Creating A Cluster; Global Cluster Properties - Red Hat Cluster for Enterprise Linux 5 Configuration

(or the equivalent). The URL syntax for the luci server is
https://luci_server_hostname:8084
log boxes are displayed. Upon acknowledging the dialog boxes, your Web browser displays
the luci login page.

3. Creating A Cluster

Creating a cluster with luciconsists of selecting cluster nodes, entering their passwords, and
submitting the request to create a cluster. If the node information and passwords are correct,
Conga automatically installs software into the cluster nodes and starts the cluster. Create a
cluster as follows:
1. As administrator of luci, select the cluster tab.
2. Click Create a New Cluster.
3. At the Cluster Name text box, enter a cluster name. The cluster name cannot exceed 15
characters. Add the node name and password for each cluster node. Enter the node name
for each node in the Node Hostname column; enter the root password for each node in the
in the Root Password column. Check the Enable Shared Storage Support checkbox if
clustered storage is required.
4. Click Submit. Clicking Submit causes the following actions:
a. Cluster software packages to be downloaded onto each cluster node.
b. Cluster software to be installed onto each cluster node.
c. Cluster configuration file to be created and propagated to each node in the cluster.
d. Starting the cluster.
A progress page shows the progress of those actions for each node in the cluster.
When the process of creating a new cluster is complete, a page is displayed providing a
configuration interface for the newly created cluster.

4. Global Cluster Properties

When a cluster is created, or if you select a cluster to configure, a cluster-specific page is dis-
played. The page provides an interface for configuring cluster-wide properties and detailed
properties. You can configure cluster-wide properties with the tabbed interface below the cluster
name. The interface provides the following tabs: General, Fence, Multicast, and Quorum Par-
tition. To configure the parameters in those tabs, follow the steps in this section. If you do not
need to configure parameters in a tab, skip the step for that tab.
1. General tab — This tab displays cluster name, the configuration version, and advanced
cluster properties. The parameters are summarized as follows:
3. Creating A Cluster
. The first time you access luci, two SSL certificate dia-
15
