Konica Minolta bizhub PRO 951
Specification & Installation Guide
bizhub PRO 951 Specifications
Type
Console
Printing Process
Electrostatographic process using LED
Original Glass
Fixed
Photoconductor
OPC
Luminous Source
Rare gas fluorescent lamp
Developing System Dry, dual-component reverse magnetic
brush developing
Transfer Method
Belt
Fusing Method
Heat roller
Density Setting
Fixed: 9 levels (manual), 2 preset levels
AES: Automatically detects the original
image/background exposure level
to adjust copy density.
Background Removal: 9 levels (manual)
Quality Adjustment Original Type: 4 types (Text/Photo,
Dot Matrix, Photo, Text)
Sharpness: 9 levels (manual)
Text/Photo: 9 levels
Magnification Ratio 1:1 (100%)
Enlargement: 1:1.214 (121.4%), 1:1.294
(129.4%), 1:1.545 (154.5%), 1:2.000 (200%)
Reduction: 1:0.939 (93.9%), 1:0.772
(77.2%), 1:0.647 (64.7%), 1:0.500 (50%)
Zoom/Special ratio magnification ratio:
25% to 400% in 0.1% increments
User preset zoom ratio: 3
Scanning Resolution 600 dpi x 600 dpi
Printing Resolution 1200 dpi x 1200 dpi
Gradation
256
Copy Paper
Fine or Plain: 11 to 80 lb. Bond
(Duplex: 14 to 80 lb. Bond)
Book/News or Embossed: 11 to 57 lb.
Bond
Blank Insert: 11 to 80 lb. Bond
• In addition to standard sizes, custom,
wide paper, tab paper, postcard sizes
are available.
• Coated paper, PrePrinted paper, labels,
embossed paper, OHP transparencies
and envelopes are unavailable.
Copying Speed
Simplex copying: 95 sheets/min.
(8.5" x 11"P, A4P), 55 sheets/min. (A3L),
54 sheets/min. (11" x 17"L)
Continuous Copying 1 to 9,999 copies
Memory
System memory: 512 MB (DDR2)
Program stored memory: 64 MB (flash
memory)
Display main memory (compression and
expansion buffer): 768 MB (SDR-SDRAM)
Non-volatile memory: 1 MB (SRAM +
battery backup)
HDD: 250 GB
Original Type
Sheets, books (spread), three-dimensional
objects
Thickness: 30mm or less
Original Size
Standard: Max. 11" x 17"L (A3w)
Custom: 11.67" x 16.97"
Original Weight
Approx. 15 lb. at maximum
Paper Size
Standard: 12" x 18"L, 11" x 17"L,
8.5" x 14"L, 8.5" x 11"L/P, 9" x 11"P,
5.5" x 8.5"P, SRA3L, A3L, B4L, SRA4L,
A4L/P, B5L/P, A5P, Foolscap
Available to detect A5P instead of
5.5" x 8.5"P, SRA3L instead of 12" x 18"L,
8" x 13"P, 8.12" x 13.2"L, 8.25" x 13"L,
8.5" x 13"L instead of 8.5" x 14"L.
Custom: Min. 7.17" x 5.472"
to Max. 12.76" x 18.23"
Wide paper: 12" x 18"WL, 11" x 1"7WL,
8.5" x 11"WL/P, 5.5" x 8.5"WP, A3WL,
B4WL, A4WL/P, B5WL/P, A5WP
Tab paper: 11" x 17"TL, 8.5" x 11"TL/P,
5.5" x 8.5"TP, A3TL, B4TL, A4TL/P,
B5TL/P
Image Loss
Leading: 3 mm or less
Trailing, right, and left edges: 2 mm or less
Paper Supply
Trays 1, 2; 1,500 sheets (22 lb. Bond)
Method
Warm-Up Time
Approx. 6.5 minutes or less (20˚, 50% RH,
230 V)
First-Page
3.4 seconds or less (8.5" x 11"P, A4P)
Copy Time
Noise
7.9B or less
Power Requirements AC 208–240 V/16 A; 60 Hz
Power Consumption 3.84 KW or less (Main body + Paper
Feeder Unit PF-706 + Finisher FS-532)
Weight
820.1 lb. (372 kg)
Dimensions
Main body: 42.2"(W) x 158"(D) x 57.1"(H)
Main body + Paper Feeder Unit PF-706 +
Finisher FS-532: 102.0"(W) x 15.8"(D) x 57.1"
Main body + Large Capacity Unit LU-409 +
Finisher FS-532: 87.4"(W) x 15.8"(D) x 57.1"(H)
Space Requirements
7.9" or more from the back (back side
(Space required for
of the duct); 3.9" or more from both right
the safe operation)
and left sides
Operating
10°C (50°F) to 30°C (86°F)
Temperature
Humidity
10% to 80%
06/18/2012
1
