3Com 3C13701 Installation Manual page 12

12 C 2: S
HAPTER YSTEM
Panel LEDs
System Description
S
PECIFICATIONS
Eight LEDs are provided on 3Com Router 5012. Their meaning is explained in the
following table:
Table 2 LEDs of 3Com Router 5012
LED
POWER
SYSTEM
SLOT1
SLOT2
SLOT3
WAN
LAN
Table 3 System description of 3Com Router 5012
Item
Slot
Fixed interface
CPU
Boot ROM
SDRAM
Flash memory
Size (H x W x D)
Weight
Input voltage AC
DC
System power
consumption
Operating temperature
Relative humidity
(noncondensing)
Indication
System power LED: OFF means power is off, ON means power is on.
Hardware system operating LED. Blinking indicates that the system is in
normal operation. Steady ON or OFF means that the system is in abnormal
operation.
MIM LED. ON indicates that the interface module operates normally. OFF
indicates that no module is installed in the slot or the module cannot
operate properly.
SIC LED. ON indicates that the interface card operates normally. OFF
indicates that no interface card is installed in the slot or the interface card
cannot operate properly.
SIC LED. ON indicates that the interface card operates normally. OFF
indicates that no interface card is installed in the slot or the interface card
cannot operate properly.
Fixed synchronous/asynchronous serial interface LED: Show the status of
data transceiving on the serial interface. OFF means that no data is being
transceived. Blinking means that data is being transceived.
Fixed Ethernet interface LED: Shows the status of data transmission on the
fixed Ethernet interface. OFF means that no data is being transceived.
Blinking means that data is being transceived.
5012
Two SIC slots
One MIM slot
One 10/100 Mbps Ethernet interface
One WAN interface
One AUX port
One console port
MPC8241 200 MHz
512 KB
128 MB
32 MB
44.4 x 442 x 315 mm (1.7 x 17.4 x 12.4 in.)
6 kg (13 lb)
Rated voltage range: 100 to 240 VAC, 50 or 60 Hz
Max voltage range: 85 to 264 VAC, 47 to 63 Hz
Rated voltage range: -48 to -60 VDC
Max voltage range: -40 to -75 VDC
60 W
0 to 40°C (32°F to 104°F)
5% to 90%
