount kills all processes using the mount point to free up
the mount when it tries to unmount.
NFS Client
Name — Enter a name for the NFS client resource.
Target — Enter a target for the NFS client resource. Supported targets are hostnames, IP
7. Adding Cluster Resources
52
to be run on the file
fsck
